一种高效精确的FMCW SAR动静目标混合场景回波模拟方法

易向东

doi:10.11999/JEIT161384

一种高效精确的FMCW SAR动静目标混合场景回波模拟方法

doi: 10.11999/JEIT161384

易向东¹

基金项目:

国家自然科学基金(61475049)

计量
- 文章访问数: 1267
- HTML全文浏览量: 205
- PDF下载量: 366
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-21
- 修回日期: 2017-06-09
- 刊出日期: 2017-08-19

An Accurate and Efficient FMCW SAR Raw Data Simulation Method with Moving and Fixed Targets

Yi Xiangdong¹

Funds:

The National Natural Science Foundation of China (61475049)

摘要

摘要: 近几年来，由于小型无人机的兴起，基于FMCW体制的合成孔径雷达(SAR)由于体积小，重量轻，成本低得到了快速发展。然而，由于传统的脉冲SAR中的停-走假设不再成立，FMCW SAR成像处理与传统的脉冲SAR有着很大的不同，这样使得在FMCW SAR实测数据进行处理和分析时往往缺乏理论支撑。因此，开展FMCW SAR的信号处理研究具有重要的现实意义和军事价值。目前，国内外关于FMCW SAR的研究主要集中在其成像处理方法上，在回波模拟方向研究甚少，特别是对于既包含分布式运动目标又有静止目标下的真实场景下的FMCW SAR回波快速模拟方法更是鲜有涉及。基于此，该文在FMCW SAR平台脉内连续运动的基础上推导了一种适用于动静目标的精确的FMCW SAR 2维频域模型，并基于该模型提出一种高效精确的FMCW SAR动静目标混合场景回波模拟的方法。点目标和场景目标的仿真试验验证了该模拟方法的有效性，效率分析发现该种模拟方法的效率远高于传统的仿真方法。
- 合成孔径雷达 /
- 调频连续波 /
- 回波模拟 /
- 2维频谱 /
- 运动目标
Abstract: Because of compact size, light weight, low-cost, FMCW SAR develops rapidly in recent years with the rose of the small Unmanned Aerial Vehicle (UAV). However, the signal processing methods are very different from that of pulsed-SAR due to the invalid suppose of stop and go and hence it is some confused in the real-data processing. Therefore, it is significant to make a deep research of FMCW SAR. However, much attention is paid on the aspect of data focusing while little research concentrates on the raw data simulation, especially for moving targets. In view of these, this paper firstly derived an accurate 2-D spectrum model in the consideration of the in-pulses motion of FMCW SAR, and then a highly-efficient raw data simulation method for FMCW SAR with moving targets is proposed. Point targets and real scene raw data simulation experiments are carried out to validate it and the its efficiencyis analyzed, results show its highefficiency comparing with the conventional methods.
- SAR /
- Frequency Modulation Continuous Wave (FMCW) /
- Raw data simulation /
- 2-D spectrum /
- Moving target

HTML全文

参考文献(20)

META A, HAKKAART P, ZWAN D F V, et al. First demonstration of an X-band airborne FMCW SAR[C]. Proceedings of EUSAR Conference, Dresden, Germany, 2006: 209-212.

刘玉立, 蔡永俊, 张祥坤, 等. 调频连续波合成孔径雷达系统设计与实现[J]. 遥感技术与应用, 2016, 31(2): 255-259.

LIU Yuli, CAI Yongjun, ZHANG Xiangkun, et al. Design and realization of LFMCW SAR system[J]. Remote Sensing Techonology and Application, 2016, 31(2): 255-259.

蔡永俊, 张祥坤, 姜景山. 调频连续波合成孔径雷达回波建模与信号分析[J]. 电波科学学报, 2015, 30(6): 1157-1163. doi: 10.13443/j.cjors.2014120902.

CAI Yongjun, ZHANG Xiangkun, and JIANG jingshan. Echo modeling and signal analysis of frequency modulated continuous wave synthetic aperture radar[J]. Chinese Journal of Radio Science, 2015, 30(6): 1157-1163. doi: 10.13443/ j.cjors.2014120902.

ZHANG F, HU C, LI W, et al. Accelerating time-domain SAR raw data simulation for large areas using multi-GPUs[J]. IEEE Journal of Selected Topics in APPlied Earth Observations and Remote Sensing, 2014, 7(9): 3956-3966.

LIU Qi, HUANG Haifeng, HE Zhihua, et al. Spaceborne AT-InSAR raw signal simulation of dynamic ocean scene[C]. Progress in Electromagnetic Research Symposium (PIERS), Shanghai, China, 2016: 1102-1107.

LIU Baochang and HE Yijun. SAR raw data simulation for ocean scenes using inverse Omega-K algorithm[J]. IEEE Transactions on Geoscience Remote Sensing, 2016, 54(10): 6151-6169.

YANG Liang, WANG Gang, and LGaohuan. Efficient TOPS mode raw data simulator of extended scenes[J]. IET Radar, Sonar Navigation, 2016, 10(6): 1065-1070.

DOGAN O and KARTAL M. Efficient strip-mode SAR raw- data simulation of fixed and moving targets[J]. IEEE Geoscience and Remote Sensing Letter, 2011, 8(5): 884-888.

汪丙南, 张帆, 向茂生. 基于混合域的 SAR 回波快速算法[J]. 电子与信息学报, 2011, 33(3): 690-695. doi: 10.3724/SP.J. 1146.2010.00555.

WANG Bingnan, ZHANG Fan, and XIANG Maosheng. SAR raw signal fast algorithm in mixed domain[J]. Journal of Electronics Information Technology, 2011, 33(3): 690-695. doi: 10.3724/SP.J.1146.2010.00555.

梁毅, 王虹现, 邢孟道, 等. 调频连续波SAR慢速动目标参数估计与成像[J]. 系统工程与电子技术, 2011, 33(5): 1001-1006. doi: 10.3969/j.issn.1001-506.2011.05.08.

LIANG Yi, WANG Hongxian, XING Mengdao, et al. Slow ground moving target parameter estimation and imaging in FMCW SAR[J]. Systems Engineering and Electronics, 2011, 33(5): 1001-1006. doi: 10.3969/j.issn.1001-506.2011.05.08.

耿淑敏, 李星. FM-CW SAR动目标检测算法研究[J]. 计算机工程与应用, 2012, 48(9): 120-123. doi: 10.3778/j.issn.1002- 8331.2012.09.035.

GENG Shumin and LI Xing. Study on moving target detection algorithm for FM-CW SAR[J]. Computer Engineering and Applications, 2012, 48(9): 120-123. doi: 10.3778/j.issn.1002-8331.2012.09.035.

WANG R, LOFFELD O, NIES H, et al. Focus FMCW SAR data using wavenumber domain algorithm[J]. IEEE Transactions on Geoscience Remote Sensing, 2010, 48(4): 2109-2118.

CARRARA W G, GOODMAN R S, MAJEWSKI R M, et al. Spotlight Synthetic Aperture Radar Signal Processing Algorithms [M]. Boston, MA: Artech House, 1995: 501-505.

FRANCESCHETTI G and LANARI R. Synthetic Aperture Radar Processing[M]. Boca Raton, FL: CRC Press, 1999: 204-207.

CUMMING I G and WONG F H. Digital Processing of Synthetic Aperture Radar Data Algorithms and Implementation[M]. Norwood, MA: Artech House, 2005: 608-611.
