基于水下成像模型的图像清晰化算法

杨爱萍; 曲畅; 王建; 张莉云

doi:10.11999/JEIT170460

基于水下成像模型的图像清晰化算法

doi: 10.11999/JEIT170460

1.
(天津大学电气自动化与信息工程学院天津 300072)

基金项目:

国家自然科学基金(61372145, 61472274)

计量
- 文章访问数: 2026
- HTML全文浏览量: 232
- PDF下载量: 273
- 被引次数: 0
出版历程
- 收稿日期: 2017-05-15
- 修回日期: 2017-11-02
- 刊出日期: 2018-02-19

Underwater Image Visibility Restoration Based on Underwater Imaging Model

Funds:

The National Natural Science Foundation of China (61372145, 61472274)

摘要

摘要: 受水下场景中有机物和悬浮颗粒的影响，水下图像存在对比度低、颜色失真和细节丢失等问题。同时，水下场景中通常有人工光源存在，造成图像光照不均。传统基于图像去雾的方法用于水下图像复原时效果欠佳，为充分考虑水对光的吸收和散射作用，近期提出了新的水下成像模型和图像复原方法。但是这些方法未考虑红通道影响，导致估计的散射比偏大；另外，也未考虑人工光源的影响，导致估计的背景光过大。针对这些问题，该文提出一套有效的水下图像清晰化方案。首先，通过设置阈值确定是否将红通道信息用于暗通道计算，并将反映人工光源影响的饱和度指标用于散射比估计，以减小人工光源的影响。由此，提出了基于红通道预判和饱和度指标的暗通道计算方法。然后，根据三通道衰减系数比估计每个通道的透射率，可弥补目前很多方法假设蓝绿通道透射率一致的缺陷。最后，利用Shades of Gray算法估计环境光，并结合新的水下成像模型得到复原图像。实验结果表明，该文算法可显著提升图像的对比度，得到颜色自然、细节清晰的复原图像。
- 水下成像模型 /
- 红通道 /
- 人工光源 /
- 透射率
Abstract: As a result of the existence of organisms and suspended particles under underwater conditions, images captured under water usually have low contrast, color distortion and loss of visibility. At the same time, due to the existence of the artificial light source, the underwater image usually has the non-uniform illumination. Traditional hazy-removal methods perform poorly under water. In order to take both absorption and scattering into consideration, a new underwater image formation model and restoration methods are proposed recently. However, these methods ignore the great impact of the red channel information and artificial light source. To solve this problem, a new approach is proposed for underwater image visibility restoration. Firstly, a threshold is set to determine whether to use the red channel information to estimate the dark channel, and a saturation indicator which is used to indicate the impact of artificial light source is utilized to calculate the scattering rate. Based on the red channel information anticipation and the saturation indicator, a new method is proposed to estimate the dark channel. Then, the transmission of each channel is estimated according to the attenuation coefficient ratio, which makes the proposed method more robust. Finally, the ambient light is obtained using the Shades of Gray algorithm, and the visibility restoration result is achieved based on a new underwater image formation model. Experimental results demonstrate that the proposed algorithm can significantly improve the contrast of the underwater image with more natural color and better visibility.
- Underwater imaging model /
- Red channel /
- Artificial light source /
- Transmission

HTML全文

参考文献(20)

HUANG Bingjing, LIU Tiegen, HU Haofeng, et al. Underwater image recovery considering polarization effects of objects[J]. Optics Express, 2016, 24(9): 9826-9838. doi: 10.1364/OE.24.009826.

LI Chongyi, GUO Jichang, CONG Runming, et al. Underwater image enhancement by dehazing with minimum information loss and histogram distribution prior[J]. IEEE Transactions on Image Processing, 2016, 25(12): 5664-5677. doi: 10.1109/TIP.2016.2612882.

DREWS P, NASCIMENTO E R, BOTELHO S, et al. Underwater depth estimation and image restoration based on single images[J]. IEEE Computer Graphics and Applications, 2016, 36(2): 24-35. doi: 10.1109/MCG.2016.26.

杨爱萍, 张莉云, 曲畅, 等. 基于加权 L1 正则化的水下图像清晰化算法[J]. 电子与信息学报, 2017, 39(3): 626-633. doi: 10.11999/JEIT160481.

YANG Aiping, ZHANG Liyun, QU Chang, et al. Underwater images visibility improving algorithm with weighted L1 regularization[J]. Journal of Electronics Information Technology, 2017, 39(3): 626-633. doi: 10.11999/JEIT160481.

WEN Haocheng, TIAN Yonghong, HUANG Tiejun, et al. Single underwater image enhancement with a new optical model[C]. IEEE International Symposium on Circuits and Systems (ISCAS), Beijing, China, 2013: 753-756.

ANCUTI C, ANCUTI C O, HABER T, et al. Enhancing underwater images and videos by fusion[C]. IEEE Computer Vision and Pattern Recognition (CVPR), Providence, USA, 2012: 81-88.

FU Xueyang, ZHUANG Peixian, HUANG Yue, et al. A retinex-based enhancing approach for single underwater image[C]. IEEE International Conference on Image Processing (ICIP), Paris, France, 2014: 4572-4576.

GALDRAN A, PARDO D, PICON A, et al. Automatic red-channel underwater image restoration[J]. Journal of Visual Communication and Image Representation, 2015, 26: 132-145. doi: 10.1016/j.jvcir.2014.11.006.

CHENG Chiayang, SUNG Chiachi, and CHANG Hernghua. Underwater image restoration by red-dark channel prior and point spread function deconvolution[C]. IEEE International Conference on Signal and Image Processing Applications (ICSIPA), Kuala Lumpar, Malaysia, 2015: 110-115.

LU Huimin, LI Yujie, XU Xing, et al. Underwater image enhancement method using weighted guided trigonometric filtering and artificial light correction[J]. Journal of Visual Communication and Image Representation, 2016, 38: 504-516. doi: 10.1016/j.jvcir.2016.03.029.

MALLIK S, KHAN S S, and PATI U C. Underwater image enhancement based on dark channel prior and histogram equalization[C]. IEEE International Conference on Innovations in Information Embedded and Communication Systems (ICIIECS), Coimbatore, India, 2016: 139-144.

HE Kaiming, SUN Jian, and TANG Xiaoou. Single image haze removal using dark channel prior[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2011, 33(12): 2341-2353. doi: 10.1109/TPAMI.2010.168.

HE Kaiming, SUN Jian, and TANG Xiaoou. Guided image filtering[C]. European Conference on Computer Vision (ECCV), Crete, Greece, 2010: 1-14.

ZHAO Xinwei, JIN Tao, and QU Song. Deriving inherent optical properties from background color and underwater image enhancement[J]. Ocean Engineering, 2015, 94: 163-172. doi: 10.1016/j.oceaneng.2014.11.036.

PARK D, PARK H, HAN D K, et al. Single image dehazing with image entropy and information fidelity[C]. IEEE International Conference on Image Processing(ICIP), Paris, France, 2014: 4037-4041.

LAND E H. The retinex theory of color vision[J]. Scientific American, 1977, 237(6): 108-128. doi: 10.1038/ scientificamerican1277-108.

BUCHSBAUM G. A spatial processor model for object colour perception[J]. Journal of The Franklin Institute- engineering and Applied Mathematics, 1980, 310(1): 1-26. doi: 10.1016/0016-0032(80)90058-7.

FINLAYSON G D and TREZZI E. Shades of gray and colour constancy[C]. Color Imaging Conference(CIC), Arizona, USA, 2004: 37-41.

LI Fang, WU Jinyong, WANG Yike, et al. A color cast detection algorithm of robust performance[C]. IEEE Fifth International Conference on Advanced Computational Intelligence(ICACI), Nanjing, China, 2012: 662-664.
