一种宽带大斜视STOLT插值及距离变标补偿方法

王金波; 唐劲松; 张森; 钟和平

doi:10.11999/JEIT171068

一种宽带大斜视STOLT插值及距离变标补偿方法

doi: 10.11999/JEIT171068

^①(海军工程大学电子工程学院武汉 430033) ^②(海军工程大学海军水声技术研究所武汉 430033)

基金项目:

国家自然科学基金(61671461, 41304015)

详细信息

作者简介:
王金波：男，1979年生，讲师，博士，研究方向为合成孔径声呐信号处理. 唐劲松：男，1964年生，教授，博士生导师，研究方向为干涉合成孔径声呐、水声通信技术. 张森：男，1982年生，副研究员，硕士生导师，研究方向为干涉合成孔径声呐和水声定位. 钟和平：男，1983年生，助理研究员，研究方向为干涉合成孔径声呐信号处理和并行计算.

中图分类号: U666.7; TN911.7
计量
- 文章访问数: 1437
- HTML全文浏览量: 207
- PDF下载量: 124
- 被引次数: 0
出版历程
- 收稿日期: 2017-11-16
- 修回日期: 2018-04-09
- 刊出日期: 2018-07-19

Range Scaling Compensation Method Based on STOLT Interpolation in Broadband Squint SAS Imaging

WANG Jinbo^① TANG Jinsong^② ZHANG Sen^② ZHONG Heping^②

Funds:

The National Natural Science Foundation of China (61671461, 41304015)

摘要

摘要: 针对大斜视合成孔径声呐成像问题，该文推导了宽带大斜视条件下合成孔径声呐回波在径向和方位向2维波数域中的波数谱的解析表达式，指出了Stolt插值需要解决的距离波数谱卷绕以及成像后距离向上目标的相对距离缩小等问题，给出了距离波数谱卷绕时的Stolt插值方法，提出了距离波数变标因子的概念，并通过在距离空域中补偿距离波数变标因子引起的距离变标的方法，解决了大斜视角条件下Stolt插值引起的距离变标问题。点目标仿真数据和模拟回波数据处理验证了该文方法的正确性和有效性。
- 合成孔径声呐成像 /
- 宽带 /
- 斜视 /
- 算法 /
- 距离波数变标因子
Abstract: Considering the problem of large squint synthetic aperture sonar imaging, the analytical expression of the wavenumber spectrum is analyzed in detail in the radial and azimuth wavenumber fields under the wide-band high-squint conditions. The spectrum winding and shrink in the distance wavenumber fields after the Stolt interpolation are pointed out, and the reduced relative distance between the target in the imaging result is also indicated, then the Stolt interpolation method for distance wavenumber spectrum winding is given. The concept of range wavenumber scaling factor is proposed, the method of compensating the scaling factor and the spectrum winding in the distance space are given. Finally, the problem of range scaling caused by Stolt interpolation under large oblique angle is solved by compensating the distance variable in distance space. Point object simulation data and simulated echo data processing verify the correctness and validity of the proposed method.
- Synthetic Aperture Sonar (SAS) imaging、Broadband、Squint、algorithm、Range wavenumber scaling factor /

HTML全文

参考文献(16)

[2] CHEN C, ZARE A, and COBB J T. Sand ripple characterization using an extended synthetic aperture sonar model and parallel sampling method[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(10): 5547-5559. doi: 10.1109/TGRS.2015.2424837.

CARBALLINI J and VIANA F. Using synthetic aperture sonar as an effective tool for pipeline inspection survey projects[C]. IEEE/OES Acoustics in Underwater Geosciences Symposium (RIO Acoustics), Rio de Janeiro, Brazil, 2015: 1-5.

[3] HANSEN R E, CALLOW H J, SABO T O, et al. Challenges in seafloor imaging and mapping with synthetic aperture sonar[J]. IEEE Transactions on Geoscience and Remote Sensing, 2011, 49(10): 3677-3687. doi: 10.1109/TGRS.2011. 2155071.

[4] HANSEN R E, LYONS A P, TORSTEIN O S, et al. The effect of internal wave-related features on synthetic aperture sonar[J]. IEEE Journal of Oceanic Engineering, 2015, 40(3): 621-631. doi: 10.1109/JOE.2014.2340351.

[6] LARSEN L J, HYDROSPHERIC S, WILBY A, et al. Deep ocean survey and search using synthetic aperture sonar[C]. MTS/IEEE Oceans Conference, Seattle, USA, 2010: 1-4.

[7] TIAN Zhen, TANG Jinsong, ZHONG Heping, et al. Extended range Doppler algorithm for multiple-receiver synthetic aperture sonar based on exact analytical two-dimensional spectrum[J]. IEEE Journal of Oceanic Engineering, 2016, 41(1): 164-174. doi: 10.1109/JOE.2015. 2402053.

[8] SAWA T, KASAYA T, NAKATSUKA K, et al. Improvement of synthetic aperture sonar with multi-channel projector[C]. MTS/IEEE OCEANS,15, Washington, USA, 2015: 1-6.

[9] QIAO Ziliang and KRAUS D. Azimuth ambiguity in redundant sampled stripmap SAS imaging[C]. MTS/IEEE OCEANS,16, Shanghai, China, 2016: 1-5. doi: 10.3873/ j.izzn.1000-1328.2016.01.015.

LI Jianbing, ZHANG Shuangxi, SU Daliang, et al. A squint SAR imaging for linear range cell migration correction in Doppler domain[J]. Journal of Astronautics, 2016, 37(1): 118-126. doi: 10.383873/j.issn.1000-1328.2016.01.015.

HOU Yuxing. Study on HRWS SAR imaging and the algorithm performance improvement[D]. [Ph.D. dissertation], Xidian University, 2015: 31-33.

[12] STOLT R H. Migration by fourier transform[J]. Geophysics, 1978, 43(1): 23-48.

[13] TOLMAN M A and LONG D G. New results on the Omega-k algorithm for processing synthetic aperture radar data[C]. 2011 IEEE Radar Conference (RADAR), Kansas City, USA, 2011: 868-873. doi: 10.1109/RADAR.2011.5960661.

[14] CUMMING I G and WONG F H. Digital Signal Processing of Synthetic Aperture Radar Data: Algorithms and Implementation[M]. London: Artech House, 2004: 119-226.

[15] CALLOW H J, HAYES M P, and Gough P T. Wavenumber domain reconstruction of SAR/SAS imagery using single transmitter and multiple-receiver geometry[J]. Electronics Letters, 2002, 38(7): 336-338. doi: 10.1049/el:20020219.

[16] CAFFORIO C, PRATI C, and ROCCA F. SAR data focusing using seismic migration techniques[J]. IEEE Transactions on Aerospace and Electronic Systems, 1991, 27(2): 194-207. doi: 10.1109/7.78293.

XING Mengdao, BAO Zheng, LI Zhenfang, et al. Progress of Radar Imaging Algorithm[M]. Beijing: Publishing House of Electronics Industry, 2014: 27-40.
