基于共形稀疏阵列的艇载外辐射源雷达性能分析

周建卫; 李道京; 田鹤; 潘洁; 胡烜

doi:10.11999/JEIT160846

基于共形稀疏阵列的艇载外辐射源雷达性能分析

doi: 10.11999/JEIT160846

2.
(中国科学院电子学研究所北京 100190) ②(中国科学院大学北京 100049)

基金项目:

国家自然科学基金(61271422)，所创新项目

计量
- 文章访问数: 1480
- HTML全文浏览量: 220
- PDF下载量: 335
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-16
- 修回日期: 2016-11-11
- 刊出日期: 2017-05-19

Performance Analysis on Airship-borne Passive Radar Based on Conformal Sparse Array

2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

The National Natural Science Foundation of China (61271422), Institute Innovation Project

摘要

摘要: 该文研究了共形稀疏阵列在艇载外辐射源雷达中的应用问题，并分析了艇载外辐射源雷达目标探测性能。鉴于天线在雷达系统中的重要地位，重点分析了稀疏阵列数字波束形成(DBF)天线的布阵方式及天线方向图指标。基于组合巴克码实现艇身稀疏阵列共形布设，提出一种曲线阵列到直线阵列的补偿方法，以获得理想的DBF天线方向图。针对曲线阵列可能存在的形变问题，采用分布式位置和姿态测量系统(POS)进行形变误差测量，经曲线拟合后实施精确补偿。仿真结果表明所提方法的有效性。
- 外辐射源雷达 /
- 稀疏阵列 /
- 目标探测 /
- 共形天线 /
- 阵列误差测量和补偿
Abstract: The application of conformal sparse array to airship-borne passive radar is studied, and the target detection performance of airship-borne passive radar is analyzed. Because of the importance of antenna in radar system, embattle method of sparse array Digital Beam Forming (DBF) antenna and antenna pattern index are selectively analyzed. Layout of airship-borne sparse array is implemented based on the combination of Barker code. In order to obtain ideal DBF antenna pattern, a method of compensating the curve array to the linear array is proposed. With respect to the possible deformation problem, the distributed Position and Orientation System (POS) is used to measure the deformation error based on which curve fitting is implemented to conduct accurate compensation. Simulation results show the effectiveness of the proposed method.
- Passive radar /
- Sparse array /
- Target detection /
- Conformal antenna /
- Array error measurement and compensation

HTML全文

参考文献(28)

侯颖妮, 李道京, 尹建凤, 等. 基于稀疏综合孔径天线的艇载成像雷达研究[J]. 电子学报, 2008, 36(12): 2377-2382. doi: 10.3321/j.issn:0372-2112.2008.12.020.

HOU Yingni, LI Daojing, YIN Jianfeng, et al. Airship imaging radar based on aperture synthesis of thinned array[J]. Acta Electronica Sinica, 2008, 36(12): 2377-2382. doi: 10.3321/j.issn:0372-2112.2008.12.020.

CLARK T and JASKA E. Million element ISIS array[C]. IEEE International Symposium on Phased Array Systems and Technology (ARRAY), Boston, 2010: 29-36. doi: 10.1109/ARRAY.2010.5613396.

VAN BEZOUWEN H, FELDLE H, and HOLPP W. Status and trends in AESA-based radar[C]. IEEE MTT-S International Microwave Symposium Digest (MTT), California, 2010: 526-529. doi: 10.1109/MWSYM.2010. 5517507.

许群, 王云香, 刘少斌, 等. 飞行器共形天线技术综述[J]. 现代雷达, 2015, 37(9): 50-54. doi: 10.16592/j.cnki.1004-7859. 2015.09.012.

XU Qun, WANG Yunxiang, LIU Shaobin, et al. An overview on conformal antenna technology for aircraft[J]. Modern Radar, 2015, 37(9): 50-54. doi: 10.16592/j.cnki.1004-7859. 2015.09.012.

张玉洁, 龚书喜, 王文涛, 等. 基于改进遗传算法的非规则共形阵的研究[J]. 电波科学学报, 2010, 25(4): 689-695. doi: 10.3969/j.issn.1005-0388.2010.04.014.

ZHANG Yujie, GONG Shuxi, WANG Wentao, et al. Research on irregular conformal array using improved genetic algorithm[J]. Chinese Journal of Radio Science, 2010, 25(4): 689-695. doi: 10.3969/j.issn.1005-0388.2010.04.014.

李杰然, 许稼. 共形阵列信号DOA和极化状态联合估计研究[J]. 雷达科学与技术, 2015, 13(2): 159-163. doi: 10.3969/ j.issn.1672-2337.2015.02.010.

LI Jieran and XU Jia. Joint Estimation of 2D-DOA and polarization based on conformal array[J]. Radar Science and Technology, 2015, 13(2): 159-163. doi: 10.3969/j.issn.1672- 2337.2015.02.010.

GROMEK D, KULPA K, and P. Experimental results of passive SAR imaging using DVB-T illuminators of opportunity[J]. IEEE Geoscience and Remote Sensing Letters, 2016, 13(8): 1124-1128. doi: 10.1109/LGRS. 2016.2571901.

王志纲, 董鹏曙, 吴琼. 飞艇载无源雷达的外辐射源选择[J]. 雷达科学与技术, 2014, 12(1): 8-12. doi: 10.3969/j.issn.1672- 2337.2014.01.002.

WANG Zhigang, DONG Pengshu, and WU Qiong. Study on selection of external transmitters for airship-borne passive radar[J]. Radar Science and Technology, 2014, 12(1): 8-12. doi: 10.3969/j.issn.1672-2337.2014.01.002.

李烈辰. 变换域稀疏压缩感知雷达成像技术研究[D]. [博士论文], 中国科学院电子学研究所, 2015.

LI Liechen. Research on imaging technology of transform domain sparse compressed sensing radar[D]. [P.h.dissertation], Institute of Electronics, Chinese Academy of Sciences, 2015.

杨波. 一种设计组合巴克码脉冲压缩旁瓣抑制滤波器的新方法[J]. 现代雷达, 2001, 23(5): 41-45. doi: 10.3969/j.issn.1004- 7859.2001.05.012.

YANG Bo. A new method for designing range-sidelobe suppression filter for combined barker code[J]. Modern Radar, 2001, 23(5): 41-45. doi: 10.3969/j.issn.1004-7859.2001.05.012.

李烈辰, 李道京, 黄平平. 基于变换域稀疏压缩感知的艇载稀疏阵列天线雷达实孔径成像[J]. 雷达学报, 2016, 5(1): 109-117. doi: 10.12000/JR14159.

LI Liechen, LI Daojing, and HUANG Pingping. Airship sparse array antenna radar real aperture imaging based on compressed sensing and sparsity in transform domain[J]. Journal of Radars, 2016, 5(1): 109-117. doi: 10.12000/ JR14159.

鄢社锋, 马远良. 传感器阵列波束优化设计及应用[M]. 北京: 科学出版社, 2009: 169-170.

YAN Shefeng and MA Yuanliang. Design and Application of Sensor Array Beam Optimization[M]. Beijing: Science Press, 2009: 169-170.

李道京, 侯颖妮, 滕秀敏, 等. 稀疏阵列天线雷达技术及其应用[M]. 北京: 科学出版社, 2014: 100-120.

LI Daojing, HOU Yingni, TENG Xiumin, et al. Sparse Array Antenna Radar Technology and Application[M]. Beijing: Science Press, 2014: 100-120.

滕秀敏, 李道京. 艇载共形稀疏阵列天线雷达成像研究[J]. 电波科学学报, 2012, 27(4): 644-649. doi: 10.13443/j.cjors.2012. 04.015.

TENG Xiumin and LI Daojing. Airship conformal sparse array radar imaging[J]. Chinese Journal of Radio Science, 2012, 27(4): 644-649. doi: 10.13443/j.cjors.2012.04.015.

李道京, 滕秀敏, 潘舟浩. 分布式位置和姿态测量系统的概念与应用方向[J]. 雷达学报, 2013, 2(4): 400-405. doi: 10.3724/ SP.J.1300.2013.13086.

LI Daojing, TENG Xiumin, and PAN Zhouhao. The concept and applications of distributed POS[J]. Journal of Radars, 2013, 2(4): 400-405. doi: 10.3724/SP.J.1300.2013.13086.

SKOLIN M I, 王军, 林强, 等译. 雷达手册[M]. 北京: 电子工业出版社, 2003: 297-301.
