屏蔽腔内任意高度线缆端接TVS管电路的电磁耦合时域分析

叶志红; 周海京; 刘强

doi:10.11999/JEIT170615

屏蔽腔内任意高度线缆端接TVS管电路的电磁耦合时域分析

doi: 10.11999/JEIT170615

1.
(重庆邮电大学通信与信息工程学院重庆 400065)
2.
(北京应用物理与计算数学研究所北京 100094)

基金项目:

重庆市教委科学技术研究项目(KJ1704082)，重庆邮电大学博士启动基金(A2016-88)

计量
- 文章访问数: 1054
- HTML全文浏览量: 166
- PDF下载量: 180
- 被引次数: 0
出版历程
- 收稿日期: 2017-06-27
- 修回日期: 2017-12-04
- 刊出日期: 2018-04-19

Time Domain Coupling Analysis for the Arbitrary Height Cable Terminated with TVS Circuit in Shield Cavity

1.
(School of Communication and Information Engineering, Chongqing University of Posts and Telecommunications, Chongqing 400065, China)
2.
(Institute of Applied Physics and Computational Mathematics, Beijing 100094, China)
3.
(Institute of Applied Physics and Computational Mathematics, Beijing 100094, China)

Funds:

The Science and Technology Research Program of Chongqing Municipal Education Commission (KJ1704082), The Doctor Start-up Funding of Chongqing University of Posts and Telecommunications (A2016-88)

摘要

摘要: 该文基于时域有限差分(FDTD)方法和传输线方程，结合插值技术和牛顿迭代法，提出一种新的时域混合算法，能够快速模拟屏蔽腔内任意高度线缆端接瞬态电压抑制(TVS)管电路的电磁耦合问题，并实现空间电磁场与线缆和电路瞬态响应的同步计算。该算法首先利用FDTD方法结合STL网格剖分技术实现屏蔽腔结构的快速建模以及腔体内空间电磁场分布的准确模拟。然后利用传输线方程结合插值技术建立腔体内线缆的场线耦合模型，结合FDTD方法，迭代求解出线缆上的电压和电流响应。对于线缆端接的TVS管电路，列写电压电流方程，采用牛顿迭代法计算得到电路端口的电压响应。通过与电磁仿真软件的计算结果进行对比，验证了所提时域混合算法的正确性。研究表明，该算法能够很好地应用于屏蔽腔内线缆端接负载的TVS管限幅防护设计。
- FDTD方法 /
- 传输线方程 /
- 牛顿迭代法 /
- 任意高度线缆 /
- 瞬态电压抑制管电路
Abstract: This paper presents a novel time domain hybrid method consisting of Finite Difference Time Domain (FDTD) method, Transmission Line (TL) equation, interpolation technique, and Newton iteration method for the coupling simulation of the arbitrary height cable terminated with TVS circuit in shield cavity rapidly. It can achieve a strong synergism computation of electromagnetic field and the responses of the cable and the circuit. The hybrid method uses FDTD method combined with the STL mesh generator technique to model the enclosure of the cavity rapidly and simulate the electromagnetic field distribution in the cavity accurately. The TL equation with interpolation technique is used to set up the coupling model of the cable in the cavity. Then the FDTD method is used to discrete the TL equation to obtain the transient voltage and current responses on the cable. The current-voltage equations are used for the analysis of the TVS circuit. Then the Newton iteration method is utilized to solve the current-voltage equations to obtain the voltage responses on the TVS. The correctness of the hybrid method is confirmed by comparing with the results obtained by electromagnetic simulation software. In testing, the hybrid method can be well applied to the limiting protection design of the loads in the terminal of the cable in shield cavity.
- Finite Difference Time Domain (FDTD) method /
- Transmission Line (TL) equation /
- Newton iteration method /
- Arbitrary height cable /
- Transient Voltage Suppressor (TVS) circuit

HTML全文

参考文献(12)

NODA T and KIKUMA T. A robust and efficient iterative scheme for the EMT simulations of nonlinear circuits[J]. IEEE Transactions on Power Delivery, 2011, 26(2): 1030-1038. doi: 10.1109/TPWRD.2010.2091288.

NIU B, SONG Z X, GENG Y S, et al. Electromagnetic topology analysis on relation between electromagnetic interference inside equipment and external electrostatic discharge[C]. Asia-Pacific Sympsoium on Electromagnetic Compatibility, Singapore, 2008: 815-818.

XIE Li and LEI Yinzhao. Transient response of a multiconductor transmission line with nonlinear terminations excited by an electric dipole[J]. IEEE Transactions on Electromagnetic Compatibility, 2009, 51(3): 805-810. doi: 10.1109/TEMC.2009.2023327.

YUAN Keliang, WANG Jianguo, XIE Haiyan, et al. SPICE model of a single twisted-wire pair illuminated by a plane wave in free space[J]. IEEE Transactions on Electromagnetic Compatibility, 2015, 57(30): 574-583. doi: 10.1109/TEMC. 2015.2392852.

XIE Haiyan, DU Taijiao, ZHANG Maoyu, et al. Theoretical and experimental study of effective coupling length for transmission lines illuminated by HEMP[J]. IEEE Transactions on Electromagnetic Compatibility, 2015, 57(6): 1529-1538. doi: 10.1109/TEMC.2015.2463814.

XIONG Run, CHEN Bin, MAO Yunfei, et al. A simple local approximation FDTD model of short apertures with a finite thickness[J]. Progress in Electromagnetics Research, 2012, 131: 135-152. doi: 10.2528/PIER12072201.

王为, 覃宇建, 刘培国, 等. 基于高阶时域有限差分法与改进节点分析法混合求解复杂传输线网络瞬态响应[J]. 电子与信息学报, 2012, 34(12): 2999-3005. doi: 10.3724/SP.J.1146. 2012.00160.

WANG Wei, QIN Yujian, LIU Peiguo, et al. The solution of transient response for complex transmission line network by hybrid higher order finite difference time domain-modified nodal analysis method[J]. Journal of Electronics Information Technology, 2012, 34(12): 2999-3005. doi: 10.3724/SP.J.1146.2012.00160.

YE Zhihong, XIONG Xiangzheng, LIAO Cheng, et al. A hybrid method for electromagnetic coupling problems of transmission lines in cavity based on FDTD method and transmission line equation[J]. Progress in Electromagnetics Research M, 2015, 42: 85-93. doi: 10.2528/PIERM15032605.

YE Zhihong, XIONG Xiangzheng, ZHANG Min, et al. A novel time domain hybrid method for coupling problems of long cables excited by electromagnetic pulses[J]. IEEE Transactions on Electromagnetic Compatibility, 2016, 58(6): 1710-1716. doi: 10.1109/TEMC.2016.2587904.

陈伶璐, 周海京, 李瀚宇, 等. 并行时域有限差分法网格自动剖分技术[J]. 西南交通大学学报, 2013, 48(4): 776-782. doi: 10.3969/j.issn.0258-2724.2013.04.028.

CHEN Linglu, ZHOU Haijing, LI Hanyu, et al. Cartesian mesh generator for parallel finite-difference time-domain method[J]. Journal of Southwest Jiaotong University, 2013, 48(4): 776-782. doi: 10.3969/j.issn.0258-2724.2013.04.028.
