3D MIMO在无线携能通信系统中的应用和优化设计

范立行; 华梦; 黄永明; 杨绿溪

doi:10.11999/JEIT170751

3D MIMO在无线携能通信系统中的应用和优化设计

doi: 10.11999/JEIT170751

基金项目:

国家自然科学基金(61372101, 61422105)，国家863重大项目(2015AA01A703)，江苏省科技计划项目(BE2015156)

计量
- 文章访问数: 969
- HTML全文浏览量: 131
- PDF下载量: 183
- 被引次数: 0
出版历程
- 收稿日期: 2017-07-25
- 修回日期: 2017-12-15
- 刊出日期: 2018-05-19

Application and Optimal Design of 3D MIMO for Simultaneous Wireless Information and Power Transfer

Funds:

The National Natural Science Foundation of China (61372101, 61422105), The National 863 Project of China (2015AA01A703), The Research Project of Jiangsu Province (BE2015156)

摘要

摘要: 为了提高无线携能通信(SWIPT)的效率，在基站采用3维(3D)定向天线，通过动态调整天线下倾角，来开发垂直维度，从而增强SWIPT中能量和信息的传输效率。该文研究单小区多输入多输出(MIMO)SWIPT系统，基站和用户分别使用迫零(ZF)预编码和功率划分(PS)技术。构建以最小化发送功率为目标的优化问题，在信噪比(SNR)和获取功率的约束下，联合优化了天线下倾角，PS比和分配的功率。最佳PS比和最优功率分配以闭合表达式给出。仿真表明，所得到的优化解的性能优于具有可调下倾角的常规MIMO系统和不考虑垂直维度的2维(2D)方案。
- 无线携能通信 /
- 3D MIMO /
- 基站天线下倾角 /
- 功率划分
Abstract: In order to improve the Simultaneous Wireless Information and Power Transfer (SWIPT) efficiency, the Base Station (BS) employs the Three-Dimensional (3D) directional antennas and exploits the vertical domain by dynamically adjusting the antenna tilt. So the efficiency of energy and information transfer can be increased. The single-cell Multiple-Input Multiple-Output (MIMO) SWIPT system is studied where the BS applies Zero-Forcing (ZF) precoding and users use the Power Splitting (PS) technique. The optimization problem is formulated to minimize the transmit power subject to SNR and harvested power targets. And the antenna tilt, PS ratios and the allocated power of each user are jointly optimized. The optimal PS ratios and the optimal power allocation are given in closed-form expressions. Simulations show that the proposal outperforms conventional MIMO systems with an adjustable tilt and the Two-Dimensional (2D) scheme without considering the vertical domain.
- Simultaneous Wireless Information and Power Transfer (SWIPT) /
- 3D MIMO /
- Base Station (BS) antenna tilt /
- Power splitting

HTML全文

参考文献(17)

VARSHNEY L R. Transporting information and energy simultaneously[C]. IEEE International Symposium on Information Theory, ISIT, Toronto, ON, Canada, 2008: 1612-1616. doi: 10.1109/ISIT.2008.4595260.

KRIKIDIS I, TIMOTHEOU S, NIKOLAOU S, et al. Simultaneous wireless information and power transfer in modern communication systems[J]. IEEE Communications Magazine, 2014, 52(11): 104-110. doi: 10.1109/MCOM.2014. 6957150.

ZHANG R and HO C K. MIMO broadcasting for simultaneous wireless information and power transfer[J]. IEEE Transactions on Wireless Communications, 2013, 12(5): 1989-2001. doi: 10.1109/TWC.2013.031813.120224.

SHI Q, LIU L, XU W, et al. Joint transmit beamforming and receive power splitting for MISO SWIPT systems[J]. IEEE Transactions on Wireless Communications, 2014, 13(6): 3269-3280. doi: 10.1109/TWC.2014.041714.131688.

SHI Q, PENG C, XU W, et al. Energy efficiency optimization for MISO SWIPT systems with zero-forcing beamforming[J]. IEEE Transactions on Signal Processing, 2016, 64(4): 842-854. doi: 10.1109/TSP.2015.2489603.

SHENG M, WANG L, WANG X, et al. Energy efficient beamforming in MISO heterogeneous cellular networks with wireless information and power transfer[J]. IEEE Journal on Selected Areas in Communications, 2016, 34(4): 954-968. doi: 10.1109/JSAC.2016.2544538.

LI Q, ZHANG Q, and QIN J. Secure relay beamforming for SWIPT in amplify-and-forward two-way relay networks[J]. IEEE Transactions on Vehicular Technology, 2016, 65(11): 9006-9019. doi: 10.1109/TVT.2016.2519339.

LI Q, ZHANG Q, and QIN J. Beamforming for information and energy cooperation in cognitive non-regenerative two-way relay networks[J]. IEEE Transactions on Wireless Communications, 2016, 15(8): 5302-5313. doi: 10.1109/TWC. 2016.2555913.

NAM Y H, Ng B L, SAYANA K, et al. Full-dimension MIMO (FD-MIMO) for next generation cellular technology[J]. IEEE Communications Magazine, 2013, 51(6): 172-179. doi: 10.1109/MCOM.2013.6525612.

KRIKIDIS I. SWIPT in 3-D bipolar ad hoc networks with sectorized antennas[J]. IEEE Communications Letters, 2016, 20(6): 1267-1270. doi: 10.1109/LCOMM.2016.2557319.

SEIFI N, ZHANG J, HEATH R W, et al. Coordinated 3D beamforming for interference management in cellular networks[J]. IEEE Transactions on Wireless Communications, 2014, 13(10): 5396-5410. doi: 10.1109/ TWC.2014.2349981.

KOPPENBORG J, HALBAUER H, SAUR S, et al. 3D beamforming trials with an active antenna array[C]. 2012 International ITG Workshop on Smart Antennas (WSA), Dresden, Germany, 2012: 110-114. doi: 10.1109/WSA.2012. 6181190.

3GPP. TR 36.814-Further advancements for E-UTRA physical layer aspects[S]. 2010.

SEIFI N, HEATH R W, COLDREY M, et al. Adaptive multicell 3-D beamforming in multiantenna cellular networks [J]. IEEE Transactions on Vehicular Technology, 2016, 65(8): 6217-6231. doi: 10.1109/TVT.2015.2478843.

LI P, PAUL D, NARASIMHAN R, et al. On the distribution of SINR for the MMSE MIMO receiver and performance analysis[J]. IEEE Transactions on Information Theory, 2006, 52(1): 271-286. doi: 10.1109/TIT.2005.860466.

BOYD S and VANDENBERGHE L. Convex Optimization [M]. New York: Cambridge University Press, 2004: 243-244.

LEE W, LEE S R, KONG H B, et al. Downlink vertical beamforming designs for active antenna systems[J]. IEEE Transactions on Communications, 2014, 62(6): 1897-1907. doi: 10.1109/TCOMM.2014.2320727.
