基于显著性权重的多曝光融合的单幅雾天图像复原算法

李红云; 施云; 高银

doi:10.11999/JEIT200931

基于显著性权重的多曝光融合的单幅雾天图像复原算法

doi: 10.11999/JEIT200931

李红云¹,
施云¹,
高银^2, ,

1.
泉州职业技术大学晋江 362200
2.
泉州装备制造研究所晋江 362200

基金项目: 国家自然科学基金(62001452)，福建省中青年教师教育科研(JAT191675)，泉州市科技计划 (2020C054, 2019C009R)

详细信息

作者简介:
李红云：女，1982年生，讲师，研究方向为室内定位地图构建和视频图像复原

施云：男，1990年生，讲师，研究方向为图像处理与机器人自适应控制

高银：男，1985年生，高级工程师，研究方向为图像增强、平滑、融合和复原

通讯作者:
高银　yngaoyin@163.com

中图分类号: TN911.73; TP391
计量
- 文章访问数: 956
- HTML全文浏览量: 440
- PDF下载量: 122
- 被引次数: 0
出版历程
- 收稿日期: 2020-10-30
- 修回日期: 2021-04-20
- 网络出版日期: 2021-08-18
- 刊出日期: 2022-01-10

Single Image Dehazing via Saliency Weighted Multi-exposure Fusion

LI Hongyun¹,
SHI Yun¹,
GAO Yin^{2
, ,}

1.
Quanzhou Vocational and Technical University, Jinjiang 362200, China
2.
Quanzhou Institute of Equipment Manufacturing, Jinjiang 362200, China

Funds: The National Natural Science Foundation of China (62001452), The Fujian Province Young band Middle-aged Teacher Education Research Project(JAT191675), The Science and Technology Program of Quanzhou (2020C054, 2019C009R)

摘要

摘要: 传统暗原色理论的相关算法，在处理雾天图像时会产生颜色的畸变和亮度的损失，针对该情况，该文提出基于权重多曝光融合的单幅雾天图像复原算法。首先通过雾天图像的直方图分析，获取全局大气背景光值的区域。其次构造一种新的Kirsh算子的高阶差分滤波方法，优化透射率图像。最后设计一种基于显著性权重的多曝光图像融合方法，提高处理后图像的视觉效果。该文采用自然图像和合成图像进行实验，与多种算法通过主观和客观评价，表明该文算法比现有的算法有更高的复原效果。
- 图像去雾 /
- 自适应边界限制 /
- 高阶差分滤波 /
- 显著性多曝光融合
Abstract: Previous techniques are not sufficient enough to deal with dehazing problems by using various hand-crafted priors and appear image hue and brightness distortion. In this paper, a saliency weighted multi-exposure fusion is proposed for single image dehazing. To produce several images with different exposures, a novel segmentation method is exploited to capture the range of global atmospheric light approximately, and a new Kirsh high-order difference filtering method is employed to optimize the transmission map. A saliency weighted multi-exposure fusion method is constructed to improve the dehazing quality. Extensive experimental results on both subjective and objective evaluation demonstrate that the proposed algorithm performs favorably against the state-of-the-art algorithms.
- Image dehazing /
- Adaptive boundary constraint /
- High order difference filtering /
- Saliency weighted multi-exposure fusion

HTML全文

图 1 算法的流程图

下载: 全尺寸图片幻灯片

图 2 区域分割的对比图

下载: 全尺寸图片幻灯片

图 3 显著性多曝光融合过程

下载: 全尺寸图片幻灯片

图 4 滤波后透射率图像的对比

下载: 全尺寸图片幻灯片

图 5 自然图像去雾对比图

下载: 全尺寸图片幻灯片

图 6 合成图像去雾对比图

下载: 全尺寸图片幻灯片

表 1 自然图像中不同方法的客观评价分析

	工地	寺庙	稻田	原野
I/E	27.16/0.24	24.02/0.12	34.55/0.01	28.74/-0.12
文献[10]	26.16/0.17	20.34/0.07	31.64/0.03	26.85/-0.14
文献[16]	22.71/0.13	17.98/0.11	29.60/0.03	25.44/0.06
文献[28]	23.99/0.13	18.99/0.09	26.02/0.11	26.01/0.02
文献[29]	21.46/0.14	18.46/0.11	27.00/0.33	27.32/0.01
文献[30]	25.96/0.18	18.43/0.11	26.10/0.06	24.87/0.09
文献[31]	26.23/0.16	18.29/0.11	35.14/0.05	32.56/-0.01
本文	21.51/0.24	17.31/0.16	28.93/0.27	25.13/0.25

下载: 导出CSV

表 2 合成图像中不同方法的客观评价分析

	校园	小区	马路	宫殿
P/R	–/–	–/–	–/–	–/–
文献[10]	14.93/0.62	15.30/0.51	12.18/0.46	16.36/0.53
文献[16]	20.79/0.68	16.49/0.53	13.99/0.55	16.58/0.55
文献[28]	15.64/0.61	13.66/0.52	14.49/0.53	18.93/0.55
文献[29]	22.70/0.67	19.82/0.58	13.67/0.53	19.32/0.56
文献[30]	23.44/0.69	16.63/0.53	19.31/0.54	18.84/0.54
文献[31]	19.49/0.55	13.31/0.47	11.57/0.41	14.59/0.47
our	24.04/0.74	22.16/0.64	23.53/0.61	23.02/0.57

下载: 导出CSV

表 3 各种算法的处理时间对比(s)

方法	文献[10]	文献[16]	文献[28]	文献[29]	文献[30]	文献[31]	本文
工地	40.72	5.82	56.36	3.74	16.71	1.64	12.61
寺庙	29.32	5.42	40.06	2.46	12.33	1.54	11.53
稻田	13.54	4.31	22.25	1.52	11.70	1.46	9.58
原野	18.52	4.64	25.72	1.88	12.04	1.43	12.04

下载: 导出CSV
