基于H形缝隙耦合的宽带圆极化微带天线
doi: 10.3724/SP.J.1146.2005.00710
Broadband Circularly Polarized H-Shaped Aperture-Coupled Microstrip Patch Antenna
-
摘要: 制作并测量了一种基于H形缝隙耦合的宽带圆极化微带天线，并讨论了天线的各结构参数对天线性能的影响。测量结果表明：通过Wilkinson功分器馈电，可使天线驻波带宽达47.5％，轴比带宽达50％，方向图前后比达－21dB，实现了低后瓣宽带圆极化微带天线的设计。
-
关键词:
- 微带天线;宽带圆极化天线;H形缝隙耦合
Abstract: Design of broadband circularly polarized microstrip patch antenna which is coupled by two H-shaped apertures is presented in this paper. Based upon the proximity coupling feed by the Wilkinson power divider, the proposed antenna can have a standing wave bandwidth of about 47.5% and the axial-ratio value within 3dB is about 50%. The front-to-back ratio of the antenna radiation pattern is better than #61485;21dB, which indicate the realization of the good circularly polarized and low backward radiation level characteristics. -
[1] Pozar D M. A microstrip antenna aperture coup1ed to a microstrip line[J].Electronics Letters.1985, 21(1):49-50 [2] 张均，刘克诚等著. 微带天线理论与工程. 北京：国防工业出版社, 1988: 237-311. [3] Rathi V, Kumar G, and Ray K P. Improved coupling for aperture coupled microstrip antennas[J].IEEE Trans. on Antennas Propagat.1996, 44(8):1196-1198 [4] Karmakar N C and Bialkowski M E. Circularly polarized aperture-coupled circular microstrip patch antennas for L-band applications[J].IEEE Trans. on Antennas Propagat.1999, 47(5):933-940 [5] Pollar K M. A reciprocity method of analysis for printed slot and slot-coupled microstrip antennas[J].IEEE Trans. on Antennas Propagat.1986, 34(8):1439-1446 [6] Gao Shi-Chang, Li Le-Wei, Leong Mook-Seng, and Yeo Tat-Soon. Wide-band microstrip antenna with an H-shaped coupling aperture. IEEE Trans. on Venhicular Technology, 2002, 54(1): 17-27. [7] Pozar D M and Duffy S M. A dual-band circularly polarized aperture-coupled staked microstrip antenna for global positioning satellite. IEEE Trans. on Antennas Propagat., I997, 45(11): 1618-1626. [8] Wang J, Fralich R, Wu C, and Litva J. Multifunctional aperture coupled stacked anrenna. Electronics. Letters, 1998, 26(10): 2067-2068. [9] Targonski S D and Pozar D M. Design of wideband circularly polarized aperture-coupled microstrip antenna. IEEE Trans. on Antennas Propagat., I993, 41(2): 214-220. -
