基于深度学习的探地雷达二维剖面图像结构特征检测方法

王辉; 欧阳缮; 刘庆华; 廖可非; 周丽军

doi:10.11999/JEIT211032

基于深度学习的探地雷达二维剖面图像结构特征检测方法

doi: 10.11999/JEIT211032

王辉^{1, 2, 3},
欧阳缮^{1, 3, ,},
刘庆华¹,
廖可非¹,
周丽军⁴

1.
桂林电子科技大学信息与通信学院桂林 541004
2.
贺州学院人工智能学院贺州 542899
3.
桂林电子科技大学卫星导航定位与位置服务国家地方联合工程研究中心桂林 541004
4.
山西省交通科技研发有限公司太原 030032

基金项目: 国家自然科学基金(61871425, 61861011, 61631019)，广西创新驱动发展专项(桂科AA21077008)，山西省交通运输厅科技项目(2019-1-18)

详细信息

作者简介:
王辉：男，1982年生，博士生，副教授，研究方向为探地雷达信号处理、深度学习

欧阳缮：男，1960年生，博士，教授，博士生导师，研究方向为智能信息处理

刘庆华：女，1973年生，博士，教授，硕士生导师，研究方向为智能信息处理、深度学习

廖可非：男，1984年生，博士，副教授，硕士生导师，研究方向为探地雷达信号处理

周丽军：女，1984年生，博士，高级工程师，研究方向为探地雷达信号处理

通讯作者:
欧阳缮　hmoysh@guet.edu.cn

中图分类号: TN957.52
计量
- 文章访问数: 975
- HTML全文浏览量: 1232
- PDF下载量: 175
- 被引次数: 0
出版历程
- 收稿日期: 2021-09-27
- 修回日期: 2022-02-18
- 录用日期: 2022-02-23
- 网络出版日期: 2022-03-07
- 刊出日期: 2022-04-18

Structure Feature Detection Method for Ground Penetrating Radar Two-Dimensional Profile Image Based on Deep Learning

WANG Hui^{1, 2, 3},
OUYANG Shan^{1, 3
, ,},
LIU Qinghua¹,
LIAO Kefei¹,
ZHOU Lijun⁴

1.
School of Information and Communication, Guilin University of Electronic Technology, Guilin 541004, China
2.
School of Artificial Intelligence, Hezhou University, Hezhou 542899, China
3.
Satellite Navigation Positioning and Location Service National and Local Joint Engineering Research Center, Guilin University of Electronic Technology, Guilin 541004, China
4.
Shanxi Transportation Technology R&D Co., LTD, Taiyuan 030032, China

Funds: The National Natural Science Foundation of China (61871425, 61861011, 61631019), Guangxi Special Fund Project for Innovation-driven Development (GuikeAA21077008), Shanxi Transportation Department Projects (2019-1-18)

摘要

摘要: 该文针对探地雷达(GPR) 2维剖面图像中目标特征提取困难及其识别精度较低等问题，采用深度学习方法来提取2维剖面图像中目标的特征双曲线。根据GPR工作的物理机制，设计了一种级联结构的卷积神经网络(CNN)，先检测并去除回波数据中的直达波干扰信号，再利用CNN得到B扫描(B-SCAN)图像的特征图，并对特征信号进行分类识别以提取目标的特征双曲线。同时，为处理各种干扰信号影响目标特征双曲线结构完整性的问题，提出了一种基于方向引导的特征数据补全方法，提高了目标特征双曲线识别的准确率。与方向梯度直方图(HOG)算法、单级式目标检测(YOLOV3)算法和更快速的区域卷积神经网络(Faster RCNN)算法相比，在综合评价指标F上该文方法的检测结果是最优的。
- 探地雷达 /
- 深度学习 /
- 特征检测 /
- 卷积神经网络
Abstract: To solve the problem of the difficulty of target feature extraction and low recognition accuracy in Ground Penetrating Radar (GPR) two-dimensional profile, a deep learning method is used to extract the characteristic hyperbola of targets in B-SCAN image. Physics-based of GPR, a cascade Convolutional Neural Network (CNN) is designed to detect and remove the direct wave interference signal in the echo data. Then, the B-SCAN image is obtained by CNN, and the characteristic signals are classified and recognized to extract the characteristic hyperbola of the target. Meanwhile, in order to deal with the problem that the interference signals affect the structural integrity of the feature hyperbola, a feature data completion method based on directional guidance is proposed to improve the accuracy of the feature hyperbola recognition results. Compared with Histogram of Oriented Gradients(HOG) algorithm, You Only Look Once V3(YOLOV3) algorithm and Faster Region-based Convolutional Neural Network(Faster RCNN) algorithm, the detection result of the proposed method is the best in the comprehensive evaluation index F.
- Ground Penetrating Radar(GPR) /
- Deep learning /
- Feature detection /
- Convolutional Neural Network(CNN)
