平面阵列方向图优化的改进PSO算法

仇永斌; 黄显林; 张树春; 姜巍

doi:10.11999/JEIT170167

平面阵列方向图优化的改进PSO算法

doi: 10.11999/JEIT170167

2.
(空军哈尔滨飞行学院飞行仿真技术研究所哈尔滨 150001) ②(哈尔滨工业大学导航制导与控制理论中心哈尔滨 150001)

基金项目:

国家自然科学基金(61273095)

计量
- 文章访问数: 1799
- HTML全文浏览量: 144
- PDF下载量: 273
- 被引次数: 0
出版历程
- 收稿日期: 2017-02-27
- 修回日期: 2017-05-12
- 刊出日期: 2017-10-19

Modified PSO Algorithm for Planar Arrays Pattern Optimization

2.
(Flight Simulation Technology Institute, Air Force Harbin Flight Academy, Harbin 150001, China)

Funds:

The National Natural Science Foundation of China (61273095)

摘要

摘要: 粒子群优化算法(PSO)是合成天线阵列预期方向图的有效手段。但对于某些大型平面阵列方向图复杂的非线性优化问题，该算法收敛速度慢且最优粒子易陷入局部最优解，因而使得算法失效。针对这一问题，该文提出一种改进PSO算法来提高传统PSO算法的收敛特性。该算法在初始化最优粒子时采用解析初值而不是随机初值。对于给定的预期方向图，通过矩阵运算解析对应该方向图的阵元权系数。之后将这些权系数指定为任意一个粒子的解析初值，而种群的其他粒子仍然赋随机初值，之后再衔接标准PSO算法的寻优迭代过程。这种初始化方法使得种群粒子在寻优搜索过程开始之前，即可得到最优粒子初值的有效估计。仿真结果表明，相对于全部粒子赋随机初值的标准算法而言，这种改进算法收敛速度更快，适应度值收敛得更深，因而有效提高了算法的收敛特性，从而能够得到满足预期方向图指标要求的优化结果。
- 有源相控阵 /
- 平面阵列 /
- 副瓣干扰 /
- 方向图优化 /
- 粒子群优化算法
Abstract: Particle Swarm Optimization (PSO) is an efficient technology to synthesize desired pattern of antenna arrays. But in some complicated cases, the optimizer will fail because the optimum particles fall into local best solutions and the convergence is so bad, especially for nonlinear optimization of large planar arrays pattern. To solve this problem, a modified optimizer is presented to improve the convergence of traditional PSO by means of initializing the particles with analytical values rather than random values. For any given desired pattern, the corresponding aperture weights can be derived by matrix operations and these weights are then used as a particles initial values while other particles are still initialized randomly. By this initialization, an efficient estimation of the optimum particles initial values can be achieved before the beginning of all particles searching process. After that the standard PSO iterations work as usual. The simulation results prove that this modified optimizer converges more rapidly and deeply than the traditional PSO and more satisfying global solutions and desired pattern could be obtained.
- Active Electronically Scanned Array (AESA) /
- Planar array /
- Sidelobes interference /
- Pattern optimization /
- Particle Swarm Optimization (PSO)

HTML全文

参考文献(16)

KINGHORN T, SCOTT I, and TOTTEN E. Recent advances in airborne phased array radar systems[C]. IEEE International Symposium on Phased Array Systems and Technology, Waltham, Massachusetts, USA, 2016: 1-7. doi: 10.1109/ARRAY.2016.7832541.

MAHAFZA B R and ELSHERBENI A Z. MATLAB Simulations for Radar Systems Design[M]. Boca Raton London New York Washington, D.C. USA, Chapman Hall/ CRC CRC Press LLC, 2004: 8.5.

赵菲, 齐会颖, 邱磊, 等. 自适应动态Meta粒子群优化算法综合多方向图共形阵列[J]. 电子与信息学报, 2012, 34(6): 1476-1482. doi: 10.3724/SP.J.1146.2011.01187.

ZHAO Fei, QI Huiying, QIU Lei, et al. Adaptive dynamic meta particle swarm optimization algorithm synthesizing multiple-pattern conformal array[J]. Journal of Electronics Information Technology, 2012, 34(6): 1476-1482. doi: 10.3724 /SP.J.1146.2011.01187.

袁智皓, 耿军平, 金荣洪, 等. 基于改进的粒子群算法的二维阵列天线方向图综合技术[J]. 电子与信息学报, 2007, 29(5): 1236-1239.

YUAN Zhihao, GENG Junping, JIN Ronghong, et al. Pattern synthesis of 2-D arrays based on a modified particle swarm optimization algorithm[J]. Journal of Electronics Information Technology, 2007, 29(5): 1236-1239.

OLIVERI G, VIANI F, ANSELMI N, et al. Synthesis of multilayer WAIM coatings for planar-phased arrays within the system-by-design framework[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(6): 2482-2496. doi: 10.1109/TAP.2015.2415516.

HADJ A L and BOUSSOUAR B. New optimisation algorithm for planar antenna array synthesis[J]. AEU- International Journal of Electronics and Communications, 2012, 66(9): 752-757. doi: 10.1016/j.aeue.2012.01.00.

YU Xiaomeng, ZHANG Yan, DONG Tao, et al. Design of low side-lobe level conformal antenna array by PSO-GA[C]. IEEE International Conference on Ubiquitous Wireless Broadband, Nanjing, China, 2016: 1-3. doi: 10.1109/ICUWB.2016. 7790529.

GHATAK R, KARMAKAR A, and PODDAR D R. Evolutionary optimization of Haferman carpet fractal patterned antenna array[J]. International Journal of RF and Microwave Computer-Aided Engineering, 2015, 25(8): 719-729. doi: 10.1002/mmce.20911.

MANICA L, CARLIN M, MALCIC I, et al. Wideband multilayer WAIM design and optimization[C]. 8th European Conference on Antennas and Propagation, Hague, the Netherlands, 2014: 2997-3000. doi: 10.1109/EuCAP.2014. 6902458.

BERA R, MANDAL D, GHOSHAL S P, et al. Optimal design of concentric elliptical array antenna for maximum side-lobe level reduction using particle swarm optimization with aging leader and challengers[C]. International Conference on Communication and Signal Processing (ICCSP), Melmaruvathur, Tamilnadu, India, 2016: 1817-1821. doi: 10.1109/ICCSP.2016.7754482.

REZAGHOLI A and MOHAJERI F. Directivity optimization of fractal antenna arrays using PSO algorithm[C]. IEEE 24th Iranian Conference on Electrical Engineering (ICEE), Shiraz, Iran, 2016: 1224-1228. doi: 10.1109/IranianCEE.2016. 7585708.

BROWN A D. Electronically Scanned Arrays: MATLAB Modeling and Simulation[M]. Boca Raton London New York, CRC Press, Taylor Francis Group, LLC, 2012: 35-80.

KENNEDY J and EBERHART R. Particle swarm optimization[C]. Proceedings of the 1995 IEEE International Conference on Neural Networks, Part 1 (of 6), Perth, Austrilia, 1995, 4: 1942-1948.

SHI Yuhui and EBERHART R. A modified particle swarm optimizer[C]. Proceedings of the IEEE International Conference on Evolutionary Computation, Anchorage, AK, USA, 1998: 69-73.
