GPS L1频点授权信号质量评估

康立; 卢晓春; 王雪; 贺成艳; 饶永南; 杨德进

doi:10.11999/JEIT170440

GPS L1频点授权信号质量评估

doi: 10.11999/JEIT170440

基金项目:

国家自然科学基金(61501430)，中国科学院青年创新促进会基金

计量
- 文章访问数: 1795
- HTML全文浏览量: 199
- PDF下载量: 282
- 被引次数: 0
出版历程
- 收稿日期: 2017-05-11
- 修回日期: 2017-12-27
- 刊出日期: 2018-04-19

Authorized Signals Quality Assessment on GPS L1

Funds:

The National Natural Science Foundation of China (61501430), The Youth Innovation Promotion Association Foundation of Chinese Academy of Sciences

摘要

摘要: GNSS信号的空间信号(SIS)质量直接影响用户的定位、测试和授时(Positioning, Velocity and Timing, PVT)服务精度，但由于授权信号保密等原因，授权信号的伪码序列未知，卫星导航系统授权信号质量评估存在一定的困难性。该文主要分析GPS BIIF-5卫星L1频点的相干自适应副载波调制(CASM)信号，利用匹配滤波理论恢复出采集数据中的P(Y)码和M码两个授权信号分量的伪码符号，采用极大似然估计结合信号分布特点准确求解出各信号分量之间的功率分配。重点分析P(Y)码和M码信号相关性能，包含相关曲线、相关损失和S曲线过零点偏差(S-Curve bias)，定量地评估了授权信号的空间信号质量。提出完整的基于GPS L1频点授权信号质量评估方法，研究成果可作为其他卫星导航系统授权信号质量评估的参考。
- 授权信号质量评估 /
- 伪码序列估计 /
- 功率分配 /
- 相关性能
Abstract: The quality of Signal-In-Space (SIS) for Global Navigation Satellite System (GNSS) is directly linked to users Positioning, Velocity and Timing (PVT) service. Limited to the insensitivity of authorized signals, the pseudo codes can not be obtained, so it is difficult to assess the authorized signal quality. This paper mainly focus on analyzing the Coherent Adaptive Subcarrier Modulation (CASM) signal on L1 frequency points for GPS BIIF-5 satellite and the code sequences of P(Y) and M signal are resumed by using matched filtering technology. The power distribution of each signal component can be solved through the maximum likelihood estimation theory combined with the signal characteristics. This paper laies special stress on quantitatively analyzing the correlation performance on P(Y) and M signals, including correlation curve, correlation loss and S-curve biases. Based on this complete authorized signals quality assessment method for GPS L1, the research productions can be reference to other satellite navigation systems authorized signals.
- Authorized signals quality assessment /
- Pseudo codes sequence estimation /
- Power distributions /
- Correlation performance

HTML全文

参考文献(18)

谢刚. 全球导航卫星系统原理GPS、格洛纳斯和伽利略系统[M]. 北京: 电子工业出版社, 2013: 111-113.

XIE Gang. Principles of GNSS: GPS, GLONASS and Galileo[M]. Beijing: Publishing House of Electronics Industry, 2013: 111-113.

卢晓春, 周宏伟. GNSS 空间信号质量分析方法研究[J]. 中国科学: 物理学力学天文学, 2010, 40(5): 528-533.

LU X C and ZHOU H W. GNSS signal-in-space quality analysis and research[J]. China Science: Physics, Mechanics and Astronomy, 2010, 40(5): 528-533.

THOELERT S, ERKER S, and MEUERE M. GNSS signal verification with a high gain antennacalibration strategies and high quality signal assessment[C]. Proceedings of ION National Technical Meeting-2009, Anaheim, California, 2009: 289-300.

KAKOS D M, ESTERHUIZEN S, and MITELMAN A. High gain antenna measurements and signal characterization of the GPS satellites[C]. Proceeding of the Institute of Navigation GNSS Meeting, Long Beach, CA, 2004: 1724-1731.

DAFESH P A, NGUYEN T M, and LAZAR S. Coherent Adaptive Subcarrier Modulation (CASM) for GPS modernization[C]. Proceedings of ION National Technical Meeting, Nashville, TN, 1999: 649-660.

FAN T, LIN V S, WANG G H, et al. Study of signal combining methodologies for future GPS flexible navigation payload(Part II)[C]. Position, Location and Navigation Symposium, Nashville, TN 2008: 1079-1089. doi: 10.1109/ PLANS.2008.4570115.

THOELERTS S and M VERGARE. Characterization of nominal signal distortions and impact on receiver performance for GPS(IIF) L5 and Galileo(IOV)E1/E5a signals[C]. Proceedings of the 27th International Technical Meeting of the ION Satellite Division, ION GNSS+2014, Tampa, Florida, 2014: 8-12.

THOELERTS S, ENNEKING C, and VERGARA M. GNSS nominal signal distortions-estimation, validation and impact on receiver performance[C]. Proceedings of the 28th International Technical Meeting of The Satellite Division of the Institute of Navigation, Tampa, Florida, 2015: 1902-1923.

HE Chengyan, GUO J, and LU Xiaochun. Generation mechanisms of GNSS navigation signal distortions and influence on ranging performance[J]. Systems Engineering Electronics, 2015, 37(7): 1611-1620. doi: 10.3969/j.issn.1001- 506X.2015.07.22.

THOELERT S, FURTHNER J, and MEURER M. GNSS survey-signal quality assessment of the latest GNSS satellites[C]. Proceedings of the 2013 International Technical Meeting of The Institute of Navigation, San Diego, California, 2013: 608-615.

THOELERT S. GPS IIR-M L1 transmit power redistribution: Analysis of GNSS receiver and high-gain antenna data[C]. Proceedings of the 30th International Technical Meeting of The Satellite Division of the Institute of Navigation, Portland, Oregon, 2017: 1589-1602.

PARTRIDG M D and DAFESH P A. Code power measurement methodology for GPS Block IIR-M and IIF on-orbit test procedures[C]. Proceedings of International Technical Meeting of the Satellite Division of the Institute of Navigation, Salt Lake City, UT, 2001: 11-14.

HEIN G W. Performance of a Galileo PRS/GPS M-code combined service[C]. Proceedings of the 2005 National Technical Meeting of The Institute of Navigation, San Diego, CA, 2005: 754-768.

THOELERT S, MEURER M, ERKE S, et al. A multi- technique approach for characterizing the SVN49 signal anomaly, Part 2: Chip Shape analysis[J]. GPS Solutions 2012, 16: 29-39. doi: 10.1007/s10291-01100204-1.

XIAO W, LIU Wenxiang, and SUN Guangfu. Modernization milestone: BeiDou M2-S initial signal analysis[J]. GPS Solutions, 2016, 20: 125-133. doi: 10.1007/s10291-015-0496-7.

PAGOT J B, THEVENON P, and JULIEN O. Estimation of GNSS signals nominal distortions from correlation and chip domain[C]. Proceedings of International Technical Meeting of the Satellite Division of the Institute of Navigation, Dana Point, California, 2015: 415-427.
