基于多尺度特征结合细节恢复的单幅图像去雾方法

张世辉; 路佳琪; 宋丹丹; 张晓微

doi:10.11999/JEIT210868

基于多尺度特征结合细节恢复的单幅图像去雾方法

doi: 10.11999/JEIT210868

张世辉^{1, 2},
路佳琪^1, ,,
宋丹丹¹,
张晓微¹

1.
燕山大学信息科学与工程学院秦皇岛 066004
2.
河北省计算机虚拟技术与系统集成重点实验室秦皇岛 066004

基金项目: 中央引导地方科技发展资金项目(216Z0301G)，河北省自然科学基金(F2019203285)

详细信息

作者简介:
张世辉：男，教授，博士生导师，研究方向为视觉信息处理、模式识别

路佳琪：女，硕士生，研究方向为雾天图像处理、计算机视觉

宋丹丹：女，硕士生，研究方向为对抗样本攻防、计算机视觉

张晓微：男，硕士生，研究方向为对抗样本攻防、计算机视觉

通讯作者:
路佳琪　1078271268@qq.com

中图分类号: TN911.73; TP391
计量
- 文章访问数: 1040
- HTML全文浏览量: 730
- PDF下载量: 202
- 被引次数: 0
出版历程
- 收稿日期: 2021-08-23
- 修回日期: 2021-12-13
- 录用日期: 2021-12-14
- 网络出版日期: 2021-12-27
- 刊出日期: 2022-11-14

Single Image Dehazing Method Based on Multi-scale Features Combined with Detail Recovery

1.
School of Information Science and Engineering, Yanshan University, Qinhuangdao 066004, China
2.
The Key Laboratory for Computer Virtual Technology and System Integration of Hebei Province, Qinhuangdao 066004, China

Funds: The Central Government Guided Local Funds for Science and Technology Development (216Z0301G), The Natural Science Foundation of Hebei Province (F2019203285)

摘要

摘要: 为提高单幅图像去雾方法的准确性及其去雾结果的细节可见性，该文提出一种基于多尺度特征结合细节恢复的单幅图像去雾方法。首先，根据雾在图像中的分布特性及成像原理，设计多尺度特征提取模块及多尺度特征融合模块，从而有效提取有雾图像中与雾相关的多尺度特征并进行非线性加权融合。其次，构造基于所设计多尺度特征提取模块和多尺度特征融合模块的端到端去雾网络，并利用该网络获得初步去雾结果。再次，构造基于图像分块的细节恢复网络以提取细节信息。最后，将细节恢复网络提取出的细节信息与去雾网络得到的初步去雾结果融合得到最终清晰的去雾图像，实现对去雾后图像视觉效果的增强。实验结果表明，与已有代表性的图像去雾方法相比，所提方法能够对合成图像及真实图像中的雾进行有效去除，且去雾结果细节信息保留完整。
- 图像去雾 /
- 细节恢复 /
- 多尺度特征 /
- 非线性加权融合
Abstract: In order to improve the accuracy of the single image dehazing method and the detail visibility of its dehazing results, a single image dehazing method based on multi-scale features combined with detail recovery is proposed. Firstly, according to the distribution characteristics and imaging principles of haze in images, the multi-scale feature extraction module and the multi-scale feature fusion module are designed to extract effectively the haze-related multi-scale features in the hazy image and perform nonlinear weighted fusion. Secondly, the end-to-end dehazing network based on the designed multi-scale feature extraction module and multi-scale feature fusion module are constructed, and the preliminary dehazing results are obtained by using this network. Then, a detail recovery network based on image blocking is constructed to extract detail information. Finally, the detail information extracted from the detail recovery network is fused with the preliminary dehazing results obtained from the dehazing network to obtain the final clear dehazed image, which can enhance the visual effect of the dehazing images. The experimental results show that compared with the existing representative image dehazing methods, the proposed method can effectively remove the haze in the synthetic images and the real-world images, and the detailed information of the dehazing results is kept.
- Image dehazing /
- Detail recover /
- Multi-scale features /
- Non-linear weighted fusion

HTML全文

图 1 所提单幅图像去雾方法流程

下载: 全尺寸图片幻灯片

图 2 MSFEM结构

下载: 全尺寸图片幻灯片

图 3 MSFFM结构

下载: 全尺寸图片幻灯片

图 4 去雾网络的整体结构

下载: 全尺寸图片幻灯片

图 5 基础块结构

下载: 全尺寸图片幻灯片

图 6 细节恢复网络的整体结构

下载: 全尺寸图片幻灯片

图 7 消融实验结果比较

下载: 全尺寸图片幻灯片

图 8 本文方法与已有方法在合成图像上的比较

下载: 全尺寸图片幻灯片

图 9 本文方法与已有方法在真实图像上的比较

下载: 全尺寸图片幻灯片

表 1 不同配置消融实验的PSNR和SSIM指标对比

数据集	MSFEM		MSFEM+MSFFM		MSFEM+MSFFM+细节恢复网络
数据集	PSNR$ \uparrow $	SSIM$ \uparrow $	PSNR$ \uparrow $	SSIM$ \uparrow $	PSNR$ \uparrow $	SSIM$ \uparrow $
SOTS(Indoor)	33.06	0.977	33.52	0.979	35.16	0.988
SOTS(Outdoor)	29.11	0.966	32.64	0.979	33.78	0.985
Middlebury	16.53	0.840	16.61	0.843	17.48	0.864

下载: 导出CSV

表 2 各算法的PSNR和SSIM指标对比

数据集	客观指标	DCP^[9]	DeHazeNet^[13]	AOD-Net^[14]	GridDehazeNet^[16]	FFA-Net^[18]	MSBDN^[25]	所提方法
SOTS(Indoor)	PSNR$ \uparrow $	16.61	19.82	20.51	32.16	36.39	32.51	35.16
SOTS(Indoor)	SSIM$ \uparrow $	0.855	0.821	0.816	0.984	0.989	0.977	0.988
SOTS(Outdoor)	PSNR$ \uparrow $	19.14	24.75	24.14	30.86	33.57	33.64	33.78
SOTS(Outdoor)	SSIM$ \uparrow $	0.861	0.927	0.920	0.982	0.984	0.982	0.985
Middlebury	PSNR$ \uparrow $	11.94	–	13.94	16.94	13.76	17.34	17.48
Middlebury	SSIM$ \uparrow $	0.762	–	0.743	0.856	0.698	0.862	0.864
I-HAZE	PSNR$ \uparrow $	11.99	14.58	15.34	16.53	15.26	23.93	20.73
I-HAZE	SSIM$ \uparrow $	0.528	0.688	0.704	0.768	0.696	0.891	0.813
O-HAZE	PSNR$ \uparrow $	13.27	15.77	16.45	16.75	21.36	24.36	25.80
O-HAZE	SSIM$ \uparrow $	0.576	0.697	0.684	0.766	0.869	0.749	0.875

下载: 导出CSV

表 3 不同算法的运行时间和参数量对比

	GridDehazeNet^[16]	FFA-Net^[18]	MSBDN^[25]	所提方法
运行时间(s)	0.32	0.33	0.05	0.22
参数量(M)	0.96	4.46	31.35	4.89

下载: 导出CSV
