一种脉冲超宽带测控信号捕获方法

廉昕; 王元钦; 侯孝民; 孟祥利

doi:10.11999/JEIT161213

一种脉冲超宽带测控信号捕获方法

doi: 10.11999/JEIT161213

计量
- 文章访问数: 1154
- HTML全文浏览量: 89
- PDF下载量: 343
- 被引次数: 0
出版历程
- 收稿日期: 2016-11-09
- 修回日期: 2017-02-08
- 刊出日期: 2017-08-19

Acquisition Scheme for Impulse Radio UWB TTC Signal

摘要

摘要: 脉冲超宽带测控系统作为一种航天测控新体制，可有效提高系统的隐蔽性和抗干扰性。该文针对脉冲超宽带测控信号的捕获问题，提出利用基于部分匹配滤波与快速傅里叶变换(Partial Matched Filtering and Fast Fourier Transform, PMF-FFT)的捕获方法完成对脉冲相位、伪码相位和多普勒频率的3维捕获。又针对搜索空间大、捕获时间长和多普勒频率估计精度低的问题，提出了一种改进的捕获方法。该方法采用两步捕获法对时延相位进行捕获，同时利用修正的Rife算法对多普勒频率进行进一步精细估计。仿真结果表明，该方法可有效提高捕获速度，减小捕获时间，且能显著提高多普勒频率估计精度。
- 脉冲超宽带 /
- 测控 /
- 捕获 /
- 多普勒频率 /
- Rife算法
Abstract: The impulse radio Ultra-WideBand (UWB) Tracking, Telemetry, and Command (TTC) system is a new kind of TTC system that can greatly improve the concealment and anti-interference performance. To solve the acquisition problem of the impulse radio UWB TTC signal, an acquisition scheme based on Partial Matched Filtering and Fast Fourier Transform (PMF-FFT) is proposed to accomplish the three-dimensional acquisition of pulse phase, pseudorandom code phase and Doppler frequency simultaneously. Then, according to the problem of excessive search space, long acquisition time and low estimation accuracy of Doppler frequency, a new improved acquisition scheme is proposed. It adopts the two-step scheme to accomplish time delay phase acquisition, and uses the modified Rife algorithm to further estimate the Doppler frequency. Simulation results show that this scheme can effectively improve the acquisition speed, reduce the acquisition time, and greatly improve the estimation accuracy of Doppler frequency.
- Impulse radio UWB /
- Tracking, Telemetry, and Command (TTC) /
- Acquisition /
- Doppler frequency /
- Rife algorithm

HTML全文

参考文献(21)

雷厉, 朱勤专. 飞行器测控通信技术发展趋势与建议[J]. 飞行器测控学报, 2014, 33(6): 463-468. doi: 10.7642/j.issn. 1674-5620.2014-06-0463-06.

LEI Li and ZHU Qinzhuan. Analysis of the trend of development of spacecraft TTC and communication technologies and suggestions[J]. Journal of Spacecraft TTC Technology, 2014, 33(6): 463-468. doi: 10.7642/j.issn.1674- 5620.2014-06-0463-06.

WANG F, ZHANG X, WANG F, et al. Joint estimation of TOA and DOA in IR-UWB system using a successive propagator method[J]. International Journal of Electronics, 2015, 102(10): 1765-1788. doi: 10.1080/00207217.2014. 996781.

AEDUDODLA S R, VIJAYAKUMARAN S, and WONG T F. Timing acquisition in ultra-wideband communication systems[J]. IEEE Transactions on Vehicular Technology, 2005, 54(5): 1570-1583. doi: 10.1109/TVT.2005.855495.

JOUNG Y B, CHONG D, YOON S, et al. A generalized analysis for search strategies in UWB signal acquisition[C]. International Conference on Advanced Communication Technology, Gangwon-Do, Korea, 2007, 612-614. doi: 10.1109 /ICACT.2007.358430.

HOMIER E A and SCHOLTZ R A. Rapid acquisition of ultra-wideband signals in the dense multipath channel[C]. 2002 IEEE Conference on Ultra Wideband Systems and Technologies, Baltimore, MD, USA, 2002, 105-109. doi: 10.1109/UWBST.2002.1006329.

VIJAYAKUMARAN S and WONG T F. A search strategy for ultra-wideband signal acquisition[J]. IEEE Transactions on Communications, 2015, 53(12): 2015-2019. doi: 10.1109 /TCOMM.2005.860074.

SAGHAFI A and FAKHRAIE S M. A new search space reduction technique for acquisition of UWB signals in multipath channels[C]. 2007 IEEE 65th Vehicular Technology Conference, Dublin, Ireland, 2007: 1559-1563. doi: 10.1109/ VETECS.2007.325.

IBRAHIM J and BUEHRER R M. Two-stage acquisition for UWB in dense multipath[J]. IEEE Journal on Selected Areas in Communications, 2006, 24(4): 801-807. doi: 10.1109/JSAC. 2005.863832.

CONROY J T, LOCICERO J L, and UCCI D R. Communication techniques using monopulse waveforms[C]. IEEE Military Communications Conference 1999, Atlantic City, NJ, USA, 1999: 1181-1185. doi: 10.1109/MILCOM.1999. 821389.

廉昕, 王元钦, 侯孝民, 等. 脉冲超宽带信号测量性能分析[J].飞行器测控学报, 2015, 34(5): 427-437. doi: 10.7642/j.issn. 1674-5620.2015-04-0427-11.

LIAN Xin, WANG Yuanqin, HOU Xiaomin, et al. Analysis of the measuring performance of UWB signals[J]. Journal of Spacecraft TTC Technology, 2015, 34(5): 427-437. doi: 10.7642/j.issn.1674-5620.2015-04-0427-11.

SPANGENBERG S M, SCOTT I, MCLAUGHLIN S, et al. An FFT-based approach for fast acquisition in spread spectrum communication systems[J]. Wireless Personal Communications, 2000, 13(1): 27-56. doi: 10.1023/A: 1008848916834.

QI J, LUO F, and SONG Q. Fast acquisition method of navigation receiver based on folded PMF-FFT[C]. Proceedings of 2014 IEEE Computing, Communications and IT Applications Conference, Beijing, China, 2014: 62-66. doi: 10.1109/ComComAp.2014.7017171.

MA Y, SUN H, and YUAN W. BDS/GPS satellite signal acquisition algorithm research based of PMF (Partial Matched Filter) and FFT[C]. 2015 International Conference on Network and Information Systems for Computers (ICNISC), Wuhan, China, 2015: 194-196. doi: 10.1109/ ICNISC.2015.38.

RIFE D C and VINCENT G A. Use of the discrete Fourier transform in the measurement of frequencies and levels of tones[J]. Bell Labs Technical Journal, 1970, 49(2): 197-228. doi: 10.1002/j.1538-7305.1970.tb01766.x.

LIU X, REN Y, CHU C, et al. Accurate frequency estimation based on three-parameter sine-fitting with three FFT samples[J]. Metrology Measurement Systems, 2015, 22(3): 403-416. doi: 10.1515/mms-2015-0032.

刘晓明, 张鹤, 吴皓威, 等. 高动态环境下长码扩频信号快捕算法[J]. 电子与信息学报, 2016, 38(6): 1398-1405. doi: 10. 11999/JEIT150860.

LIU Xiaoming, ZHANG He, WU Haowei, et al. Rapid DSSS signal acquisition algorithm under high dynamic environment [J]. Journal of Electronics Information Technology, 2016, 38(6): 1398-1405. doi: 10.11999/JEIT150860.

冯文全, 刘曦, 李春升. 扩频测控体制信号捕获方法分析[J]. 北京航空航天大学学报, 2013, 39(9): 1150-1156.

FENG Wenquan, LIU Xi, and LI Chunsheng. Analysis on acquisition method in spread spectrum TTC system[J]. Journal of Beijing University of Aeronautics and Astronautics, 2013, 39(9): 1150-1156.
