昆虫雷达散射截面积特性分析

胡程; 方琳琳; 王锐; 周超; 李卫东; 张帆; 郎添娇; 龙腾

doi:10.11999/JEIT190611

昆虫雷达散射截面积特性分析

doi: 10.11999/JEIT190611

1.
北京理工大学雷达技术研究所北京 100081
2.
北京理工大学卫星导航电子信息技术教育部重点实验室北京 100081

基金项目: 国家重大科研仪器研制项目(31727901)

详细信息

作者简介:
胡程：男，1981年生，研究员，博士生导师，研究方向为新体制合成孔径雷达系统与信号处理、生物探测雷达系统与信息处理技术等

方琳琳：女，1993年生，博士生，研究方向为雷达目标检测跟踪算法

王锐：男，1985年生，副教授，博士生导师，研究方向为昆虫雷达信号处理等

周超：男，1987年生，博士后，研究方向为雷达目标检测跟踪算法

李卫东：男，1991年生，博士生，研究方向为昆虫雷达极化信号处理

张帆：男，1996年生，博士生，研究方向为空中生物目标电磁仿真

郎添娇：女，1994年生，硕士生，研究方向为空中生物目标电磁仿真

龙腾：男，1968年生，教授，研究方向为实时信号与信息处理

通讯作者:
王锐　bit.wangrui@gmail.com

中图分类号: TN959.4
计量
- 文章访问数: 3052
- HTML全文浏览量: 1283
- PDF下载量: 146
- 被引次数: 0
出版历程
- 收稿日期: 2019-08-12
- 修回日期: 2019-11-22
- 网络出版日期: 2019-11-30
- 刊出日期: 2020-01-21

Analysis of Insect RCS Characteristics

1.
Radar Research Laboratory, Beijing Institute of Technology, Beijing 100081, China
2.
Key Laboratory of Electronic and Information Technology in Satellite Navigation of Ministry of Education, Beijing Institute of Technology, Beijing 100081, China

Funds: The Special Fund for Research on National Major Research Instruments (31727901)

摘要

摘要:
昆虫雷达是观测昆虫迁飞最有效的工具。研究昆虫的雷达散射截面积(RCS)特性对于昆虫雷达目标识别有着重要意义。该文将分析昆虫的静态RCS特性和动态RCS特性。首先，基于实测的X波段全极化昆虫RCS数据，分析昆虫的静态RCS特性，包括水平和垂直极化RCS随体重变化规律以及昆虫极化方向图随体重的变化规律。其次，总结当前通过电磁仿真研究昆虫RCS特性所用到的介质和几何形状模型，并对比了水、脊髓、干皮肤和壳质与血淋巴混合物4种介质和等体型扁长椭球体、等质量扁长椭球体和三轴椭球体3种几何模型组成的12种介质模型，经过电磁仿真结果与实测数据相对比发现脊髓介质等质量扁长椭球体模型与实测昆虫RCS特性最接近。然后，基于Ku波段高分辨昆虫雷达外场实测昆虫回波数据，分析了昆虫动态RCS的起伏特性，将实测昆虫动态RCS起伏数据与4种经典的RCS起伏分布模型χ², Log-normal, Weibull和Gamma分布分别进行了拟合分析，从最小二乘拟合误差和拟合优度检验结果可以看出，相比于其他3种模型，Gamma分布可以较好地描述昆虫目标RCS起伏的统计特性。最后，综述了昆虫RCS特性在昆虫雷达测量昆虫朝向、体重等参数测量的应用。
- 昆虫雷达 /
- 昆虫雷达散射截面积特性 /
- 电磁仿真 /
- 雷达散射截面积起伏
Abstract:
Insect radar is the most effective tool for insect migration observation. In order to realize target recognition of insect radar, it is important to study the RCS characteristics of insects. This paper will analyze the static and dynamic Radar Cross Section (RCS) characteristics of insects. Firstly, based on the measured X-band fully-polarimetric RCS data, the static RCS characteristics of insects are analyzed, including the variations of horizontal and vertical polarization RCS with body weight respectively, and the variation of insect polarization pattern with body weight. Secondly, the dielectrics and geometric models currently used to study the RCS characteristics of insects are summarized by electromagnetic simulation. Twelve dielectric models consisting of four dielectrics (including water, spinal cord, dry skin, and chitin and hemolymph mixture) and three geometric models (including equivalent size prolate spheroid, equivalent mass prolate spheroid and triaxial prolate spheroid) are compared, and it be found that the RCS characteristics of equivalent mass prolate spheroid are closest to that of the real insects. Then, the fluctuation characteristics of insect dynamic RCS are analyzed based on the insect echo data measured in field by a Ku-band high-resolution insect radar. The measured insect dynamic RCS fluctuation data are fitted with four classical RCS fluctuation distribution models (χ², Log-normal, Weibull and Gamma distribution), respectively. It can be seen from the least square error of fitting and goodness of fit test that Gamma distribution gives the best description of the statistical characteristics of insect RCS fluctuations. Finally, the application of insect RCS characteristics to insect orientation, mass and body length measurements for insect radars is summarized.
- Insect radar /
- Insect Radar Cross Section (RCS) characteristics /
- Electromagnetic simulation /
- RCS fluctuations

HTML全文

图 1 RCS与昆虫体重关系

下载: 全尺寸图片幻灯片

图 2 实测昆虫RCS极化特性

下载: 全尺寸图片幻灯片

图 3 昆虫目标几何模型

下载: 全尺寸图片幻灯片

图 4 不同模型-介质仿真RCS百分比误差

下载: 全尺寸图片幻灯片

图 5 昆虫目标RCS起伏模型研究流程

下载: 全尺寸图片幻灯片

图 6 昆虫RCS起伏

下载: 全尺寸图片幻灯片

图 7 昆虫RCS起伏幅度PDF拟合

下载: 全尺寸图片幻灯片

表 1 实验昆虫样本信息

序号	昆虫名称	体长(mm)	体宽(mm)	体重(mg)
1	未辨识飞蛾1#1	11.1	2.8	25.6
2	未辨识飞蛾1#2	15.0	3.0	35.5
3	枯叶蛾#1	16.7	4.0	72.2
4	枯叶蛾#2	17.9	5.0	105.0
5	小地老虎	19.5	4.9	218.4
6	霜天蛾	34.8	9.1	319.7
7	未辨识飞蛾2	22.9	6.8	400.7
8	甘薯天蛾#1	38.9	9.0	530.1
9	甘薯天蛾#2	40.0	12.4	680.4
10	甘薯天蛾#3	36.8	10.2	935.3

下载: 导出CSV

表 2 介质密度及相对介电常数

介质	密度ρ(g/cm³)	X波段相对介电常数
水	1.000	60.30-33.10j
脊髓	1.038	23.80-10.84j
干皮肤	1.045	31.30-14.41j
壳质与血淋巴混合物	1.260	34.30-18.60j

下载: 导出CSV

表 3 等尺寸椭球体模型质量百分比误差(%)

昆虫序号	水	脊髓	干皮肤	壳质混合物
1	–77.99	–84.75	–86.00	–124.27
2	–99.12	–106.68	–108.08	–150.88
3	–93.78	–101.14	–102.49	–144.16
4	–123.15	–131.63	–133.19	–181.17
5	–12.25	–16.51	–17.30	–41.43
6	–371.97	–389.91	–393.21	–494.69
7	–38.37	–43.63	–44.59	–74.34
8	–211.23	–223.05	–225.23	–292.14
9	–373.30	–391.29	–394.60	–496.36
10	–114.34	–122.48	–123.98	–170.06
平均误差	–151.55	–161.11	–162.87	–216.95

下载: 导出CSV

表 4 等质量椭球体模型体长百分比误差(%)

昆虫序号	水	脊髓	干皮肤	壳质混合物
1	17.48	18.50	18.69	23.60
2	20.51	21.49	21.67	26.41
3	19.79	20.78	20.96	25.74
4	23.48	24.42	24.59	29.15
5	3.78	4.97	5.18	10.91
6	40.38	41.12	41.25	44.80
7	10.26	11.37	11.57	16.91
8	31.51	32.35	32.51	36.59
9	40.44	41.18	41.31	44.86
10	22.44	23.40	23.57	28.19
平均误差	23.01	23.96	24.13	28.72

下载: 导出CSV

表 5 三轴椭球体模型高度百分比误差(%)

昆虫序号	水	脊髓	干皮肤	壳质混合物
1	43.82	45.87	46.23	55.41
2	49.78	51.62	51.94	60.14
3	48.39	50.28	50.62	59.04
4	55.19	56.83	57.12	64.43
5	10.91	14.17	14.75	29.29
6	78.81	79.59	79.72	83.18
7	27.73	30.37	30.84	42.64
8	67.87	69.05	69.25	74.50
9	78.87	79.65	79.78	83.23
10	53.34	55.05	55.35	62.97
平均误差	51.47	53.25	53.56	61.49

下载: 导出CSV

表 6 等质量椭球体模型RCS百分比误差(%)

介质	极化方向平行体轴RCS	极化方向垂直体轴RCS
水	224.3	22.1
脊髓	65.9	19.7
干皮肤	101.2	6.7
壳质与血淋巴混合物	68.8	32.8

下载: 导出CSV

表 7 分布函数表达式

分布函数	表达式	参数
${\chi ^2}$	$p\left( \sigma \right) = \dfrac{m}{ {\varGamma \left( m \right)\bar \sigma } }{\left[ {\dfrac{ {m\sigma } }{ {\bar \sigma } } } \right]^{m - 1} }\exp \left[ {\dfrac{ { - m\sigma } }{ {\bar \sigma } } } \right]$	$\bar \sigma $为平均值，$2m$为自由度
Log-normal	$p\left( \sigma \right) = \dfrac{1}{{\sigma \sqrt {4{\pi }\ln \rho } }}\exp \left\{ {\dfrac{{ - {{\left( {\ln \sigma - {\sigma _0}} \right)}^2}}}{{4\ln \rho }}} \right\}$	${\sigma _0}$为中值，$\rho $为平均中值比
Gamma	$p\left( \sigma \right) = \dfrac{1}{ { {\beta ^\alpha }\varGamma \left( \alpha \right)} }{\sigma ^{\alpha - 1} }\exp \left( { - \dfrac{\sigma }{\beta } } \right)$	$\alpha $是形状参数，$\beta $是尺度参数
Weibull	$p\left( \sigma \right) = \dfrac{b}{a}{\left( {\dfrac{\sigma }{a}} \right)^{b - 1}}\exp \left( { - {{\left( {\dfrac{\sigma }{a}} \right)}^b}} \right)$	$a$是尺度参数，$b$是形状参数

下载: 导出CSV

表 8 昆虫RCS起伏PDF分布拟合误差

昆虫序号	RCS起伏样本点数	Log-normal	${\chi ^2}$	Gamma	Weibull
1	1500	0.0812	0.3870	0.0747	0.0960
2	1250	0.1288	0.5774	0.1204	0.1307
3	1280	0.0724	0.7709	0.0710	0.1102
4	1340	0.0992	0.5652	0.0960	0.1262
5	1460	0.0861	0.3555	0.0765	0.0903
均值		0.0935	0.5312	0.0877	0.1107

下载: 导出CSV

表 9 昆虫RCS起伏PDF分布K-S检验参数D值

昆虫序号	RCS起伏样本点数	Log-normal	χ²	Gamma	Weibull
1	1500	0.0221	0.2141	0.0181	0.0370
2	1250	0.0306	0.2045	0.0169	0.0266
3	1280	0.0195	0.2094	0.0096	0.0342
4	1340	0.0211	0.1831	0.0181	0.0356
5	1460	0.0258	0.1583	0.0145	0.0271
均值		0.0238	0.1939	0.0154	0.0321

下载: 导出CSV
