Performance Analysis of Short Reference Multi-User Differential Chaos Shift Keying Communication System
-
摘要:
短参考差分混沌移位键控(SR-DCSK)系统主要的缺陷是数据传输速率较低。为此，该文提出一种短参考多用户差分混沌移位键控(SR-MUDCSK) 通信方案。利用Walsh码的正交性传输多个用户的信息，有效提高了数据传输速率。在AWGN和多径Rayleigh衰落信道环境下，对其误码性能进行了理论分析，并进行了实验仿真。结果表明：该系统在传输速率方面有较大提升，且能量效率也得到了显著改善，因此其具有重要应用价值。
-
关键词:
- 短参考多用户差分混沌移位键控通信系统 /
- 短参考差分混沌移位键控 /
- Walsh码 /
- 传输速率 /
- 误码率
Abstract:The major drawback of Short Reference Differential Chaos Shift Keying (SR-DCSK) system is the low data transmission rate. To solve the problem, a Short Reference Multi-User Differential Chaos Shift Keying (SR-MUDCSK) communication scheme is proposed. The orthogonality of Walsh code is used to transmit the information of multiple users, which effectively improves the data transmission rate. The theoretical Bit Error Rate (BER) performance is analyzed, and experimental simulation is carried out under AWGN and multipath Rayleigh fading channel environment, respectively. The results show that the system has a significant improvement in transmission rate, and the energy efficiency is also significantly improved. Therefore, it is of great value in application.
-
表 1 几种系统的能量效率和数据传输速率
系统名称 能量效率(${E_\eta }$) 传输速率(${R_{\rm{B}}}$) DCSK ${1 / 2}$ ${1 / {2\beta }}$ SR-DCSK ${P / {(1 + P)}}$ ${1 / {(R + PR)}}$ SR-MUDCSK ${{PN} / {(1 + PN)}}$ ${N / {(R + PR)}}$
下载: 导出CSV
-
张刚, 孟维, 张天骐. 多用户分段移位差分混沌键控通信方案[J]. 电子与信息学报, 2017, 39(5): 1219–1225. doi: 10.11999/JEIT160795ZHANG Gang, MENG Wei, and ZHANG Tianqi. Multiuser communication scheme based on segment shift differential chaos shift keying[J]. Journal of Electronics &Information Technology, 2017, 39(5): 1219–1225. doi: 10.11999/JEIT160795 禹思敏, 吕金虎, 李澄清. 混沌密码及其在多媒体保密通信中应用的进展[J]. 电子与信息学报, 2016, 38(3): 735–752. doi: 10.11999/JEIT151356YU Simin, LÜ Jinhu, and LI Chengqing. Some progresses of chaotic cipher and its applications in multimedia secure communications[J]. Journal of Electronics &Information Technology, 2016, 38(3): 735–752. doi: 10.11999/JEIT151356 张刚, 许嘉平, 张天骐. 基于希尔伯特变换的多用户DCSK通信系统性能分析[J]. 电子与信息学报, 2018, 40(11): 2744–2751. doi: 10.11999/JEIT180110ZHANG Gang, XU Jiaping, and ZHANG Tianqi. Performance analyze for multiuser-DCSK communication system based on Hilbert transform[J]. Journal of Electronics &Information Technology, 2018, 40(11): 2744–2751. doi: 10.11999/JEIT180110 HU Wei, WANG Lin, and KADDOUM G. Design and performance analysis of a differentially spatial modulated chaos shift keying modulation system[J]. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2017, 64(11): 1302–1306. doi: 10.1109/TCSⅡ.2017.2697456 ESCRIBANO F J, KADDOUM G, WAGEMAKERS A, et al. Design of a new differential chaos-shift-keying system for continuous mobility[J]. IEEE Transactions on Communications, 2016, 64(5): 2066–2078. doi: 10.1109/TCOMM.2016.2538236 KADDOUM G, TRAN H V, LONG K, et al. Design of simultaneous wireless information and power transfer scheme for short reference DCSK communication systems[J]. IEEE Transactions on Communications, 2017, 65(1): 431–443. doi: 10.1109/TCOMM.2016.2619707 KADDOUM G and GAGNON F. Design of a high-data-rate differential chaos-shift keying system[J]. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2012, 59(7): 448–452. doi: 10.1109/TCSⅡ.2012.2198982 YANG Hua and JIANG Guoping. High-efficiency differential-chaos-shift-keying scheme for chaos-based noncoherent communication[J]. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2012, 59(5): 312–316. doi: 10.1109/TCSⅡ.2012.2190859 KADDOUM G and SOUJERI E. NR-DCSK: A noise reduction differential chaos shift keying system[J]. IEEE Transactions on Circuits and Systems Ⅱ: Express Briefs, 2016, 63(7): 648–652. doi: 10.1109/TCSⅡ.2016.2532041 YANG Hua and JIANG Guoping. Reference-Modulated DCSK: A novel chaotic communication scheme[J]. IEEE Transactions on Circuits & Systems Ⅱ Express Briefs, 2013, 60(4): 232–236. doi: 10.1109/TCSⅡ.2013.2251949 张刚, 孟维, 张天骐. 基于FDM的多进制多用户DCSK[J]. 系统工程与电子技术, 2017, 39(1): 183–187. doi: 10.3969/j.issn.1001-506X.2017.01.27ZHANG Gang, MENG Wei, and ZHANG Tianqi. Multiple ary multiple user DCSK based on FDM[J]. Systems Engineering and Electronics, 2017, 39(1): 183–187. doi: 10.3969/j.issn.1001-506X.2017.01.27 YANG Hua, TANG W K S, CHEN Guanrong, et al. System design and performance analysis of orthogonal multi-level differential chaos shift keying modulation scheme[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2016, 63(1): 146–156. doi: 10.1109/TCSI.2015.2510622 KADDOUM G, SOUJERI E, and NIJSURE Y. Design of a short reference noncoherent chaos-based communication systems[J]. IEEE Transactions on Communications, 2016, 64(2): 680–689. doi: 10.1109/TCOMM.2015.2514089 张刚, 郝怡曼, 张天骐. 短参倍速差分混沌键控系统[J]. 系统工程与电子技术, 2018, 40(1): 184–190. doi: 10.3969/j.issn.1001-506X.2018.01.27ZHANG Gang, HAO Yiman, and ZHANG Tianqi. Short reference multifold rate differential chaos shift keying[J]. Systems Engineering and Electronics, 2018, 40(1): 184–190. doi: 10.3969/j.issn.1001-506X.2018.01.27 HASAN F S. Design and analysis of an OFDM-based short reference quadrature chaos shift keying communication system[J]. Wireless Personal Communications, 2017, 96(2): 2205–2222. doi: 10.1007/s11277-017-4293-1 KADDOUM G, CHARGÉ P, ROVIRAS D, et al. A methodology for bit error rate prediction in chaos-based communication systems[J]. Circuits, Systems and Signal Processing, 2009, 28(6): 925–944. doi: 10.1007/s00034-009-9124-5 MANDAL S and BANERJEE S. Analysis and CMOS implementation of a chaos-based communication system[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2004, 51(9): 1708–1722. doi: 10.1109/TCSI.2004.834482 -
图(9) / 表(1)
