一种估计ISAR成像转角的新方法
doi: 10.3724/SP.J.1146.2005.00997
A New Method for Estimating the Rotation Angle of ISAR Image
-
摘要: ISAR成像中的转角估计是进行正确成像的先决条件。该文从分析目标回波信号入手提出了一种新的转角估计方法,对目标转动时不同距离单元回波数据近似为多分量三次相位信号,通过理论推导,得出每个信号分量的三次相位系数与一次相位系数成正比的结论,其比例系数为目标转动的角速度平方,然后采用最大似然方法估计三次相位信号参数,进而得到总转角。外场实测数据结果验证了该文方法的有效性。
-
关键词:
- ISAR成像;转角估计;最大似然
Abstract: The estimation of rotation angle is the precondition for ISAR imaging. In this passage, a new method based on the analysis of the echo signals is proposed. The signals in different range bin are approximated as the multi-component third-order polynomial signals, and the proportion of third-order phase coefficient to first-order phase coefficient is constant just equal to the square of the rotation rate. Then the parameters of the third-order polynomial signal are estimated by the maximum likelihood method. The results of real data show the validity of the method proposed. -
[1] Chen C C and Andrews H C. Targets-motion-induced radar imaging. IEEE Trans. on AES, 1980, 16(1): 2-14. [2] 王国林. 逆合成孔径雷达运动补偿和系统补偿的研究. [博士论文]. 哈尔滨: 哈尔滨工业大学, 1996, 1. [3] Werness S, et al.. Moving target imaging algorithm for SAR data. IEEE Trans. on AES, 1990, 26(1): 57-67. [4] Benjamin C and Ugarte Alberto. Refinement of range-doppler imagery by feedback control. SPIE Automatic Object Recognition Ⅲ, 1993, 1960: 36-46. [5] 李玺, 顾红, 刘国岁. ISAR成像中转角估计的新方法. 电子学报, 2000, 28(6): 44-47. Li Xi, Gu Hong, and Liu Guo-sui. A method for estimating the rotation angle of the ISAR image. Acta Electronica Sinica, 2000, 28(6): 44-47. [6] Peleg S and Porat B. The discrete polynomial-phase transform[J].IEEE Trans. on SP.1995, 43(8):1901-1914 [7] Peleg S and Porat B. The Cramer-Rao lower bound for signals with constant amplitude and polynomial phase[J].IEEE Trans. on SP.1991, 39(3):749-752
