全同态加密软硬件加速研究进展

边松; 毛苒; 朱永清; 傅云濠; 张舟; 丁林; 张吉良; 张博; 陈弈; 董进; 关振宇

doi:10.11999/JEIT230448

全同态加密软硬件加速研究进展

doi: 10.11999/JEIT230448

边松¹,
毛苒¹,
朱永清¹,
傅云濠¹,
张舟¹,
丁林²,
张吉良²,
张博³,
陈弈³,
董进^3, ,,
关振宇^1, ,

1.
北京航空航天大学网络空间安全学院北京 100191
2.
湖南大学半导体学院(集成电路学院) 长沙 410000
3.
北京微芯区块链与边缘计算研究院北京 100080

基金项目: 国家重点研发计划(2023YFB3106200)，国家自然科学基金(62002006, 62172025, U21B2021, 61932011, 61932014, 61972018, 61972019, 62202028, U2241213)，国防基础科研项目(JCKY2021211B017)

详细信息

作者简介:
边松：男，副教授，研究方向为隐私计算、AI安全、应用密码学、硬件架构

毛苒：女，博士生，研究方向为隐私计算、全同态加密、硬件安全

朱永清：男，博士生，研究方向为全同态加密、硬件安全、隐私计算

傅云濠：男，硕士生，研究方向为全同态加密、硬件安全

张舟：男，硕士生，研究方向为全同态加密、隐私计算

丁林：男，博士生，研究方向为硬件安全、隐私计算及其专用芯片设计

张吉良：男，教授，研究方向为集成电路设计、集成电路硬件安全、后摩尔时代新型计算架构

张博：男，副研究员，研究方向为RISC-V开放架构芯片、区块链与隐私计算领域专用芯片、微型传感器芯片与系统方案设计

陈弈：男，副研究员，研究方向为集成电路设计、隐私计算软硬协同设计

董进：男，研究员，研究方向为区块链、隐私计算、人工智能、物联网、新型传感器

关振宇：男，教授，研究方向为硬件安全、区块链、视频压缩

通讯作者:
董进　dongjin@baec.org.cn

关振宇　guanzhenyu@buaa.edu.cn

中图分类号: TN918.4; TP309.2
计量
- 文章访问数: 1823
- HTML全文浏览量: 783
- PDF下载量: 416
- 被引次数: 0
出版历程
- 收稿日期: 2023-05-18
- 修回日期: 2023-12-13
- 网络出版日期: 2023-12-22
- 刊出日期: 2024-05-30

A Survey on Software-hardware Acceleration for Fully Homomorphic Encryption

1.
School of Cyber Science and Technology, Beihang University, Beijing 100191, China
2.
College of Semiconductors (College of Integrated Circuits), Hunan University, Changsha 410000, China
3.
The Beijing Academy of Blockchain and Edge Computing, Beijing 100080, China

Funds: The National Key R&D Program of China (2023YFB3106200), The National Natural Science Foundation of China (62002006, 62172025, U21B2021, 61932011, 61932014, 61972018, 61972019, 62202028, U2241213), The Defense Industrial Technology Development Program (JCKY2021211B017)

摘要

摘要: 全同态加密(FHE)是一种重计算、轻交互的多方安全计算协议。在基于全同态加密的计算协议中，尽管计算参与方之间无需多轮交互与大量通信，加密状态下的密态数据处理时间通常是明文计算的$ {10}^{3}\mathrm{～}{10}^{6} $倍，极大地阻碍了这类计算协议的实际落地；而密态数据上的主要处理负担是大规模的并行密码运算和运算所必须的密文及密钥数据搬运需求。该文聚焦软、硬件两个层面上的全同态加密加速这一研究热点，通过系统性地归类及整理当前领域中的文献，讨论全同态加密计算加速的研究现状与展望。
- 全同态加密 /
- 同态算法 /
- 密码硬件加速
Abstract: Fully Homomorphic Encryption (FHE) is a multi-party secure computation protocol characterized by its high computational complexity and low interaction requirements. Although there is no need for multiple rounds of interactions and extensive communications between computing participants in protocols based on FHE, the processing time of encrypted data is typically $ {10}^{3} $ to $ {10}^{6} $ times of that of plaintext computing, and thus significantly hinders the practical deployment of such protocols. In particular, the large-scale darallel cryptographic operations and the cost of data movement for the ciphertext and key data needed in the operations become the dominating performance bottlenecks. The topic of accelerating FHE in both the software and the hardware layers is discussed in this paper. By systematically categorizing and organizing existing literatures, a survey on the current status and outlook of the research on FHE is presented.
- Fully Homomorphic Encryption(FHE) /
- Homomorphic algorithm /
- Cryptographic hardware acceleration

HTML全文

图 1 全同态加密研究进展概述

下载: 全尺寸图片幻灯片

图 2 BGV自举流程

下载: 全尺寸图片幻灯片

图 3 CKKS自举流程

下载: 全尺寸图片幻灯片

图 4 TFHE自举流程算法1 同态累加

下载: 全尺寸图片幻灯片

图 5 同态矩阵-向量乘法

下载: 全尺寸图片幻灯片

图 6 可编程自举中的盲旋转

下载: 全尺寸图片幻灯片

图 7 F1加速器硬件架构

下载: 全尺寸图片幻灯片

图 8 MATCHA架构

下载: 全尺寸图片幻灯片

表 1 符号定义

符号	描述	符号	描述
$ \lambda $	安全参数	$ \chi $	噪声分布
$ p $	明文模数	$ \mathbb{Z}_q^n $	$ \mathbb{Z}_q^n $上的$ n $维向量
$ q $	LWE密文模数	$ R $	$ \mathbb{Z}[X]/\left( {{X^N} + 1} \right) $上的分圆多项式环
$ Q $	RLWE密文模数	$ {R_Q} $	$ {\mathbb{Z}_Q}[X]/\left( {{X^N} + 1} \right) $上的分圆多项式环
$ Q' $	GSW密文模数	$ {\boldsymbol{a}} $	向量域上的元素
$ n $	LWE密文维数	$ {a_i} $	$ a $的第$ i $个元素
$ N $	RLWE密文维数	$ \tilde a $	多项式环上的元素
$ N^{\prime} $	GSW密文维数	$ {\tilde {\boldsymbol{a}}_i} $	多项式环$ \tilde {\boldsymbol{a}} $的第$ i $元素
$ l $	GSW中包含RLWE个数	$ {{\mathrm{LWE}}}_{\boldsymbol{s}}^{n,q}({\boldsymbol{m}}) $	参数$ \left( {n,q} \right) $和密钥$ {\boldsymbol{s}} $加密消息$ {\boldsymbol{m}} $的LWE密文
$ \Delta $	缩放因子	$ {\text{RLWE}}_{{\boldsymbol{\tilde s}}}^{N,Q}({\boldsymbol{\tilde m}}) $	参数$ \left( {N,Q} \right) $和密钥$ {\boldsymbol{\tilde s}} $加密消息$ {\boldsymbol{\tilde m}} $的RLWE密文
$ \varkappa $	自举中未被刷新的位数	$ {\text{RGSW}}_{{\boldsymbol{\tilde s}}}^{N',Q'}({\boldsymbol{m}}) $	参数$ \left( {N',Q'} \right) $和密钥$ {\boldsymbol{\tilde s}} $加密消息$ {\boldsymbol{m}} $的RGSW密文
$ \vartheta $	自举置零的位数	$ d \leftarrow \mathcal{D} $	从分布$ \mathcal{D} $中随机选择一个元素$ d $

下载: 导出CSV

算法1　同态累加
ACC$ \leftarrow b $
For $ i = 1 $ to $ n $ do
$ {\text{ACC}} \leftarrow {\text{ACC}} - {\text{B}}{{\text{K}}_i} \cdot {a_i}{\rm{mod}} q $
End
ReturnACC

下载: 导出CSV

表 2 全同态加密体系对比

加密体系	线性计算	非线性计算	批处理	特点及应用
BFV/BGV加密体系	√	×	√	整数运算，标量乘法，高效层级同态设计
CKKS加密体系	√	△	√	实数运算，多项式近似，离散傅里叶变换
AP/GINX加密体系	√	√	×	比特运算，快速自举，布尔电路

下载: 导出CSV

表 3 近期全同态加密算法的硬件加速方案

年份	加速方案	实验平台	面向算法	实验效果
2020	HEAX^[60]	FPGA	CKKS	与单线程Intel Xeon(R) Silver 4108处理器相比较，HEAX可以实现164～268倍的性能提升
2021	Cheetah^[61]	40 nm ASIC	BFV	相较于当时最好的面向神经网络的同态加密接口解决方案Gazelle^[23]，综合电路可提供约79倍的加速效果
2021	F1^[62]	14 nm/12 nm ASIC	BGV, BFV, GSW, CKKS	性能相较于4核心8线程的3.5 GHz Xeon E3-1240v5 CPU软件实现方案速度平均提高了5400倍，其中最高的可达17000倍，并且比当时最快的硬件加速方案HEAX^[60]快了172到1866倍不等
2022	CraterLake^[63]	14 nm/12 nm ASIC	BGV, GSW, CKKS	性能比CPU(32核64线程3.5 GHz AMD Ryzen Threadripper PRO 3975WX)平均高出4600倍，比之前的最佳全同态加密加速器F1^[62]高出11.2倍
2022	ARK^[64]	7 nm ASIC	CKKS	相较于CPU(2.6 GHz Xeon Platinum 8358)单线程软件实现速度提升了最高18 214倍，相较于GPU实现方案100x^[65]在一些算子上提升了104～563倍，相较于CraterLake^[63]速度提升了1.23～2.58倍
2023	Poseidon^[66]	FPGA	CKKS	对于全同态加密基本运算，Poseidon相较于现有的单线程CPU(3.3 GHz Intel Xeon Gold 6 234)的加速比高达370倍；对于关键算子，Poseidon相较于CPU和FPGA解决方案HEAX^[60]的加速比分别高达1300倍和52倍；对于全同态加密基准测试，Poseidon相较于GPU解决方案100x^[65]和ASIC解决方案F1^[62]的加速比分别高达10.6倍和8.7倍
2023	FxHENN^[67]	FPGA	CKKS	与最先进的基于CPU的HE-CNN推理解决方案LoLa^[68]相比，FxHENN实现了高达13.49倍的推理延迟加速效果和1 187.12倍的能量效率
2023	TensorFHE^[69]	GPU	BFV, BGV	比GPGPU上最先进的全同态加密实现100x^[4]快 2.61 倍;在特定的工作负载下，TensorFHE可以比 F1+^[62]快 2.9 倍
2022	MATCHA^[70]	16 nm ASIC	TFHE	与实现的GPU同态运行库cuFHE^[71]相比，将TFHE门处理吞吐量提高了2.3倍；与FPGA方案TVE^[72]改造的ASIC加速器相比，在能效上将每瓦特吞吐量提高了6.3倍
2022	FPT^[73]	FPGA	TFHE	FPT的自举吞吐量比现有基于CPU(2.1 GHz Intel Xeon Silver 4208 CPU)的单核实现高近937倍，比FPGA方案^[74]高出7.1倍，并且比最近的ASIC方案MATCHA^[8]高出2.5倍。

下载: 导出CSV
