三维空间中高超声速目标修正三级Hough变换-检测前跟踪算法

王国宏; 李岳峰; 于洪波; 李林

doi:10.11999/JEIT170622

三维空间中高超声速目标修正三级Hough变换-检测前跟踪算法

doi: 10.11999/JEIT170622

基金项目:

国家自然科学基金(61731023, 61372027, 61501489, 61671462, 61701519)，泰山学者建设工程专项经费

计量
- 文章访问数: 1231
- HTML全文浏览量: 158
- PDF下载量: 171
- 被引次数: 0
出版历程
- 收稿日期: 2017-06-28
- 修回日期: 2017-12-14
- 刊出日期: 2018-04-19

Modified Triple-stage Hough Transform Track-before-detect Algorithm in Three-dimensional Space for Hypersonic Target

Funds:

The National Natural Science Foundation of China (61731023, 61372027, 61501489, 61671462, 61701519), Distinguished Taishan Scholars in Climbing Plan

摘要

摘要: 针对大型相控阵雷达对于临近空间高超声速目标的检测跟踪问题，该文提出一种修正的3级Hough变换(MTS-HT)检测前跟踪算法。首先，为了解决直接进行3维Hough变换计算量大的问题，将3维点迹依次降维映射至径向距离-时间、方位角-时间和仰角-时间3个平面进行2维Hough变换；其次，为了能够在充分利用点迹能量信息的基础上尽量减小强干扰的影响，在每级Hough变换中采用非相参积累和二值积累相结合的双重积累方式进行点迹筛选；最后，通过引入运动约束以及合并相似航迹的方式进行航迹精简，从而有效降低虚假航迹数，得到按照时序关联的最终检测航迹。仿真结果表明，该算法具有较高的航迹检测概率和较低的虚假航迹检测概率，可以实现对临近空间高超声速目标的有效检测跟踪。
- 目标检测 /
- 检测前跟踪 /
- 临近空间 /
- 高超声速目标 /
- 3维Hough变换 /
- 回波能量
Abstract: In view of detection and tracking issue with large phased array radar for near-space hypersonic targets, a Modified Triple-Stage Hough Transform (MTS-HT) Track-Before-Detect (TBD) algorithm is proposed. Firstly, in order to reduce huge computational load problem from direct three-dimensional Hough transform, three- dimensional measurement points are mapped into range-time plane, azimuth-time plane and elevation-time plane in turn for two-dimensional Hough transforms. Besides, to decrease the impact from strong interference, meanwhile, make full use of energy information of points, point selection is carried on by double integration means of non-coherent integration and binary integration in every stage. Finally, false trajectory will be reduced effectively by motion constraints as well as merging of similar trajectories and the final trajectory from sequence association can be obtained. Simulation results show that proposed algorithm can realize effective detection and tracking for near-space hypersonic targets with relatively high trajectory detection probability and low false trajectory detection probability.
- Target detect /
- Track-Before-Detect (TBD) /
- Near space /
- Hypersonic target /
- Three-dimensional Hough transform /
- Echo energy

HTML全文

参考文献(33)

ZHANG Jingmei, SUN Changyin, ZHANG Ruimin, et al. Adaptive sliding mode control for re-entry attitude of near space hypersonic vehicle based on backstepping design[J]. IEEE/CAA Journal of Automatica Sinica, 2015, 2(1): 94-101. doi: 10.1109/JAS.2015.7032910.

WANG Wenqin. Near-space vehicle-borne SAR with reflector antenna for high-resolution and wide-swath remote sensing [J]. IEEE Transactions on Geoscience and Remote Sensing, 2012, 50(2): 338-348. doi: 10.1109/TGRS.2011.2158224.

黄伟, 罗世彬, 王振国. 临近空间高超声速飞行器关键技术及展望[J]. 宇航学报, 2010, 31(5): 1259-1265. doi: 10.3873/ j.issn.1000-1328.2010.05.001.

HUANG Wei, LUO Shibin, and WANG Zhenguo. Key techniques and prospect of near-space hypersonic vehicle[J]. Journal of Astronautics, 2010, 31(5): 1259-1265. doi: 10.3873 /j.issn.1000-1328.2010.05.001.

SAVILLE M A, JACKSON J A, and FULLER D F. Rethinking vehicle classification with wide-angle polarimetric SAR[J]. IEEE Aerospace and Electronic Systems Magazine, 2014, 29(1): 41-49. doi: 10.1109/MAES. 2014.130057.

YANG Yueneng, WU Jie, XIE Yu, et al. Dynamics modeling and maneuverability analysis of a near-space earth observation platform[C]. IEEE Proceedings of the 5th International Conference on Recent Advance in Space Technologies, Istanbal, 2011: 223-226. doi: 10.1109/RAST. 2011.5966828.

杨玉明, 王红, 谭贤四, 等. 再入等离子体隐身及反隐身分析[J]. 空军雷达学院学报, 2012, 26(4): 248-251. doi: 10.3969/ j.issn.1673-8691.2012.04.004.

YANG Yuming, WANG Hong, TAN Xiansi, et al. Analysis of reentry plasma stealth and anti-stealth[J]. Journal of Air Force Radar Academy, 2012, 26(4): 248-251. doi: 10.3969/ j.issn.1673-8691.2012.04.004.

朱方, 吕琼之. 返回舱再入段雷达散射特性研究[J]. 现代雷达, 2008, 30(5): 14-16. doi: 10.3969/j.issn.1004-7859.2008.05.004.

ZHU Fang and L Qiongzhi. A study on radar scattering characteristics of the reentry capsule[J]. Modern Radar, 2008, 30(5): 14-16. doi: 10.3969/j.issn.1004-7859.2008.05.004.

YU Hongbo, WANG Guohong, WU Wei, et al. A novel RHT-TBD approach for weak targets in HPRF radar[J]. Science China Information Sciences, 2016, 59(12): 122304. doi: 10.1007/s11432-015-5482-8.

李林, 王国宏, 于洪波, 等. 一种临近空间高超声速目标检测前跟踪算法[J]. 宇航学报, 2017, 38(4): 420-427. doi: 10.3873 /j.issn.1000-1328.2017.04.012.

LI Lin, WANG Guohong, YU Hongbo, et al. A TBD algorithm for near space hypersonic target[J]. Journal of Astronautics, 2017, 38(4): 420-427. doi: 10.3873/j.issn.1000- 1328.2017.04.012.

ORLANDO D and RICCI G. Track-before-detect algorithms for targets with kinematic constraints[J]. IEEE Transactions on Aerospace and Electronic Systems, 2011, 47(3): 1837-1849. doi: 10.1109/TAES.2011.5937268.

TANG Xu, RATNASINGHAM T, MICHAEL M, et al. Multiple detection-aided low-observable track initialization using ML-PDA[J]. IEEE Transactions on Aerospace and Electronic Systems, 2017, 53(2): 722-735. doi: 10.1109/TAES. 2017.2664598.

JIANG Haichao, YI Wei, THIA K, et al. Multi-frame radar detection of fluctuating targets using phase information[J]. IEEE Transactions on Aerospace and Electronic Systems, 2017, 53(2): 736-749. doi: 10.1109/TAES.2017.2664639.

ZHENG Daikun, WANG Shouyong, and MENG Qingwen. Dynamic programming track-before-detect algorithm for radar target detection based on polynomial time series prediction[J]. IET Radar, Sonar Navigation, 2016, 10(8): 1327-1336. doi: 10.1049/iet-rsn.2015.0332.

GARCIA-FERNANDEZ A F. Track-before-detect labeled multi-bernoulli particle filter with label switching[J]. IEEE Transactions on Aerospace and Electronic Systems, 2016, 52(5): 2123-2138. doi: 10.1109/TAES.2016.150343.

LUIS U M, ANGEL G F, and JESUS G L. Adaptive auxiliary particle filter for track-before-detect with multiple targets[J]. IEEE Transactions on Aerospace and Electronic Systems, 2017, 53(5): 2317-2330. doi: 10.1109/TAES.2017.2691958.

CARSON B D, EVANS E D, and WILSON S L. Search radar detection and track with the Hough transform part I: System concept[J]. IEEE Transactions on Aerospace and Electronic Systems, 1994, 30(1): 102-108. doi: 10.1109/7.250410.

CARSON B D, EVANS E D, and WILSON S L. Search radar detection and track with the Hough transform part II: Detection statistics[J]. IEEE Transactions on Aerospace and Electronic Systems, 1994, 30(1): 109-115. doi: 10.1109/7. 250411.

CARSON B D, EVANS E D, and WILSON S L. Search radar detection and track with the Hough transform part III: Detection performance with binary integration[J]. IEEE Transactions on Aerospace and Electronic Systems, 1994, 30(1): 116-125. doi: 10.1109/7.250412.

MOYER L R, SPAK J, and LAMANNA P. A multi-dimensional Hough transform-based track-before- detect technique for detecting weak targets in strong clutter backgrounds[J]. IEEE Transactions on Aerospace and Electronic Systems, 2011, 47(4): 3062-3068. doi: 10.1109/ TAES.2011.6034689.

CHEN Ji, HENRY L, TIYUS L, et al. A modified probabilistic data association filter in a real clutter environment[J]. IEEE Transactions on Aerospace and Electronic Systems, 1996, 32(1): 300-313. doi: 10.1109/7. 481270.

王国宏, 李林, 于洪波. 基于点集合并的修正Hough变换TBD算法[J]. 航空学报, 2017, 38(1): 320009. doi: 10.7527/ S1000-6893.2016.0068.

WANG Guohong, LI Lin, and YU Hongbo. A modified Hough transform TBD algorithm based on point set merging[J]. Acta Aeronautica et Astronautica Sinica, 2017, 38(1): 320009. doi: 10.7527/S1000-6893.2016.0068.

MOPISEH A and NAYEBI M M. 3-D Hough transform for surveillance radar target detection[C]. Proceedings of IEEE Radar Conference, Rome, 2008: 1-5. doi: 10.1109/RADAR. 2008.4720878.

王国宏, 苏峰, 何友. 三维空间中基于Hough变换和逻辑的航迹起始[J]. 系统仿真学报, 2004, 16(10): 2198-2200. doi: 10.16182/j.cnki.joss.2004.10.021.

WANG Guohong, SU Feng, and HE You. Hough Transform (HT) and logic based track initiator in three dimensional space[J]. Journal of System Simulation, 2004, 16(10): 2198-2200. doi: 10.16182/j.cnki.joss.2004.10.021.

金术玲, 梁彦, 王增福, 等. 两级Hough变换航迹起始算法[J]. 电子学报, 2008, 36(3): 590-593. doi: 10.3321/j.issn:0372-2112. 2008.03.035.

JIN Shuling, LIANG Yan, WANG Zengfu, et al. A two- hierarchy Hough transform based track initiation algorithm [J]. Acta Electronica Sinica, 2008, 36(3): 590-593. doi: 10.3321/j.issn:0372-2112.2008.03.035.

孔敏. 天波超视距雷达目标跟踪技术研究[D]. [博士论文], 海军航空工程学院, 2007.

KONG Min. Research on target tracking technology for over-the-horizon radar[D]. [Ph.D. dissertation], Naval Aeronautical and Astronautical University, 2007.
