修正主模抑制稳健自适应波束形成算法

王昊; 马启明

doi:10.11999/JEIT170236

修正主模抑制稳健自适应波束形成算法

doi: 10.11999/JEIT170236

王昊¹,
马启明¹

计量
- 文章访问数: 1293
- HTML全文浏览量: 150
- PDF下载量: 236
- 被引次数: 0
出版历程
- 收稿日期: 2017-03-20
- 修回日期: 2017-05-31
- 刊出日期: 2017-11-19

Modified Dominant Mode Rejection Robust Adaptive Beamforming Algorithm

WANG Hao¹,
MA Qiming¹

摘要

摘要: 针对自适应波束形成器在少快拍和波束指向角度失配情况下性能严重下降的问题，该文提出一种基于修正协方差矩阵的稳健主模抑制算法。算法提出利用修正协方差矩阵估计主模成分，进而重构出数据协方差矩阵，同时利用其特征向量向期望信号导引向量的投影来确定信号子空间维数。为提高算法在低信噪比情况下的性能，提出利用信号区域积分得到正定矩阵，以其主特征向量对信号子空间进行扩充，再将导引向量向信号子空间进行投影得到修正的导引向量。最终利用重构协方差矩阵及修正导引向量得到最优权值。理论分析和仿真实验验证了所提算法的有效性和稳健性。
- 信号与信息处理 /
- 自适应波束形成 /
- 主模抑制 /
- 修正协方差矩阵 /
- 少快拍 /
- 角度失配
Abstract: In order to solve the problem of adaptive beamformer performance degradation due to few snapshots and mainlobe angle mismatch, a robust dominant mode rejection adaptive beamforming algorithm based on modified covariance matrix is proposed. The algorithm employs modified covariance matrix to estimate dominant mode component and reconstructs covariance matrix. Then, the signal subspace is obtained by projecting the steering vector of the desired signal onto eigenvector of the reconstructed covariance matrix, for enhancing the performance of algorithm at low SNR, the algorithm uses the principal eigenvector of a positive define matrix which integrates the desired signal region to modify signal subspace, thus calibrated steering vector of the desired signal is obtained by projecting the presumed steering vector onto the modified signal subspace. Finally, the optimal weight is obtained from the reconstructed covariance matrix and the calibrated steering vector. Theoretical analysis and simulation show the effectiveness and robustness of the proposed algorithm.
- Signal and information processing /
- Adaptive beamforming /
- Dominant mode rejection /
- Modified covariance matrix /
- Few snapshots /
- Angle mismatch

HTML全文

参考文献(19)

ABRAHAM D A and OWSLEY N L. Beamforming with dominant mode rejection[C]. IEEE OCEANS Conference, Washington, 1990: 470-475. doi: 10.1109/ OCEANS.1990. 584812.

DU Lin, LI Jian, and PETER S. Fully automatic computation of diagonal loading levels for robust adaptive beamforming[J]. IEEE Transactions on Aerospace and Electronic Systems, 2010, 46(1): 449-458. doi: 10.1109/TAES. 2010.5417174.

ZHANG W, WANG J, and WU S. Robust Capon beamforming against large DOA mismatch[J]. Signal Processing, 2013, 93(4): 804-810. doi: 10.1016/j.sigpro.2012. 10.002.

FELDMAN D D and GRIFFITHS L J. A projection approach for robust adaptive beamforming[J]. IEEE Transactions on Signal Processing, 1994, 42(4): 867-876. doi: 10.1109/78.285650.

FELDMAN D D and GRIFFITHS L J. A constraint projection approach for robust adaptive beamforming[C]. Proceedings of the IEEE International Conference on Acoustics, Speech and Signal Processing, Toronto, Canada, 1991: 1381-1384. doi: 10.1109/ICASSP.1991.150680.

LI Jian, PETER S, and WANG Z. On robust Capon beamforming and diagonal loading[J]. IEEE Transactions on Signal Processing, 2003, 51(7): 1702-1715. doi: 10.1109/TSP. 2003.812831.

CAPON J. High-resolution frequency-wavenumber spectrum analysis[J]. Proceedings of the IEEE, 1969, 57(8): 1408-1418. doi: 10.1109/PROC.1969.7278.

YU L, LIU W, and LANGLEY R. SINR analysis of the subtraction-based SMI beamformer[J]. IEEE Transactions on Signal Processing, 2010, 58(11): 5926-5932. doi: 10.1109/TSP. 2010.2058801.

ZHANG L, LIU W, and YU L. Performance analysis for finite sample MVDR beamformer with forward backward processing[J]. IEEE Transactions on Signal Processing, 2011, 59(5): 2427-2431. doi: 10.1109/TSP.2011.2109957.

JOHN E, RUSSEL C, and MARK E. Comment on mofied MUSIC algorithm for estimating DOA of signals[J]. Signal Processing, 1996, 55(2): 253-254. doi: 10.1016/S0165- 1684(96)00179-X.

WAGE K E and BUCK J R. Snapshot performance of the dominant mode rejection beamformer[J]. IEEE Journal of Oceanic Engineering, 2014, 39(2): 212-225. doi: 10.1109/JOE. 2013.2251538.

WAGE K E and BUCK J R. SINR loss of the dominant mode rejection beamformer[C]. IEEE International Conference on Acoustics, Speech and Signal Processing, Brisbane, Queensland, 2015: 2499-2503. doi: 10.1109/ICASSP.2015. 7178421.

JOSE A D S and KATHLEEN E W. An improved whitening transformation for snapshot-deficient scenarios[C]. OCEANS 2015 MTS/IEEE Washington, 2015: 1-6. doi: 10.23919/ OCEANS.2015.7404410.

SHAN Chao, WU Y, and WANG Y. ESB-DMR beamforming

under random matrix theory judgment principle[C]. IET International Radar Conference, Hangzhou, China, 2015: 1-4. doi: 10.1049/cp.2015.1006.

SOMASUNDARAM S D and PARSONS N H. Evaluation of robust Capon beamforming for passive sonar[J]. IEEE Journal of Oceanic Engineering, 2011, 36(4): 686-695. doi: 10.1109/JOE.2011.2167374.

GU Y and LESHEM A. Robust adaptive beamforming based on interference covariance matrix reconstruction and steering vector[J]. IEEE Transactions on Signal Process, 2012, 60(7): 3881-3885. doi: 10.1109/TSP.2012.2194289.

HUANG L, ZHANG J, XU X, et al. Robust adaptive beamforming with a novel interference-plus-noise covariance matrix reconstruction method[J]. IEEE Transactions on Signal Processing, 2015, 63(7): 1643-1650. doi: 10.1109/TSP. 2015.2396002.

YUAN X and GAN L. Robust adaptive beamforming via a novel subspace method for interference covariance matrix reconstruction[J]. Signal Processing, 2017, 130: 233-242. doi: 10.1016/j.sigpro.2016.07.008.
