导数法峰值锐化算法提高磁感应成像图像分辨率

罗海军; 廖勇; 潘海涛; 温开旭

doi:10.11999/JEIT171102

导数法峰值锐化算法提高磁感应成像图像分辨率

doi: 10.11999/JEIT171102

罗海军^{*廖勇潘海涛温开旭},
廖勇,
潘海涛,
温开旭

基金项目:

国家自然科学基金(51507023)，重庆市科委基础和前沿研究项目(CSTC2016JCYJA0920)，重庆市教委科学技术研究项目( KJ1703063)

计量
- 文章访问数: 1639
- HTML全文浏览量: 408
- PDF下载量: 103
- 被引次数: 0
出版历程
- 收稿日期: 2017-11-24
- 修回日期: 2018-04-16
- 刊出日期: 2018-08-19

Derivative Method Peak Sharpening Algorithm Improves Image Resolution of Magnetic Induction Tomography

LUO Haijun^{*廖勇潘海涛温开旭},
LIAO Yong,
PAN Haitao,
WEN Kaixu

Funds:

The National Natural Science Foundation of China (51507023), The Chongqing Research Program of Basic Research and Frontier Technology (CSTC2016JCYJA0920), The Scientific and Technological Research Program of Chongqing Municipal Education Commission (KJ1703063)

摘要

摘要: 磁感应成像(MIT)是一种利用电磁感应原理重构生物组织电导率分布的非接触式电阻抗成像技术。该文利用亥姆霍兹线圈和20个检测线圈搭建了旋转式磁感应成像系统，利用滤波反投影算法重构图像。分别利用2阶和4阶导数法峰值锐化算法处理单目标和双目标检测线圈的测量数据，通过3个客观参数对比处理前后的重构图像结果。结果证明磁感应成像中导数法峰值锐化能够有效地增加图像质量。
- 磁感应成像 /
- 滤波反投影算法 /
- 图像重建 /
- 峰值锐化
Abstract: Magnetic Induction Tomography (MIT) is a contactless Electrical Impedance Tomography (EIT) technique to reconstruct the conductivity distribution of biological tissue using the principle of electromagnetic induction. In this paper, a rotating magnetic induction imaging system is constructed by using Helmholtz coil and 20 detection coils, with filtered back projection algorithm. The single target and double target detection coil measurement data are processed by the two order and four order derivative peak sharpening algorithm. The measurement data before and after processing of the reconstructed image are compared by three objective parameters. The results show that the magnetic induction imaging derivative method can effectively increase the peak sharpening image quality.
- Magnetic Induction Tomography (MIT) /
- Filtered back projection algorithm /
- Image reconstruction /
- Peak sharpening

HTML全文

参考文献(18)

DIJKSTRA A M, BROWN B H, LEATHARD A D, et al. Clinical applications of electrical impedance tomography[J]. Journal of Medical Engineering Technology, 1993, 17(3): 89-98. doi: 10.3109/03091909309016213.

DJAJAPUTRA D. Electrical impedance tomography: Methods, history and applications[J]. Medical Physics, 2005, 32(8): 2730-2731. doi: 10.1118/1.1995712.

GRIFFITHS H, STEWART W R, and GOUGH W. Magnetic induction tomography: A measuring system for biological tissues[J]. Annals of the New York Academy of Sciences, 1999, 873(1): 335-345. doi: 10.1111/j.1749-6632.1999.tb09481.x.

GRIFFITHS H. Magnetic induction tomography[J]. Measurement Science and Technology, 2001, 12(8): 1126-1131. doi: 10.1088/0957-0233/12/8/319.

宣杨, 王旭, 刘承安, 等. 不完全乔列斯基分解共轭梯度法在磁感应成像三维有限元正问题中的应用[J]. 电子与信息学报, 2016, 38(1): 187-194. doi: 10.11999/JEIT150437. XUAN Yang, WANG Xu, LIU Chengan, et al. Incomplete cholesky conjugate gradient method for the three- dimensional forward problem in magnetic induction tomography using finite element method[J]. Journal of Electronics Information Technology, 2016, 38(1): 187-194. doi: 10.11999/JEIT150437.

刘润生, 董秀珍, 刘锐岗. 线性卡尔曼滤波算法在磁感应断层成像技术中的仿真研究[J]. 医疗卫生装备, 2016, 37(1): 1-4. doi: 10.7687/J.ISSN1003-8868.2016.01.001. LIU Runsheng, DONG Xiuzhen, and LIU Ruigang. Simulation study of linear Kalman filtering algorithm in magnetic induction tomography[J]. Chinese Medical Equipment Journal, 2016, 37(1): 1-4. doi: 10.7687/J. ISSN1003-8868.2016.01.001.

MARMUGI L and RENZONI F. Optical magnetic induction tomography of the heart[J]. Scientific Reports, 2016, 6: 23962. doi: 10.1038/srep23962.

YAN Qingguang, JIN Gui, QIN Mingxin, et al. Experimental study on the detection of rabbit intracranial hemorrhage using four coil structures based on magnetic induction phase shift[J]. Biomedizinische Technik Biomedical Engineering, 2017, 62(1): 1-14. doi: 10.1515/bmt-2015-0129.

LUO Haijun, HE Wei, XU Zheng, et al. Preliminary results on brain monitoring of meningitis using 16 channels magnetic nduction tomography measurement system[J]. Progress in Electromagnetics Research M, 2012, 24(3): 57-68. doi: 10.2528/PIERM12021406.

GENCER N G, KUZUOGLU M, and IDER Y Z. Electrical impedance tomography using induced currents[J]. IEEE Transactions on Medical Imaging, 1994, 13(2): 338-350. doi: 10.1109/42.293927.

罗海军, 何为, 徐征, 等. 基于同步检波的单通道磁感应成像技术研究[J]. 仪器仪表学报, 2012, 33(4): 899-904. doi: 10.3969/j.issn.0254-3087.2012.04.027. LUO Haijun, HE Wei, XU Zheng, et al. Study on single channel magnetic induction tomography technique based on synchronous detection[J]. Chinese Journal of Scientific Instrument, 2012, 33(4): 899-904. doi: 10.3969/j.issn.0254- 3087.2012.04.027.

MA Lu and SOLEIMANI M. Magnetic induction tomography methods and applications: A review[J]. Measurement Science and Technology, 2017, 28(7): 072001. doi: 10.1088/1361-6501/aa7107.

吕轶, 王旭, 杨丹, 等. 一种磁感应成像中生物组织涡流信号的新型测量方法[J]. 电子与信息学报, 2011, 33(9): 2258-2262. doi: 10.3724/SP.J.1146.2010.01422. L Yi, WANG Xu, YANG Dan, et al. A new measurement method of eddy current for biological tissue in magnetic induction tomography[J]. Journal of Electronics Information Technology, 2011, 33(9): 2258-2262. doi: 10.3724/SP.J.1146.2010.01422.

SOLEIMANI M and LIONHEAT W R B. Absolute conductivity reconstruction in magnetic induction tomography using a nonlinear method[J]. IEEE Transactions on Medical Imaging, 2006, 25(12): 1521-1530. doi: 10.1109/ TMI.2006.884196.

王聪, 刘锐岗, 李烨, 等. 一种用于磁感应断层成像的图像重建算法[J]. 仪器仪表学报, 2008, 29(10): 2052-2057. doi: 10.3321/j.issn:0254-3087.2008.10.007. WANG Cong, LIU Ruigang, LI Ye, et al. Image reconstruction algorithm for magnetic induction tomography [J]. Chinese Journal of Scientific Instrument, 2008, 29(10): 2052-2057. doi: 10.3321/j.issn:0254-3087.2008.10.007.

THOMAS C O. A pragmatic introduction to signal processing: With applications in scientific measurement[OL]. https://terpconnect.umd.edu/~toh/spectrum/ResolutionEnhancement.html, 2015.

柯丽, 刘欢, 杜强, 等. 基于滤波反投影的脑磁感应迭代重建算法研究[J]. 仪器仪表学报, 2016, 31(11): 2445-2451. doi: 10.3969/j.issn.0254-3087.2016.11.005. KE Li, LIU Huan, DU Qiang, et al. Study on iterative reconstruction algorithm for brain magnetic induction based on filtered back-projection[J]. Chinese Journal of Scientific Instrument, 2016, 31(11): 2445-2451. doi: 10.3969/j.issn. 0254-3087.2016.11.005.

李冰, 何为, 何传红, 等. 三维电阻抗成像系统激励模式仿真分析[J]. 重庆大学学报, 2012, 35(2): 78-86. doi: 10.11835/ j.issn.1000-582X.2012.02.013. LI Bing, HE Wei, HE Chuanhong, et al. Simulation analysis on stimulation patterns of three-dimension electrical imped- ance tomography[J]. Journal of Chongqing University, 2012, 35(2): 78-86. doi: 10.11835/j.issn.1000-582X.2012.02.013.
