基于主从博弈的分层联邦学习激励机制研究

贾云健; 黄宇; 梁靓; 万杨亮; 周继华

doi:10.11999/JEIT220175

基于主从博弈的分层联邦学习激励机制研究

doi: 10.11999/JEIT220175

1.
重庆大学微电子与通信工程学院重庆 400044
2.
95696部队重庆 400030
3.
重庆金美通信有限责任公司复杂环境通信重庆市重点实验室重庆 400030

基金项目: 国家自然科学基金(62071075, 61971077)，重庆市自然科学基金(cstc2020jcyj-msxmX0704)

详细信息

作者简介:
贾云健：男，博士，教授，研究方向为新一代移动通信网络、网络内生安全

黄宇：男，硕士生，研究方向为联邦学习

梁靓：女，博士，副教授，研究方向为移动通信网络、可信网络

万杨亮：女，硕士，工程师，研究方向为计算机网络与无线通信

周继华：男，博士，研究员，研究方向为无线通信

通讯作者:
梁靓　liangliang@cqu.edu.cn

中图分类号: TN92
计量
- 文章访问数: 799
- HTML全文浏览量: 844
- PDF下载量: 241
- 被引次数: 7
出版历程
- 收稿日期: 2022-02-25
- 修回日期: 2022-06-27
- 录用日期: 2022-08-15
- 网络出版日期: 2022-08-16
- 刊出日期: 2023-04-10

Research on Hierarchical Federated Learning Incentive Mechanism Based on Master-Slave Game

1.
School of Microelectronics and Communication Engineering, Chongqing University, Chongqing 400044, China
2.
95696 Troops, Chongqing 400030, China
3.
Chongqing Key Laboratory of Complex Environment Communication, Chongqing Jinmei Communication Co. Ltd. Chongqing 400030, China

Funds: The National Natural Science Foundation of China (62071075, 61971077), The Natural Science Foundation of Chongqing (cstc2020jcyj-msxmX0704)

摘要

摘要: 为了优化分层联邦学习(FL)全局模型的训练时延，针对实际场景中终端设备存在自私性的问题，该文提出一种基于博弈论的激励机制。在激励预算有限的条件下，得到了终端设备和边缘服务器之间的均衡解和最小的边缘模型训练时延。考虑终端设备数量不同，设计了基于主从博弈的可变激励训练加速算法，使得一次全局模型训练时延达到最小。仿真结果显示，所提出的算法能够有效降低终端设备自私性带来的影响，提高分层联邦学习全局模型的训练速度。
- 分层联邦学习 /
- 博弈论 /
- 激励机制
Abstract: In order to optimize the training delay of the hierarchical Federated Learning (FL) global model, focusing on the selfishness of the terminal devices in the actual scene, an incentive mechanism based on game theory is proposed. Under the condition of limited incentive budget, the equilibrium solution between terminal devices and edge servers and the minimum edge model training delay are obtained. Considering the different number of terminal devices, a variable incentive training acceleration algorithm based on Stackelberg game is designed to minimize the training delay of a global model. Simulation results demonstrate that the proposed algorithm can effectively reduce the impact of terminal devices selfishness and improve the training speed of hierarchical federated learning global model.
- Hierarchical Federated Learning (FL) /
- Game theory /
- Incentive mechanism

HTML全文

图 1 系统模型图

下载: 全尺寸图片幻灯片

图 2 博弈框架图

下载: 全尺寸图片幻灯片

图 3 激励单价 $q$ 与单个终端设备效用的关系

下载: 全尺寸图片幻灯片

图 4 激励单价 $q$ 与单个边缘服务器效用的关系

下载: 全尺寸图片幻灯片

图 5 激励单价 $q$ 与单个终端设备本地计算时间的关系

下载: 全尺寸图片幻灯片

图 6 不同 ${W_1}$ 的值与 ${T_1}$ , ${T_2}$ 的关系

下载: 全尺寸图片幻灯片

图 7 两种算法在不同终端设备总数下训练总时间的比较

下载: 全尺寸图片幻灯片

算法1　基于主从博弈的可变激励训练加速算法
输入： $\mathcal{N} = \{ {i}:{i = }1,2, \cdots ,{N}\}$ ， ${\mathcal{M}_{i}} = \{ {m}:{m = }{\text{1,2,}} \cdots {\text{,}}{M}\}$ ，计算任务Task，数据集 $D$ ， ${W_1} = {W_2} = \cdots = {W_i} = \dfrac{V}{i}$ 。
输出：激励预算分配的均衡点 ${\mathcal{W}_i} = \{ {W_i},i \in \mathcal{N}\}$ ， ${\mathcal{Q}_{i:m}} = \{ {q_{i:m}},m \in {\mathcal{M}_i}\}$ ，终端设备 $m$ 提供的算力均衡解 $\mathcal{F}_{i:m}^{\text{}} = \{ f_{i:m}^ ,m \in {\mathcal{M}_i}\}$ 。
(1) repeat
(2) for $i$ in $N$ do 　(3) 边缘服务器 $i$ 分配激励单价 $\{ {q_{i:m}},m \in {\mathcal{M}_i}\}$ ，激励单价需满足条件 $\displaystyle\sum\limits_{m \in {\mathcal{M}_i} } { {q_{i:m} } } {f_{i:m} } \le {W_i}$ 。终端设备 $m$ 会提供相应的算力　　　 $\left\{ f_{i:m}^ * = {\rm{max}}\left\{ \dfrac{ { {q_{i:m} } } }{ {2\eta k{C_m} } },f_{i:m}^{\max }\right\} ,m \in {\mathcal{M}_i}\right\}$ ，使得自己的效用 ${U_{i:m}}$ 达到最大。
(4) if $t_{i:m}^{{\rm{cmp}}} \ne t_{i:n}^{{\rm{cmp}}}(m \ne n)$ then
(5) 边缘服务器 $i$ 重新分配 ${q_{i:m}}$ ，使得自己的效用函数 ${U_i}$ 达到最大，同时得到时间 ${T_i}$ 。
(6) end for
(7) if ${T_i} < {T_j}(i \ne j)$ then
(8) 云服务器重新分配 $V$ (减小 ${W_i}$ ，增大 ${W_j}$ )。
(9) Until ${T_i} = {T_j}(i \ne j)$

下载: 导出CSV

参考文献(15)

[1]	MCMAHAN B and RAMAGE D. Federated learning: Collaborative machine learning without centralized training data[EB/OL]. https://starrymind.tistory.com/180, 2017.
[2]	NIKNAM S, DHILLON H S, and REED J H. Federated learning for wireless communications: Motivation, opportunities, and challenges[J]. IEEE Communications Magazine, 2020, 58(6): 46–51. doi: 10.1109/MCOM.001.1900461
[3]	LIU Yi, PENG Jialiang, KANG Jiawen, et al. A secure federated learning framework for 5G networks[J]. IEEE Wireless Communications, 2020, 27(4): 24–31. doi: 10.1109/MWC.01.1900525
[4]	McMAHAN B, MOORE E, RAMAGE D, et al. Communication-efficient learning of deep networks from decentralized data[C]. The 20th International Conference on Artificial Intelligence and Statistics, Fort Lauderdale, USA, 2017: 1273–1282.
[5]	LI Tian, SAHU A K, ZAHEER M, et al. Federated optimization in heterogeneous networks[C]. Machine Learning and Systems 2020, Austin, USA, 2020, 2: 429–450.
[6]	MILLS J, HU Jia, and MIN Geyong. Communication-efficient federated learning for wireless edge intelligence in IoT[J]. IEEE Internet of Things Journal, 2020, 7(7): 5986–5994. doi: 10.1109/JIOT.2019.2956615
[7]	LI Tian, SANJABI M, BEIRAMI A, et al. Fair resource allocation in federated learning[C]. The 8th International Conference on Learning Representations (ICLR), Addis Ababa, Ethiopia, 2019: 1–27.
[8]	LIU Lumin, ZHANG Jun, SONG S H, et al. Client-edge-cloud hierarchical federated learning[C]. 2020 IEEE International Conference on Communications (ICC), Dublin, Ireland, 2020: 1–6.
[9]	ABAD M S H, OZFATURA E, GUNDUZ D, et al. Hierarchical federated learning ACROSS heterogeneous cellular networks[C]. 2020 IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), Barcelona, Spain, 2020: 8866–8870.
[10]	SUN Haifeng, LI Shiqi, YU F R, et al. Toward communication-efficient federated learning in the internet of things with edge computing[J]. IEEE Internet of Things Journal, 2020, 7(11): 11053–11067. doi: 10.1109/JIOT.2020.2994596
[11]	SHI Yuanming, YANG Kai, JIANG Tao, et al. Communication-efficient edge AI: Algorithms and systems[J]. IEEE Communications Surveys & Tutorials, 2020, 22(4): 2167–2191. doi: 10.1109/COMST.2020.3007787
[12]	LUO Siqi, CHEN Xu, WU Qiong, et al. HFEL: Joint edge association and resource allocation for cost-efficient hierarchical federated edge learning[J]. IEEE Transactions on Wireless Communications, 2020, 19(10): 6535–6548. doi: 10.1109/TWC.2020.3003744
[13]	KHAN L U, RAJ PANDEY S, TRAN N H, et al. Federated learning for edge networks: Resource optimization and incentive mechanism[J]. IEEE Communications Magazine, 2020, 58(10): 88–93. doi: 10.1109/MCOM.001.1900649
[14]	TRAN N H, BAO Wei, ZOMAYA A, et al. Federated learning over wireless networks: Optimization model design and analysis[C]. IEEE INFOCOM 2019-IEEE Conference on Computer Communications, Paris, France, 2019: 1387–1395.
[15]	LECUN Y, BOTTOU L, BENGIO Y, et al. Gradient-based learning applied to document recognition[J]. Proceedings of the IEEE, 1998, 86(11): 2278–2324. doi: 10.1109/5.726791
