平面变压器在空间行波管中的应用

赵斌; 王刚; 王东蕾

doi:10.11999/JEIT160911

平面变压器在空间行波管中的应用

doi: 10.11999/JEIT160911

2.
(中国科学院电子学研究所空间行波管研究发展中心北京 100190) ②(中国科学院大学北京 100039)

计量
- 文章访问数: 1235
- HTML全文浏览量: 103
- PDF下载量: 386
- 被引次数: 0
出版历程
- 收稿日期: 2016-09-09
- 修回日期: 2017-02-22
- 刊出日期: 2017-06-19

Application of Planar Transformers for Space Travelling-wave Tube Amplifiers

2.
(Space Travelling-wave Tube Research Center, Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

摘要

摘要: 平面变压器具有小体积、高功率密度以及热特性好的特点，在低压领域得到了广泛应用。该文研究了将平面变压器应用于行波管电源中，从而达到减小电源体积，提高电源功率密度的目的。结合行波管电源常用的LCLC谐振拓扑，采用部分交错绕组结构设计了一种平面变压器，并进行了电路仿真和实际测试，仿真结果与实测结果一致。采用该平面变压器的LCLC谐振变换器，输入电压为40 V，输出电压为4800 V，输出功率为295 W，开关频率为500 kHz。仿真结果与实验结果均表明，采用平面变压器，可以提高开关频率，缩小电源体积，提高功率密度，从而降低整个行波管放大器的体积和重量。
- 空间行波管放大器 /
- LCLC谐振变换器 /
- 平面变压器 /
- 开关频率
Abstract: Planar transformers are widely used in low-voltage applications because of the advantages of low profile, high power density and excellent thermal characteristics. This paper applies the planar transformer for power supplies to Travelling-Wave Tube Amplifiers (TWTAs). Based on the LCLC topology, which is always used in TWTAs, a planar transformer with an interleaved structure is designed. In addition, the experimental results are in accordance with the simulation results. The input voltage of the converter is 40 V, the output voltage is 4800 V, the output power is 295 W and the switching frequency is 500 kHz. Conclusions can be drawn that with the planar transformers, the switching frequency can be increased and the volume of the power supplies can be reduced.
- Space Travelling-Wave Tube Amplifiers (TWTAs) /
- LCLC resonant converter /
- Planar transformer /
- Switching frequency

HTML全文

参考文献(20)

胡银富, 冯进军. 用于雷达的新型真空电子器件[J]. 雷达学报, 2016, 5(4): 350-360. doi: 10.12000/JR16078.

HU Yinfu and FENG Jinjun. New vacuum electronic devices for radar[J]. Journal of Radars, 2016, 5(4): 350-360. doi: 10. 12000/JR16078.

ZUBORAJ M, NAHAR N K, and VOLAKIS J L. An S-band high power traveling wave tube for RADAR application[C]. Radio Science Meeting (Joint with AP-S Symposium), Memphis, USA, 2014, 81-81. doi: 10.1109/USNC-URSI.2014. 6955463.

LIU Yawei and SU Xiao-bao. High power and efficiency power combining of space TWTAs with waveguide magic-T for satellite communication[C]. Vacuum Electronics Conference (IVEC), Beijing, 2015: 1-2. doi: 10.1109/IVEC. 2015.7223941.

刘洁, 胡波雄, 王刚, 等. 一种适用于Ku波段行波管放大器的预失真线性化器[J]. 电子与信息学报, 2014, 36(10): 2515-2520. doi: 10.3724/SP.J.1146.2013.01820.

LIU Jie, HU Boxiong, WANG Gang, et al. A predistortion linearizer for Ku-band traveling-wave tube amplifier[J]. Journal of Electronics Information Technology, 2014, 36(10): 2515-2520. doi: 10.3724/SP.J.1146.2013.01820.

LIU Jie, ZHANG Huadong, and LI Zengliang. A novel two-branch predistortion linearizer of Ku-band TWTA in communication applications[C]. IET International Radar Conference, Hangzhou, China, 2015: 1-8. doi: 10.1049/cp. 2015.1172.

BLANES J M, GARRIGOS A, GUTIERREZ R, et al. Evaluation of gallium nitride transistors in electronic power conditioners for TWTAs[C]. IEEE Aerospace Conference, MT USA, 2015: 1-8. doi: 10.1109/AERO.2015.7119140.

PEQUET E, DEPORTE P, FAYT P, et al. ESA qualified EPC for telecommunication satellites TWTA[C]. Vacuum Electronics Conference, Monterey CA, 2000: 1-2. doi: 10.1109 /OVE:EC.2000.847524.

BARBI I and GULES R. Isolated DC-DC converters with high-output voltage for TWTA telecommunication satellite applications[J]. IEEE Transactions on Power Electronics, 2003, 18(4): 975-984. doi: 10.1109/TPEL.2003.813762.

OUYANG Z and ANDERSON M A E. Overview of planar magnetic technologyfundamental properties[J]. IEEE Transactions on Power Electronics, 2014, 29(9): 4888-4900. doi: 10.1109/TPEL.2013.2283263.

OUYANG Z, ZHANG Z, THOMSEN O C, et al. Planar- Integrated Magnetics (PIM) module in hybrid bidirectional DC-DC converter for fuel cell application[J]. IEEE Transactions on Power Electronics, 2011, 26(11): 3254-3264. doi: 10.1109/TPEL.2011.2129598.

ZHANG J, HURLEY W G, and WOLFLE W H. Optimized design of LLC resonant converters incorporating planar magnetics[C]. Applied Power Electronics Conference and Exposition, Long Beach, CA, USA, 2013: 1683-1688. doi: 10.1109/APEC.2013.6520523.

ZHAO Bin, WANG Gang, HURLEYW G, et al. An interleaved structure for a high-voltage planar transformer for a travelling-wave tube[C]. International Power Electronics and Motion Control Conference, Hefei, 2016: 3695-3701. doi: 10.1109/IPEMC.2016.7512887.

HABIBINIA D and FEYZI M R. Optimal winding design of a pulse transformer considering parasitic capacitance effect to reach best rise time and overshoot[J]. IEEE Transactions on Dielectrics and Electrical Insulation, 2014, 21(3): 1350-1359. doi: 10.1109/TDEI.2014.6832283.

FU Dianbo, WANG S, KONG Pengju, et al. Novel techniques to suppress the common-mode EMI noise caused by transformer parasitic capacitances in DC-DC converters[J]. IEEE Transactions on Industrial Electronics, 2013, 60(11): 4968-4977. doi: 10.1109/TIE.2012.2224071.

BIELA J and KOLAR J W. Using transformer parasitics for resonant convertersA review of the calculation of the stray capacitance of transformers[J]. IEEE Transactions on Industry Applications, 2008, 44(1): 223-233. doi: 10.1109/ TIA.2007.912722.

OUYANG Z, ZHANG J, and HURLEY W G. Calculation of leakage inductance for high-frequency transformers[J]. IEEE Transactions on Power Electronics, 2015, 30(10): 5769-5775. doi: 10.1109/TPEL.2014.2382175.

ZHANG J, OUYANG Z, DUFFY M, et al. Leakage inductance calculation for planar transformers with a magnetic shunt[J]. IEEE Transactions on Industry Application, 2014, 50(6): 4107-4112. doi: 10.1109/TIA.2014. 2322140.

BAHMANI M A and THIRINGER T. Accurate evaluation of leakage inductance in high-frequency transformers using an improved frequency-dependent expression[J]. IEEE Transactions on Power Electronics, 2015, 30(10): 5738-5745. doi: 10.1109/TPEL.2014.2371057.
