改进型Logistic混沌映射及其在图像加密与隐藏中的应用

刘公致 吴琼 王光义 靳培培

刘公致, 吴琼, 王光义, 靳培培. 改进型Logistic混沌映射及其在图像加密与隐藏中的应用[J]. 电子与信息学报, 2022, 44(10): 3602-3609. doi: 10.11999/JEIT210763
引用本文: 刘公致, 吴琼, 王光义, 靳培培. 改进型Logistic混沌映射及其在图像加密与隐藏中的应用[J]. 电子与信息学报, 2022, 44(10): 3602-3609. doi: 10.11999/JEIT210763
LIU Gongzhi, WU Qiong, WANG Guangyi, JIN Peipei. A Improved Logistic Chaotic Map and Its Application to Image Encryption and Hiding[J]. Journal of Electronics & Information Technology, 2022, 44(10): 3602-3609. doi: 10.11999/JEIT210763
Citation: LIU Gongzhi, WU Qiong, WANG Guangyi, JIN Peipei. A Improved Logistic Chaotic Map and Its Application to Image Encryption and Hiding[J]. Journal of Electronics & Information Technology, 2022, 44(10): 3602-3609. doi: 10.11999/JEIT210763

改进型Logistic混沌映射及其在图像加密与隐藏中的应用

doi: 10.11999/JEIT210763
基金项目: 国家自然科学基金(61771176)
详细信息
    作者简介:

    刘公致:男,副研究员,研究方向为非线性电路与系统

    吴琼:男,硕士生,研究方向为混沌密码理论及应用

    王光义:男,教授,研究方向为新型纳米记忆器件理论及应用、混沌密码、信息加密与保密通信

    靳培培:女,博士生,研究方向为非线性电路及应用、忆阻器神经网络

    通讯作者:

    王光义 wanggyi@163.com

  • 中图分类号: TN918.4; TP309.7

A Improved Logistic Chaotic Map and Its Application to Image Encryption and Hiding

Funds: The National Natural Science Foundation of China (61771176)
  • 摘要: 鉴于原Logistic映射的映射范围有限、混沌参数范围小、分布不均匀等缺陷,该文提出一个新的改进型Logistic混沌映射。该映射有$ \mu $$ \alpha $两个参数,$ {x_{n - 1}} $$ {x_n} $两个初值,参数和初值选取范围可扩展到任意实数,其混沌映射均为满映射,且映射范围可任意调控。将该映射应用到图像加密,其算法采用像素值异或(XOR)加密、像素位置置乱处理。之后再把密文数据隐藏在与密文无关的载图之中。对密文图像做了一系列的分析,包括图像的相邻像素点相关性,直方图分析和密钥敏感性测试。分析结果表明,所提加密算法具有很好的安全性和加密效果。
  • 图  1  改进的Logistic映射

    图  2  加密过程

    图  3  原图与密文图像像素相关性比较

    图  4  直方图比较

    图  5  密文嵌入方式

    图  6  密文隐藏效果比较

    图  7  密文提取与明文还原

    表  1  Logistic映射与改进的Logistic映射比较

    映射范围初值取值范围参数µ取值范围
    原Logistic映射[0,1][0,1](0,4]
    改进的Logistic映射任意实数任意实数任意实数
    下载: 导出CSV

    表  2  明文/密文图像在3个方向上的相关系数

    垂直方向水平方向对角方向
    明文图像0.97800.96850.9380
    密文图像0.0029–0.0342–0.0021
    下载: 导出CSV

    表  3  密钥敏感性分析(%)

    NPCRUACI
    只改变$ {x_{n - 1}} $99.546833.5983
    只改变$ {x_n} $99.569233.6474
    只改变$ \mu $99.579633.6091
    下载: 导出CSV

    表  4  明文敏感性分析(%)

    NPCRUACI
    像素点199.572433.6345
    像素点299.571633.6354
    像素点399.572833.6357
    平均值99.572333.6352
    下载: 导出CSV

    表  5  不同算法时间复杂度比较

    算法时间复杂度
    文献[15]$ O(9 \times M \times N) $
    文献[16]$O(8 \times M \times N \times \log(M \times N))$
    本文$ O(8 \times M \times N) $
    下载: 导出CSV
  • [1] 郝晋, 王伟, 李庆宇, 等. 基于混沌序列与DNA突变原理的彩色图像加密方案[J]. 大连工业大学学报, 2021, 40(3): 214–221. doi: 10.19670/j.cnki.dlgydxxb.2021.0703

    HAO Jin, WANG Wei, LI Qingyu, et al. Color image encryption scheme based on chaotic sequences and DNA mutation principle[J]. Journal of Dalian Polytechnic University, 2021, 40(3): 214–221. doi: 10.19670/j.cnki.dlgydxxb.2021.0703
    [2] 范九伦, 张雪锋. 分段Logistic混沌映射及其性能分析[J]. 电子学报, 2009, 37(4): 720–725. doi: 10.3321/j.issn:0372-2112.2009.04.009

    FAN Jiulun and ZHANG Xuefeng. Piecewise Logistic chaotic map and its performance analysis[J]. Acta Electronica Sinica, 2009, 37(4): 720–725. doi: 10.3321/j.issn:0372-2112.2009.04.009
    [3] 陈志刚, 梁涤青, 邓小鸿, 等. Logistic混沌映射性能分析与改进[J]. 电子与信息学报, 2016, 38(6): 1547–1551. doi: 10.11999/JEIT151039

    CHEN Zhigang, LIANG Diqing, DENG Xiaohong, et al. Performance analysis and improvement of Logistic chaotic mapping[J]. Journal of Electronics &Information Technology, 2016, 38(6): 1547–1551. doi: 10.11999/JEIT151039
    [4] HUA Zhongyun and ZHOU Yicong. Exponential chaotic model for generating robust chaos[J]. IEEE Transactions on Systems, Man, and Cybernetics:Systems, 2021, 51(6): 3713–3724. doi: 10.1109/TSMC.2019.2932616
    [5] HUA Zhongyun, JIN Fan, XU Binxuan, et al. 2D Logistic-sine-coupling map for image encryption[J]. Signal Processing, 2018, 149: 148–161. doi: 10.1016/j.sigpro.2018.03.010
    [6] 曾祥秋, 叶瑞松. 基于改进Logistic映射的混沌图像加密算法[J]. 计算机工程, 2021, 47(11): 158–165,174. doi: 10.19678/j.issn.1000-3428.0059928

    ZENG Xiangqiu and YE Ruisong. Chaotic image encryption algorithm based on improved Logistic map[J]. Computer Engineering, 2021, 47(11): 158–165,174. doi: 10.19678/j.issn.1000-3428.0059928
    [7] HUA Zhongyun, ZHOU Yicong, and HUANG Hejiao. Cosine-transform-based chaotic system for image encryption[J]. Information Sciences, 2019, 480: 403–419. doi: 10.1016/j.ins.2018.12.048
    [8] 杨吉云, 吴昊. 基于混沌系统和动态DNA编码与运算的彩色图像加密算法[J]. 计算机工程, 2018, 44(2): 151–157. doi: 10.3969/j.issn.1000-3428.2018.02.027

    YANG Jiyun and WU Hao. Color image encryption algorithm based on chaotic system and dynamic DNA coding and operation[J]. Computer Engineering, 2018, 44(2): 151–157. doi: 10.3969/j.issn.1000-3428.2018.02.027
    [9] LIU Zeyu and XIA Tiecheng. Novel two dimensional fractional-order discrete chaotic map and its application to image encryption[J]. Applied Computing and Informatics, 2018, 14(2): 177–185. doi: 10.1016/j.aci.2017.07.002
    [10] SHANNON C E. Communication theory of secrecy systems[J]. The Bell System Technical Journal, 1949, 28(4): 656–715. doi: 10.1002/j.1538-7305.1949.tb00928.x
    [11] 章秀君, 吴志强, 方正. 一种基于四维超混沌系统的数字图像加密算法[J]. 计算机工程, 2013, 39(8): 169–172. doi: 10.3969/j.issn.1000-3428.2013.08.036

    ZHANG Xiujun, WU Zhiqiang, and FANG Zheng. A digital image encryption algorithm based on four-dimensional hyperchaotic system[J]. Computer Engineering, 2013, 39(8): 169–172. doi: 10.3969/j.issn.1000-3428.2013.08.036
    [12] 庄志本, 刘静漪, 李军, 等. 一种基于五维超混沌系统的数字图像加密算法[J]. 湖北民族学院学报:自然科学版, 2019, 37(2): 195–200. doi: 10.13501/j.cnki.42-1569/n.2019.06.016

    ZHUANG Zhiben, LIU Jingyi, LI Jun, et al. A digital image encryption algorithm based on five-dimensional hyperchaotic system[J]. Journal of HuBei Minzu University:Natural Science Edition, 2019, 37(2): 195–200. doi: 10.13501/j.cnki.42-1569/n.2019.06.016
    [13] 刘睿. 基于改进Logistic混沌映射的图像自适应加密算法[J]. 计算机与现代化, 2016(7): 13–17,23. doi: 10.3969/j.issn.1006-2475.2016.07.003

    LIU Rui. Self-adaptive image encryption algorithm based on improved Logistic chaotic map[J]. Computer and Modernization, 2016(7): 13–17,23. doi: 10.3969/j.issn.1006-2475.2016.07.003
    [14] 李楠, 任清华, 苏玉泽. 基于改进型Logistic混沌序列的SPC-TDCS多址接入研究[J]. 空军工程大学学报:自然科学版, 2016, 17(3): 45–50. doi: 10.3969/j.issn.1009-3516.2016.03.009

    LI Nan, REN Qinghua, and SU Yuze. Research on multiple accesses of SPC TDCS based on modified Logistic chaotic sequence[J]. Journal of Air Force Engineering University:Natural Science Edition, 2016, 17(3): 45–50. doi: 10.3969/j.issn.1009-3516.2016.03.009
    [15] XU Lu, LI Zhi, LI Jian, et al. A novel bit-level image encryption algorithm based on chaotic maps[J]. Optics and Lasers in Engineering, 2012, 78: 17–25. doi: 10.1016/j.optlaseng.2015.09.007
    [16] ZHOU Yicong, CAO Weijia, and CHEN C L P. Image encryption using binary bitplane[J]. Signal Processing, 2014, 100: 197–207. doi: 10.1016/j.sigpro.2014.01.020
    [17] 李付鹏, 刘敬彪, 王光义, 等. 基于混沌集的图像加密算法[J]. 电子与信息学报, 2020, 42(4): 981–987. doi: 10.11999/JEIT190344

    LI Fupeng, LIU Jingbiao, WANG Guangyi, et al. An image encryption algorithm based on chaos set[J]. Journal of Electronics &Information Technology, 2020, 42(4): 981–987. doi: 10.11999/JEIT190344
    [18] CHAN C K and CHENG L M. Hiding data in images by simple LSB substitution[J]. Pattern Recognition, 2004, 37(3): 469–474. doi: 10.1016/j.patcog.2003.08.007
    [19] 宫海梅. 图像隐藏算法的MATLAB实现[J]. 智能计算机与应用, 2016, 6(4): 60–62. doi: 10.3969/j.issn.2095-2163.2016.04.018

    GONG Haimei. Realization of image hiding algorithm based on MATLAB[J]. Intelligent Computer and Applications, 2016, 6(4): 60–62. doi: 10.3969/j.issn.2095-2163.2016.04.018
  • 加载中
图(7) / 表(5)
计量
  • 文章访问数:  1228
  • HTML全文浏览量:  667
  • PDF下载量:  212
  • 被引次数: 0
出版历程
  • 收稿日期:  2021-08-02
  • 修回日期:  2021-12-11
  • 录用日期:  2021-12-14
  • 网络出版日期:  2021-12-27
  • 刊出日期:  2022-10-19
