基于背景差分法的单通道圆迹SAR动目标检测算法研究

洪文; 申文杰; 林赟; 鲍慊

doi:10.11999/JEIT161300

基于背景差分法的单通道圆迹SAR动目标检测算法研究

doi: 10.11999/JEIT161300

基金项目:

国家自然科学基金(61431018)

计量
- 文章访问数: 1187
- HTML全文浏览量: 196
- PDF下载量: 345
- 被引次数: 0
出版历程
- 收稿日期: 2016-12-01
- 修回日期: 2017-04-20
- 刊出日期: 2017-09-19

Single Channel Circular SAR Moving Targets Detection Based on Background Subtraction Algorithm

Funds:

The National Natural Science Foundation of China (61431018)

摘要

摘要: 圆迹SAR(CSAR)作为一种新的对地高分辨率成像方法，兼具长时间观测以及获得目标全向信息的优势。该文利用其长时间观测的特性，针对单通道圆迹SAR提出一种新的图像域动目标检测算法。首先从等多普勒等距离角度分析了动目标信号模型，后给出动目标检测算法。该方法将原始图像分为无动目标的背景以及含有动目标的前景图像，由于静止背景较动目标变化缓慢，故利用中值滤波器对重叠子孔径图像序列沿时间维进行滤波以获得背景图像，再利用每帧原始图像与背景图像的差来获得相应的含有动目标的前景图像。机载圆迹SAR数据处理结果说明了该方法的有效性。
- 圆迹SAR /
- 动目标检测 /
- 背景差分法
Abstract: As a new high resolution ground imaging technique, Circular Synthetic Aperture Radar (CSAR) is capable of long time observation and retrieving the information of the targets. By taking the long time observation advantage, a new moving target detecting method is developed based on the single channel CSAR. Moving target signal model is analyzed with equal range equal Doppler equations, then the method is described. This method regards the original SAR image as combination of two images, one is background without moving target, the other one is foreground with moving target. Because the stationary background changes slower than the moving target signal. Thus median filter can be applied to a sequence of overlapping subaperture SAR images along the time to generate the background image. Next, each original frame is used to subtract the background image. Then the moving targets can be obtained. The proposed method is demonstrated on airborne CSAR moving targets dataset.
- Circular Synthetic Aperture Radar (CSAR) /
- Moving Target Identification (MTI) /
- Background subtraction

HTML全文

参考文献(15)

CUMMING I G and WONG F H. Digital Processing of Synthetic Aperture Radar Data Algorithms and Implementation[M]. Norwood, MA, US, Artech House Inc, 2005, Chapter 1.

PONCE O, IROALA P P, SCHEIBER R, et al. First airborne demonstration of holographic SAR tomography with fully polarimetric multicircular acquisitions at L-band[J]. IEEE Transactions on Geoscience and Remote Sensing, 2016, 54(10): 6170-6196. doi: 10.1109/TGRS.2016.2582959.

PONCE O, IROALA P P, PINHEIRO M, et al. Fully polarimetric high-resolution 3-D imaging with circular SAR at L-band[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(6): 3074-3090. doi: 10.1109/TGRS. 2013. 2269194.

PALM S, ORIOT H M, and CANTALLOUBE H M. Radargrammetric DEM extraction over urban area using circular SAR imagery[J]. IEEE Transactions on Geoscience and Remote Sensing, 2012, 50(11): 4720-4725. doi: 10.1109 /TGRS.2011.2166081.

FROLIND P, GUSTAVSSON A, LUNDBERG M, et al. Circular-aperture VHF-band synthetic aperture radar for detection of vehicles in forest concealment[J]. IEEE Transactions on Geoscience and Remote Sensing, 2012, 50(4): 1329-1339. doi: 10.1109/TGRS.2011.2166081.

LIN Yun, HONG Wen, TAN Weixian, et al. Airborne circular SAR imaging: Results at P-band[C]. IEEE International Geoscience Remote Sensing Symposium, Munich, Germany, 2012: 3074-3090. doi: 10.1109/IGARSS.2012.6352051.

RANEY R K. Synthetic aperture imaging radar and moving targets[J]. IEEE Transactions on Aerospace and Electronic Systems, 1971, AES-7(3): 499-505. doi: 10.1109/TAES.1971. 310292.

FIENUP J R. Detecting moving targets in SAR imagery by focusing[J]. IEEE Transactions on Aerospace and Electronic Systems, 2001, 37(3): 794-809. doi: 10.1109/7.953237.

MAKHOUL E, BAUMGARTNER S V, JAGER M, et al. Multichannel SAR-GMTI in maritime scenarios with F-SAR and TerraSAR-X sensors[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 2015, 8(11): 5052-5067. doi: 10.1109/JSTARS.2015.2438898.

PERLOVSKY L, ILIN R, DEMING R, et al. Moving target detection and characterization with circular SAR[C]. IEEE Radar Conference, Washington, DC, USA, 2010: 661-666. doi: 10.1109/RADAR.2010.5494540.

POISSON J-B, ORIOT H M, and TUPIN F. Ground moving target trajectory reconstruction in single-channel circular SAR[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(4): 1976-1984. doi: 10.1109/TGRS.2014. 2351419.

DEMING R, BEST M, and FARRELL S. Simultaneous SAR and GMTI using ATI/DPCA[C]. Proceedings of Society of Photo-Optical Instrumentation Engineers, Baltimore, Maryland, USA, 2014, 90930U-90930U-19. doi: 10.1117/12. 2058264.

ZHAO Yue, LIN Yun, HONG Wen, et al. Adaptive imaging of anisotropic target based on circular-SAR[J]. Electronics Letters, 2016, 52(16): 1406-1408. doi: 10.1049/el.2016.1764.

JAO J K. Theory of synthetic aperture radar imaging of a moving target[J]. IEEE Transactions on Geoscience and Remote Sensing, 1991, 39(9): 1984-1992. doi: 10.1109/36. 951089.

SCARBOROUG S M, CASTEEL Jr C H, GORHAM L, et al. A challenge problem for SAR-based GMTI in urban environments[C]. Proceedings of Society of Photo-Optical Instrumentation Engineers, Orlando, Florida, USA, 2009: 73370G-73370G-10. doi: 10.1117/12.823461.
