基于改进U型神经网络的脑出血CT图像分割

胡敏; 周秀东; 黄宏程; 张光华; 陶洋

doi:10.11999/JEIT200996

基于改进U型神经网络的脑出血CT图像分割

doi: 10.11999/JEIT200996

胡敏¹,
周秀东¹,
黄宏程^{1, 2, ,},
张光华³,
陶洋^{1, 2}

1.
重庆邮电大学通信与信息工程学院重庆 400065
2.
重庆市通信软件工程技术研究中心重庆 400065
3.
太原学院计算机科学与工程系太原 030000

基金项目: 国家重点研发计划(2019YFB2102001)，山西省回国留学人员科研项目(2020-149)

详细信息

作者简介:
胡敏：女，1971年生，教授，研究方向为数字媒体技术、人机交互理论与技术应用

周秀东：男，1995年生，硕士生，研究方向为智能多媒体信息处理

黄宏程：男，1979年生，副教授，研究方向为人机融合计算智能、智能多媒体信息处理

张光华：男，1986年生，副教授，主要研究方向为量子点微型多光谱成像技术、多光谱图像处理、医学图像处理

陶洋：男，1964年生，教授，研究方向为人工智能、大数据与计算智能

通讯作者:
黄宏程 huanghc@cqupt.edu.cn

中图分类号: TN911.73; TP391.41
计量
- 文章访问数: 1504
- HTML全文浏览量: 1012
- PDF下载量: 230
- 被引次数: 0
出版历程
- 收稿日期: 2020-11-25
- 修回日期: 2021-05-27
- 网络出版日期: 2021-08-16
- 刊出日期: 2022-01-10

Computed-Tomography Image Segmentation of Cerebral Hemorrhage Based on Improved U-shaped Neural Network

1.
School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China
2.
Chongqing Engineering Research Center of Communication Software, Chongqing 400065, China
3.
Department of Computer Science and Engineering, Taiyuan University, Taiyuan 030000, China

Funds: The National Key Research and Development Program of China(2019YFB2102001), The Research Project of Shanxi Scholarship Council of China (2020-149)

摘要

摘要: 针对脑出血CT图像病灶部位的多尺度性导致分割精度较低的问题，该文提出一种基于改进U型神经网络的图像分割模型(AU-Net+)。首先，该模型利用U-Net中的编码器对脑出血CT图像特征编码，将提出的残差八度卷积(ROC)块应用到U型神经网络的跳跃连接部分，使不同层次的特征更好地融合；其次，对融合后的特征，分别引入混合注意力机制，用以提高对目标区域的特征提取能力；最后，通过改进Dice损失函数进一步加强模型对脑出血CT图像中小目标区域的特征学习力度。为验证模型的有效性，在脑出血CT图像数据集上进行实验，同U-Net, Attention U-Net, UNet++以及CE-Net相比，mIoU指标分别提升了20.9%, 3.6%, 7.0%, 3.1%，表明AU-Net+模型具有更好的分割效果。
- 脑出血CT图像分割 /
- 注意力机制 /
- Dice损失函数 /
- 残差八度卷积模块
Abstract: In view of the problem of low segmentation accuracy caused by the multi-scale of the lesion location in Computed-Tomography (CT) images of cerebral hemorrhage, an image segmentation model based on Attention improved U-shaped neural Network plus (AU-Net+) is proposed. Firstly, the model uses the encoder in U-Net to encode the features of the CT image of cerebral hemorrhage, and applies the proposed Residual Octave Convolution (ROC) block to the jump connection part of the U-shaped neural network to make the features of different levels more blend well. Secondly, for the merged features, a hybrid attention mechanism is introduced to improve the feature extraction ability of the target area. Finally, the Dice loss function is improved to enhance further the feature learning of the model for small and medium-sized target regions in CT images of cerebral hemorrhage. To verify the performance of the model, the mIoU index is improved by 20.9%, 3.6%, 7.0%, 3.1% compared with U-Net, Attention U-Net, UNet++ and CE-Net respectively, which indicates that AU-Net+ model has better segmentation effect.
- Segmentation of Computed-Tomography (CT) images of cerebral hemorrhage /
- Attention mechanism /
- Dice loss function /
- Residual Octave Convolution block (ROC) module

HTML全文

图 1 AU-Net+网络框架

下载: 全尺寸图片幻灯片

图 2 混合注意力机制

下载: 全尺寸图片幻灯片

图 3 位置注意力机制

下载: 全尺寸图片幻灯片

图 4 通道注意力机制

下载: 全尺寸图片幻灯片

图 5 八度卷积计算过程

下载: 全尺寸图片幻灯片

图 6 残差八度卷积模块(ROC)

下载: 全尺寸图片幻灯片

图 7 实验流程图

下载: 全尺寸图片幻灯片

图 8 实验预处理效果对比图

下载: 全尺寸图片幻灯片

图 9 典型病例的分割结果

下载: 全尺寸图片幻灯片

图 10 AU-Net+模型训练曲线

下载: 全尺寸图片幻灯片

图 11 分割效果图

下载: 全尺寸图片幻灯片

图 12 实验结果分割效果图

下载: 全尺寸图片幻灯片

图 13 ${y_{{\rm{pred}}}}$的指数对分割的影响

下载: 全尺寸图片幻灯片

表 1 AU-Net+网络结构

编码器-解码器	跳跃连接
conv2d_1 (UConv2D)	up_sampling2d_4 (Conv2DTrans)
max_pooling2d_1 (MaxPooling2D)	concatenate_4 (Concatenate)
conv2d_2 (UConv2D)	roc_1(Roc)
max_pooling2d_2 (MaxPooling2D)	up_sampling2d_5 (Conv2DTrans)
conv2d_3 (UConv2D)	concatenate_5 (Concatenate)
max_pooling2d_3 (MaxPooling2D)	roc_2(Roc)
conv2d_4 (UConv2D)	up_sampling2d_6 (Conv2DTrans)
dropout_1 (Dropout)	add_1 (Add)
up_sampling2d_1 (Conv2DTrans)	att_1(Attention)
concatenate_1 (Concatenate)	up_sampling2d_7 (Conv2DTrans)
conv2d_5 (UConv2D)	concatenate_6 (Concatenate)
up_sampling2d_2 (Conv2DTrans)	roc_3(Roc)
concatenate_2 (Concatenate)	up_sampling2d_8 (Conv2DTrans)
conv2d_6 (UConv2D)	add_2 (Add)
up_sampling2d_3 (Conv2DTrans)	att_2(Attention)
concatenate_3 (Concatenate)	up_sampling2d_9 (Conv2DTrans)
conv2d_7 (UConv2D)	add_3 (Add)
conv2d_8 (EConv2D)	att_3(Attention)

下载: 导出CSV

表 2 分类结果的混淆矩阵

预测值\实际值	正样本	负样本
正样本	${\rm{TP}}$	${\rm{FP}}$
负样本	${\rm{FN}}$	${\rm{TN}}$

下载: 导出CSV

表 3 评价指标的统计结果

评价指标	mIoU	VOE	Recall	DICE	Specificity
均值	0.862	0.021	0.912	0.924	0.987
方差	0.009	0.001	0.004	0.002	0.002
中值	0.901	0.023	0.935	0.953	0.998

下载: 导出CSV

表 4 实验结果对比

方法(参数量)	迭代次数	mIoU	VOE	Recall	DICE	Specificity
U-Net (31377858)	4600	0.653	0.043	0.731	0.706	0.974
Attention U-Net(31901542)	4600	0.826	0.021	0.861	0.905	0.977
U-Net++(36165192)	4800	0.792	0.025	0.833	0.883	0.976
CE-Net (29003094)	4500	0.831	0.022	0.873	0.911	0.981
AU-Net+(37646416)	5000	0.862	0.021	0.912	0.924	0.987

下载: 导出CSV

表 5 混合注意力机制和ROC结构分析指标对比

模型	mIoU	VOE	Recall	DICE	Specificity
Network_1	0.661	0.042	0.735	0.714	0.976
Network_2	0.835	0.025	0.841	0.893	0.974
Network_3	0.781	0.041	0.744	0.723	0.985
Network_4	0.842	0.023	0.862	0.905	0.986
AU-Net+	0.862	0.021	0.912	0.924	0.987

下载: 导出CSV

表 6 实验结果对比

模型	参数量	mIoU	VOE	Recall	DICE	Specificity
Attention U-Net^*	38654416	0.804	0.027	0.853	0.896	0.956
Attention U-Net	31901542	0.826	0.021	0.861	0.905	0.977
AU-Net+	37646416	0.862	0.021	0.912	0.924	0.987

下载: 导出CSV
