基于运动补偿的弹载前斜视SAR成像算法

张延; 张林让; 唐世阳

doi:10.11999/JEIT161006

基于运动补偿的弹载前斜视SAR成像算法

doi: 10.11999/JEIT161006

基金项目:

国家自然科学基金(61601343, 61671361)

计量
- 文章访问数: 1284
- HTML全文浏览量: 105
- PDF下载量: 290
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-30
- 修回日期: 2016-11-24
- 刊出日期: 2016-12-19

Novel Missile-borne Forward-looking SAR Algorithm Based on Motion Compensation

Funds:

The National Natural Science Foundation of China (61601343, 61671361)

摘要

摘要: 曲线轨迹下的弹载合成孔径雷达(SAR)前视成像算法校正了方位时不变运动误差，忽略了时变运动误差，造成成像质量下降。针对这一问题，该文提出一种基于运动补偿的前斜视成像算法。首先将加速度分解成前向加速度和径向加速度，然后将径向加速度分解为成像平面内的加速度和垂直于成像平面的加速度，经过分析可知，对成像质量起决定作用的是成像平面内的加速度，该文通过矢量方法将其补偿。此外，对于加速度带来的较大的距离徙动，通过级数反演法求出信号的2维频谱，然后结合非线性频调变标(NCS)算法进行校正，取得了良好的效果。最后通过仿真实验证明了所提算法的有效性。
- 运动补偿 /
- 曲线轨迹 /
- 弹载 /
- 非线性频调变标算法 /
- 级数反演法
Abstract: For missile-borne forward-looking SAR in curve trajectory, time-variant motion errors are ignored, leading to degradations in imaging result. This paper proposes a missile-borne forward-looking SAR algorithm based on motion compensation to solve the above problem. The acceleration is divided into forward-looking acceleration and cross-track acceleration, the second phase error and cubic phase error caused by these two accelerations are analyzed in detail. For the cross-track acceleration component, it can be divided into the acceleration vertical to the imaging plane and the one in imaging plane further. Via such dividing, the phase errors caused by acceleration are compensated by using vectorial methods. Moreover, for range migration, it is compensated through Nonlinear Chirp Scaling (NCS) approach based on the accurate 2-D spectrum acquired by the Method of Series Reversion (MSR). The simulated results are given to illustrate the validity of the proposed algorithm.
- Motion compensation /
- Curve trajectory /
- Missile-borne /
- Nonlinear Chirp Scaling (NCS) algorithm /
- Method of Series Reversion (MSR)

HTML全文

参考文献(23)

庞礡, 代大海, 邢世其, 等. 前视SAR成像技术的发展和展望[J]. 系统工程与电子技术, 2013, 35(11): 2283-2290. doi: 10.3969/j.issn.1001-506X.2013.11.09.

PANG Bo, DAI Dahai, XING Shiqi, et al. Development and perspective of forward-looking SAR imaging technique[J]. Systems Engineering and Electronics, 2013, 35(11): 2283-2290. doi: 10.3969/j.issn.1001-506X.2013.11.09.

黎剑兵, 张双喜, 苏大亮, 等. 一种多普勒域走动校正的斜视SAR成像算法[J]. 宇航学报, 2016, 37(1): 118-126. doi: 10.3873/j.issn.1000-1328.2016.01.015.

LI Jianbing, ZHANG Shuangxi, SU Daliang et al. A squint SAR imaging algorithm for linear range cell migration correction in Doppler domain[J]. Journal of Astronautics, 2016, 37(1): 118-126. doi: 10.3873/j.issn.1000-1328.2016.01. 015.

梁颖, 张群, 杨秋, 等. 基于改进NCS算法的弹载FMCW SAR大斜视成像方法[J]. 系统工程与电子技术, 2016, 38(8): 1764-1770. doi: 10.3969/j.issn.1001-506X.2016.08.09.

LIANG Ying, ZHANG Qun, YANG Qiu, et al . Study on the high squint imaging method for missile-borne FMCW SAR based on extended NCS algorithm[J]. Systems Engineering and Electronics, 2016, 38(8): 1764-1770. doi: 10.3969/j.issn. 1001-506X.2016.08.09.

CUMMING I G and WONG F. Digital Processing of Synthetic Aperture Radar: Algorithms and Implemention[M]. Norwood, MA: Artech House, 2005, Chapters 1-4.

YI Yusheng, ZHANG Linrang, LI Yan, et al. Range Doppler algorithm for bistatic missile-borne forward-looking SAR[C]. 2nd Asian-pacific Conference on Synthetic Aperture Radar Proceedings, Xian, China, 2009, 4: 960-963. doi: 10.1109/ APSAR.2009.5374268.

孟自强, 李亚超, 刑孟道, 等. 基于斜距等效的弹载双基前视SAR相位空变校正方法[J]. 电子与信息学报, 2016, 38(3): 613-621. doi: 10.11999/JEIT150782.

MENG Ziqiang, LI Yachao, XING Mengdao, et al. Phase space-variance correction method for missile-borne bistatic forward-looking SAR based on equivalent range equation[J]. Journal of Electronics Information Technology, 2016, 38(3): 613-621. doi: 10.11999/JEIT150782.

HEE S S and JONG T L. Omega-K algorithm for airborne forward-looking spotlight SAR imaging[J]. IEEE Geoscience and Remote Sensing Letters, 2009, 6(2): 312-316. doi: 10.1109/LGRS.2008.2011924.

LI Wenchao, YANG Jianyu, HUANG Yulin, et al. A geometry-based Doppler centroid estimator for bistatic forward-looking SAR[J]. IEEE Geoscience and Remote Sensing Letters, 2012, 9(3): 388-392. doi: 10.1109/LGRS. 2011.2170151.

孟自强, 李亚超, 邢孟道, 等. 弹载双基前视SAR扩展场景成像算法设计[J]. 西安电子科技大学学报(自然科学版), 2016, 43(3): 31-37. doi: 10.3969/j.issn.1001-2400.2016.03.006.

MENG Ziqiang, LI Yachao, XING Mengdao, et al. Imaging method for the extended scene of missile-borne bistatic forward-looking SAR[J]. Journal of Xidian University (Natural Science), 2016, 43(3): 31-37. doi: 10.3969/j.issn. 1001-2400.2016.03.006.

REN Xiaozhen, SUN Jiantao, YANG Ruliang, et al. A new three-dimensional imaging algorithm for airborne forward-looking SAR[J]. IEEE Geoscience and Remote Sensing Letters, 2011, 8(1): 153-157. doi: 10.1109/LGRS. 2010.2055035.

包敏, 周鹏, 史林. 双天线前视弹载SAR解模糊算法研究[J]. 电子与信息学报, 2013, 35(12): 2857-2862. doi: 10.3724/ SP.J.1146.2013.00083.

BAO Min, ZHOU Peng, and SHI Lin. Study on deambiguity algorithm for double antenna forward looking missile borne SAR[J]. Journal of Electronics Information Technology, 2013, 35(12): 2857-2862. doi: 10.3724/SP.J.1146.2013.00083.

陈琦, 杨汝良. 机载前视合成孔径雷达Chirp Scaling成像算法研究[J]. 电子与信息学报, 2008, 30(1): 228-232. doi: 10.3724/SP.J.1146.2006.00747.

CHEN Qi and YANG Ruliang. Research of chirp scaling algorithm for airborne forward-looking SAR[J]. Journal of Electronics Information Technology, 2008, 30(1): 228-232. doi: 10.3724/SP.J.1146.2006.00747.

刘高高, 张林让, 刘昕, 等. 一种曲线轨迹下的大场景前斜视成像算法[J]. 电子与信息学报, 2011, 33(3): 628-633. doi: 10.3724/SP.J.1146.2010.00575.

LIU Gaogao, ZHANG Linrang, LIU Xin, et al. Missile-borne large region squint SAR algorithm based on a curve trajectory[J]. Journal of Electronics Information Technology, 2011, 33(3): 628-633. doi: 10.3724/SP.J.1146. 2010.00575.

NEO Y L, WONG F, and CUMMING I G. A two- dimensional spectrum for bistatic SAR processing using series reversion[J]. IEEE Geoscience and Remote Sensing Letters, 2007, 4(1): 93-96. doi: 10.1109/LGRS.2006.885862.

DAVIDSON G W, CUMMING I G, and ITO M R. A chirp scaling approach for processing squint mode SAR data[J]. IEEE Transactions on Aerospace and Electronic Systems, 1996, 32(1): 121-133. doi: 10.1109/7.481254.
