A Novel Design Algorithm for Low Complexity Sparse FIR Notch Filters
-
摘要:
FIR陷波滤波器具有线性相位、精度高、稳定性好等诸多优势，然而当陷波性能要求较高时，通常需要较高的阶数，导致FIR陷波滤波器硬件实现复杂度大大提高。该文基于稀疏FIR滤波器设计算法和共同子式消除的思想，提出一种低复杂度的FIR陷波滤波器设计方法。该方法首先采用稀疏滤波器设计算法得到满足频域性能设计要求的FIR陷波原始滤波器系数，然后对其进行CSD编码，并分析CSD编码量化系数集中所有的2项子式和孤子的灵敏度，最后根据灵敏度的大小依次选择合理的2项子式或孤子直接合成滤波器系数集。仿真结果表明，新算法设计实现的FIR陷波滤波器比已有的低复杂度设计方法最多可减少51%的加法器，有效地降低了硬件实现复杂度，大大节省了硬件资源。
Abstract:FIR notch filter has many advantages such as linear phase, high precision and good stability. However, when the notch performance is required to be high, a higher order is usually required, resulting in increased greatly hardware complexity of the FIR notch filter. Based on sparse FIR filter design algorithm and common subexpression elimination, a novel algorithm is proposed for the design of low complexity sparse FIR notch filter. First, a sparse FIR notch benchmark filter that fulfills frequency response specifications is obtained from the sparse filter design algorithm. Then, each quantized filter coefficient is represented in Canonical Signed Digit (CSD). The sensitivities of all weight-two subexpressions and isolated nonzero digits of the quantized coefficient set are analyzed. Finally, the filter coefficient set with lower implementation cost is constructed by iteratively admitting subexpressions and isolated nonzero digits according to their sensitivities. Simulation results show that the proposed algorithm can save about 51% of adder compared with other low complexity filter design algorithms, which reduces effectively the implementation complexity and saves greatly the hardware cost.
-
Key words:
- FIR notch filter /
- Common subexpression elimination /
- Sparse filter design
-
MEIDANI M and MASHOUFI B. Introducing new algorithms for realising an FIR filter with less hardware in order to eliminate power line interference from the ECG signal[J]. IET Signal Processing, 2016, 10(7): 709–716 doi: 10.1049/iet-spr.2015.0552 SZADKOWSKI Z and GLAS D. The least mean squares adaptive FIR filter for narrow-band RFI suppression in radio detection of cosmic rays[J]. IEEE Transactions on Nuclear Science, 2017, 64(6): 1304–1315 doi: 10.1109/TNS.2017.2703617 MEHRNIA A and WILLSON A N. A lower bound for the hardware complexity of FIR filters[J]. IEEE Circuits and Systems Magazine, 2018, 18(1): 10–28 doi: 10.1109/MCAS.2017.2785422 GU Chao, ZHAO Jiaxiang, XU Wei, et al. Design of linear-phase notch filters based on the OMP scheme and the chebyshev window[J]. IEEE Transactions on Circuits and Systems-II: Express Briefs, 2012, 59(9): 592–596 doi: 10.1109/TCSII.2012.2206931 XU Wei, ZHAO Jiaxiang, and GU Chao. Design of linear-phase FIR multiple-notch filters via an iterative reweighted OMP scheme[J]. IEEE Transactions on Circuits and Systems-II: Express Briefs, 2014, 61(10): 813–817 doi: 10.1109/TCSII.2014.2345299 JIANG Aimin, KWAN H K, ZHU Yanping, et al. Design of sparse FIR filters with joint optimization of sparsity and filter order[J]. IEEE Transactions on Circuits and Systems-I: Regular Papers, 2015, 62(1): 195–204 doi: 10.1109/TCSI.2014.2354771 JIANG Aimin, KWAN H K, and ZHU Yanping. Peak-error-constrained sparse FIR filter design using iterative L1 optimization[J]. IEEE Transactions on Signal Processing, 2012, 60(8): 4035–4044 doi: 10.1109/TSP.2012.2199316 DAM H H, CANTONI A, TEO K L, et al. FIR variable digital filter with signed power-of-two coefficients[J]. IEEE Transactions on Circuits and Systems-I: Regular Papers, 2007, 54(6): 1348–1357 doi: 10.1109/TCSI.2007.897775 CHOUDHARY S, MUKHERJEE P, CHAKRABORTY M, et al. A SPT treatment to the realization of the sign-LMS based adaptive filters[J]. IEEE Transactions on Circuits and Systems-I: Regular Papers, 2012, 59(9): 2025–2033 doi: 10.1109/TCSI.2012.2185300 YE Jinghao, SHI Youhua, TOGAWA N, et al. A low cost and high speed CSD-based symmetric transpose block FIR implementation[C]. IEEE 12th International Conference on ASIC, Guiyang, China, 2017: 311–314. FENG Feng, CHEN Jiajia, and CHANG C H. Hypergraph based minimum arborescence algorithm for the optimization and reoptimization of multiple constant multiplications[J]. IEEE Transactions on Circuits and Systems-I: Regular Papers, 2016, 63(2): 233–244 doi: 10.1109/TCSI.2015.2512742 DING Jiatao, CHEN Jiajia, and CHANG C H. A new paradigm of common subexpression elimination by unification of addition and subtraction[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2016, 35(10): 1605–1617 doi: 10.1109/TCAD.2016.2527700 LIU Hui and JIANG Aimin. Efficient design of FIR filters using common subexpression elimination[C]. International Conference on Wireless Communications & Signal Processing, Yangzhou, China, 2016: 1–5. TRIMALE M B and CHILVERI. A review: FIR filter implementation[C]. 2017 2nd IEEE International Conference on Recent Trends in Electronics, Information & Communication Technology, Bangalore, India, 2017: 137–141. CHEN Jiajia, TAN Jinghong, CHANG C H, et al. A new cost-aware sensitivity-driven algorithm for the design of FIR filters[J]. IEEE Transactions on Circuits and Systems-I: Regular Papers, 2017, 64(6): 1588–1598 doi: 10.1109/TCSI.2016.2557840 MARTINEZ-PEIRO M, BOEMO E I, and WANHAMMAR L. Design of high-speed multiplierless filters using a nonrecursive signed common subexpression algorithm[J]. IEEE Transactions on Circuits and Systems-II: Analog and Digital Signal Processing, 2002, 49(3): 196–203 doi: 10.1109/TCSII.2002.1013866 -
