双频双极化频率选择表面
doi: 10.3724/SP.J.1146.2005.00627
Dualband and Dual-Polarized Frequency Selective Surfaces
-
摘要: 该文对分形的频率选择表面的特性进行了详细地研究。由于分形包含初始形状的很多比例，谐振也具有分形的比例，同时加上形状的对称性，所以双频双极化频率选择表面就得以实现。利用周期矩量法设计了几种频率选择表面，仿真和实验结果基本相吻合。
-
关键词:
- 频率选择表面;分形;周期矩量法
Abstract: In this paper, the resonance of fractal Frequency Selective Surfaces(FSS) is studied in particular. Because fractals contain several scales of the starting geometry and each of them resonant at a scaled frequency of the original one, the dualband and dual-polarized FSS can be realized plusing the symmetry of the geometry. Several FSSs have been designed by the periodic Method Of Moments(MOM), and simulation and measurement are basically in agreement. -
[1] Peitgen H, Jurgens H, Saupe D. New Frontiers of Scidence [M]. New York, Springer-Verlag, 1992, Chapter 1. [2] Puente C, Romeu J, Pous R, Garcia X, Benitez F. Fractal multiband antenna based on the Sierpinski gasket [J].Electron. Lett.1996, 32(1):1-2 [3] Romeu J, Rahmat-Samii Y. Dual band FSS with fractal elements [J].Electron. Lett.1999, 35(9):702-703 [4] Gianvittorio John P, Romeu Jordi, Blanch Sebastian, Yahya Rahmat-Samii. Self-similar prefractal frequency selective surfaces for multiband and dual-polarized applications [J].IEEE Transactions on Antennas and Propagation.2003, 51(11):3088-3096 [5] Mittra Aj, Chan Chi H, Cwik Tom. Techniques for analyzing frequency selective surfacesA review [J].Proc.IEEE.1988, 76(12):1593-1614 [6] Chen Chao-Chun. Transmission through a conducting screen perforated periodically with apertures [J]. IEEE Transactions on Microwave Theory and Techiniques, 1979, 18(9): 627-632. [7] Rubin Barry J, Bertoni Henry L. Reflection from periodically perforated plane using a subsectional current approximation [J].IEEE Trransactions on Antennas and Propagation.1983, 31(6):829-836 [8] Munk Ben A. Frequency Selective Surface Theory and Design [M]. chapter 2.( New York, Wiley: 2001). -
