基于微带天线的能量传输技术及其性能研究
doi: 10.3724/SP.J.1146.2005.00889
The Studies of Energy Transmission Technology and Its Performances Based on Microstrip Antennas
-
摘要: 对于安装在旋转部件上的监测系统来说,供能问题一直是一个难点。该文提出了一种基于微带天线的非接触式的能量传输技术,以代替传统的滑环或光电池等能量传输方法。该文以扭矩监测为应用背景,提出了能量传输系统的总体结构和天线馈源方案,并对天线的各种能量传输情况进行了研究,同时分析了旋转速度对能量传输的影响。
-
关键词:
- 微带天线;能量传输;扭矩监测;监测系统
Abstract: For monitoring system which fixed on rotating component, the energy supply is a difficult problem for a long time. A non-contact energy transmission technology based on microstrip antennas is put forward to replace the traditional methods such as slip-rings or optoelectronic cell. Taking torque monitoring as the application background, the total scheme of the energy transmission system and the feeding method of antennas are presented. The various conditions of microstrip antennas in energy transmission course are studied and the influence of rotating velocity on energy transmission is analyzed.
