FiWi网络比例公平和QoS感知的分级动态带宽分配机制

何蓉; 谢辉; 方旭明

doi:10.11999/JEIT160731

FiWi网络比例公平和QoS感知的分级动态带宽分配机制

doi: 10.11999/JEIT160731

基金项目:

国家自然科学基金(61471303)，国家留学基金 (20130700501)

计量
- 文章访问数: 1250
- HTML全文浏览量: 116
- PDF下载量: 336
- 被引次数: 0
出版历程
- 收稿日期: 2016-07-08
- 修回日期: 2017-03-17
- 刊出日期: 2017-06-19

Proportional Fair and QoS-aware Hierarchical Dynamic Bandwidth Allocation Scheme for Fiber-wireless Networks

Funds:

The National Natural Science Foundation of China (61471303), China Scholarship Council (20130700501)

摘要

摘要: 光纤网络和无线接入技术结合的FiWi网络可提供高容量、灵活以及低基础设施成本的无线接入能力。由于FiWi网络中客户端业务量一般具有不稳定性，很难提前有效预测，高效公平的动态带宽分配(DBA)机制具有重要作用。该文针对EPON和WLAN构成的FiWi网络提出一种分级DBA机制。引入剩余带宽比例因子解决多个轮询周期内各用户分配的带宽资源与其权值不匹配而产生的不公平问题；联合考虑业务优先级、带宽请求比例和网络负载解决带宽分配中的业务QoS保证和信道带宽浪费问题。仿真实验表明，与现有文献的DBA机制相比，系统公平性、吞吐量和信道利用率有明显提升。且所提DBA算法不限定具体带宽资源类型，具有良好通用性。
- FiWi网络 /
- 以太网无源光网络 /
- 无线局域网 /
- 动态带宽分配 /
- 比例公平 /
- QoS感知
Abstract: The integration of optical and wireless technologies, denoted as Fiber-Wireless (FiWi) networks, can provide not only high capacity but also flexible wireless access ability with less infrastructure deployment. Since data traffic generated in FiWi networks usually experiences unstable and unpredictable, it is difficult to perform traffic prediction in advance. An effective and fair Dynamic Bandwidth Allocation (DBA) scheme plays an important role. This paper proposes an upstream fair hierarchical DBA scheme for EPON-WLAN networks. Excess bandwidth proportion factor is introduced to address the unfair issue due to the unmatched problem between the allocated bandwidth resource and the assigned user weight among multiple granting cycles. On the other hand, in order to deal with the QoS guarantee and bandwidth waste issue in bandwidth allocation, we jointly taken into account of different traffic QoS priorities, bandwidth requirement proportion, and actual traffic load. Extensive simulation results show that compared with the existing DBA schemes, the proposed hierarchical DBA scheme can improve proportional fairness, throughput and channel utilization. Moreover, the proposed FiWi DBA scheme does not refer to a specific bandwidth resource types, thus obtains good generality.
- Fiber-Wireless (FiWi) network /
- Ethernet Passive Optical Network (EPON) /
- WLAN /
- Dynamic Bandwidth Allocation (DBA) /
- Proportional fairness /
- QoS-aware

HTML全文

参考文献(16)

IEEE Standard for Information Technology-Telecommunica- tions and information exchange between systems-local and metropolitan area networks-specific requirements, part11:

Wireless LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications. Amendment 3: Enhancements forvery high throughput in the 60 GHz band[S]. March 2014.

GHAZISAIDI N and MAIER M. Fiber-Wireless (FiWi) access networks: Challenges and opportunities[J]. IEEE Network. 2011, 17(1): 36-42. doi: 10.1109/MNET.2011. 5687951.

SARIGIANNIDIS A G, ILORIDOU M, NICOPOLITIDIS P, et al. Architectures and bandwidth allocation schemes for hybrid wireless-optical networks[J]. IEEE Communication Surveys Tutorials, 2015, 17(1): 427-468. doi: 10.1109/ COMST.2014.2356640.

YANG K, OU Shumao, GUILD Ken, et al. Convergence of Ethernet PON and IEEE 802.16 broadband access networks and its QoS-aware dynamic bandwidth allocation scheme[J]. IEEE Journal on Selected Areas in Communications, 2009, 27(2): 101-116. doi: 10.1109/JSAC.2009.090202.

JIANG Ling, FU MingLei, and LE Zichun. Hierarchical QoS-aware dynamic bandwidth allocation algorithm for wireless optical broadband access network[C]. International Conference on Electronics, Communications and Control, Ningbo, China, 2011: 4329-4332. doi: 10.1109/ICECC.2011. 6066634.

SARIGIANNIDIS P, LOUTA M, PAPADIMITRIOU G, et al. Alleviating the high propagation delays in FiWi networks: A prediction-based DBA scheme for 10G-EPON-WiMAX systems[C]. International Workshop on Fiber Optics in Access Network, Brno, Czechoslovakia, 2015: 45-50. doi: 10.1109/FOAN.2015.7320478.

RANAWEERA C, WONG E, LIM C, et al. Architecture discovery enabled resource allocation mechanism for next generation optical-wireless converged networks[J]. Optical Communication Network, 2013, 5(9): 1083-1095.

SARIGIANNIDIS A and NICOPOLITIDIS P. Quality- of-service-aware fair bandwidth allocation scheme for fiber wireless networks[J]. IET Networks, 2016, 5(3): 56-63. doi: 10.1049/iet-net.2015.0090.

NAM R, NM D, SK S, et al. The delay and fairness study of a centralized EPON DBA algorithm[C]. IEEE Region 10 Symposium, Kuala Lumpur, Malaysia, 2014: 301-305. doi: 10.1109/TENCONSpring.2014.6863046.

LI Yan, WANG Jianping, and QIAO Chunming. Integrated Fiber-Wireless (FiWi) access networks supporting inter-ONU communications[J]. Journal of Lightwave Technology, 2010, 28(5): 714-724. doi: 10.1109/JLT.2009.2038598.

HE Rong, XIE Hui, and FANG Xuming. A long-term proportional fair dynamic bandwidth allocation scheme for EPON[C]. The 25th Wireless and Optical Communication Conference (WOCC). Chengdu, China, 2016: 1-5. doi: 10. 1109/WOCC.2016.7506545.

MCGARRY M P, REISSLEIN M, AURZADA F, et al. Shortest Propagation Delay (SPD) first scheduling for EPONs with heterogeneous propagation delays[J]. IEEE Journal on Selected Areas in Communications, 2010, 28(6): 849-862. doi: 10.1109/JSAC.2010.100810.

VAN D P, RIMAL B Pr, MAIER M, et al. ECO-FiWi: An energy conservation scheme for integrated fiber-wireless access networks[J]. IEEE Transactions on Wireless Communications, 2016, 15 (6): 3979-3994. doi: 10.1109/ TWC.2016.2531694.

MCGARRY M P, REISSLEIN M, COLBOURN C J, et al. Just-in-time scheduling for multichannel EPONs[J]. Journal of Lightwave Technology, 2008, 26(10): 1204-1216. doi: 10. 1109/JLT.2008.919366.

HE Rong and FANG Xuming. A fair MAC scheme for EDCA based wireless networks[C]. International Conference on Testbeds and Research Infrastructures for the Development of Networks and Communities, Washington DC, USA, 2009: 1-6. doi: 10.1109/TRIDENTCOM.2009.4976242.
