基于SRAM物理不可克隆函数的高效真随机种子发生器设计

李冰; 涂云晶; 陈帅; 吉建华

doi:10.11999/JEIT160835

基于SRAM物理不可克隆函数的高效真随机种子发生器设计

doi: 10.11999/JEIT160835

1.
(东南大学集成电路学院南京 210000) ②(深圳大学信息工程学院深圳 518060)

基金项目:

国家自然科学基金(61571116)

计量
- 文章访问数: 1177
- HTML全文浏览量: 105
- PDF下载量: 369
- 被引次数: 0
出版历程
- 收稿日期: 2016-08-15
- 修回日期: 2017-01-11
- 刊出日期: 2017-06-19

Efficient Design of Truly Random Seed Generator Based on SRAM Physical Unclonable Functions

1.
(School of Integrated Circuit, Southeast University, Nanjing 210000, China)
2.
(College of Information Engineering, Shenzhen University, Shenzhen 518060, China)

Funds:

The National Natural Science Foundation of China (61571116)

摘要

摘要: 该文设计了一种基于SRAM物理不可克隆函数(PUFs)的高效真随机种子发生器。通过将不提供熵值的稳定节点和提供低熵值的噪声节点筛除，只选用能够提供较高熵值的噪声节点来生成满熵种子，大幅降低需要处理的数据量，提高节点数据的处理效率。通过测试SRAM PUFs内部噪声节点的振荡特性，提出筛选出SRAM PUFs内部高熵值的噪声节点的最佳策略，最终基于此策略设计出真随机种子发生器。该设计可以产生128~256 bit长度的满熵的种子且处理的节点数据量只有当前方法的0.5%~4%。生成的种子满足NIST架构的随机数生成器要求，产生的伪随机数全部通过了随机数检测。与现有设计相比，该文提出的真随机种子发生器是一种高效的、适用范围较广的设计。
- 物理不可克隆函数 /
- 噪声节点 /
- 真随机种子 /
- 高效率
Abstract: An efficient design of truly random seed generator based on SRAM Physical Unclonable Functions (PUFs) is proposed in this paper. Only the noisy cells of high min-entropy are selected to generate full entropy seeds in this design. Therefore, it can reduce the amount of data to be processed significantly and improve the efficiency of seed generation. The oscillating characteristics of the noisy cells inside SRAM are measured, and screening strategies for filtering out the selected noisy cells inside the SRAM are put forward. Finally, based on the strategies, a truly random seed generator is designed, which can generate full entropy seeds. The length of seeds generated by this design is from 128 bit to 256 bit. The number of the selected cells which are used to generate seeds is from 0.5% to 4% of all SRAM cells. Compared to the current design, it is shown that the proposed design in this paper is efficient and widely applicable.
- Physical Unclonable Functions (PUFs) /
- Noisy cells /
- Truly random seed /
- Efficient

HTML全文

参考文献(15)

PAPPU R, RECHT B, TAYLOR J, et al. Physical one-way functions[J]. Science, 2002, 297(5589): 2026-2030. doi: 10.1126/science.1074376.

BARBARESCHI M, BATTISTA E, MAZZEO A, et al. Testing 90 nm microcontroller SRAM PUF quality[C]. IEEE International Conference on Design Technology of Integrated Systems in Nanoscale Era, Naples, Italy, 2015: 1-6.

HOLCOMB D E, BURLESON W P, and FU K. Power-Up SRAM state as an identifying fingerprint and source of true random numbers[J]. IEEE Transactions on Computers, 2008, 58(9): 1198-1210. doi: 10.1109/TC.2008.212.

XIAO K, RAHMAN M T, FORTE D, et al. Bit selection algorithm suitable for high-volume production of SRAM-PUF[C]. IEEE International Symposium on Hardware-Oriented Security and Trust, Arlington, Virginia, USA, 2014: 101-106.

LEEST V V D, SLUIS E V D, SCHRIJEN G J, et al. Efficient implementation of true random number generator based on SRAM PUFs[J]. Lecture Notes in Computer Science, 2012, 6805: 300-318. doi: 10.1007/978-3-642-28368-0_20.

ZHANG J, LIN Y, LYU Y, et al. A PUF-FSM binding scheme for FPGA IP protection and pay-per-device licensing[J]. IEEE Transactions on Information Forensics Security, 2015, 10(6): 1137-1150. doi: 10.1109/TIFS.2015.2400413.

DELVAUX J, GU D, SCHELLEKENS D, et al. Helper data algorithms for PUF-based key generation: Overview and analysis[J]. IEEE Transactions on Computer-Aided Design of Integrated Circuits and Systems, 2015, 34(6): 889-902. doi: 10.1109/TCAD.2014.2370531.

KIM H and HONG S. AES Sbox GF(24) inversion functions based PUFs[C]. IEEE International SoC Design Conference (ISOCC), Jeju, South Korea, 2014: 15-16.

VARCHOLA M, DRUTAROVSKY, M, and FISCHER V. New universal element with integrated PUF and TRNG capability[C]. International Conference on Reconfigurable Computing and FPGAs, Cancun, Mexico. 2013: 1-6.

HUSSAIN S U, MAJZOOBI M, and KOUSHANFAR F. A built-in-self-test scheme for online evaluation of physical unclonable functions and true random number generators[J]. IEEE Transactions on Multi-Scale Computing Systems, 2016, 2(1): 2-16. doi: 10.1109/TMSCS.2016.2519902.

LI D, LU Z, ZOU X, et al. PUFKEY: A high-security and high-throughput hardware true random number generator for sensor networks[J]. Sensors, 2015, 15(10): 26251-26266. doi: 10.3390/s151026251.

HERREWEGE V A, VINCENT V D L, SCHALLER A, et al. Secure PRNG seeding on commercial off-the-shelf microcontrollers[C]. International Workshop on Trustworthy Embedded Devices, Berlin, Germany, 2013: 55-64.

CORTEZ M, DARGAR A, HAMDIOUI S, et al. Modeling SRAM start-up behavior for physical unclonable functions[C]. IEEE International Symposium on Defect and Fault Tolerance in VLSI and Nanotechnology Systems, Austin, TX, USA, 2012: 815-828.

BARKER E and KELSEY J. Recommendation for random number generation using deterministic random bit generators[R]. NIST Special Publication, 2012: 800-890.

GUAJARDO J, KUMAR S S, SCHRIJEN G J, et al. FPGA intrinsic PUFs and their use for IP protection[C] Cryptographic Hardware and Embedded Systems, CHES 2007, International Workshop, Vienna, Austria, 2007: 63-80.
