基于最小二乘的短垂线阵匹配场处理

王奇; 陈航; 王英民; 苟艳妮

doi:10.11999/JEIT160727

基于最小二乘的短垂线阵匹配场处理

doi: 10.11999/JEIT160727

计量
- 文章访问数: 1085
- HTML全文浏览量: 92
- PDF下载量: 321
- 被引次数: 0
出版历程
- 收稿日期: 2016-07-08
- 修回日期: 2016-11-17
- 刊出日期: 2017-06-19

Matched Field Processing Based on the Least SquaresAlgorithm for Short Vertical Linear Array

摘要

摘要: 匹配场处理通常要求接收基阵能够覆盖整个水层，如此大尺度的布阵方式严重阻碍了该方法的广泛使用。为了缓解匹配场处理对阵形的苛刻要求，该文提出一种基于最小二乘的短垂线阵匹配场处理技术。该方法把接收阵的声场分解为模态函数矩阵和模态系数向量，并在最小范数意义下用最小二乘算法得到了各阶模态系数的估计值，在此基础上重新构造了短垂线阵的测量场向量，使得重构后的测量场包含更多的环境信息，从而提高了短垂线阵匹配场处理的性能。最后，在典型的Pekeris波导环境中进行仿真，以3种布放在水面附近的短垂线阵为例，分析了匹配场被动定位的性能，并用广义余弦量化分析了不同布阵方式对测量场的影响。结果表明：使用最小二乘算法对短阵的测量场进行声场重构后广义余弦变大，此时短垂线阵匹配场处理的定位性能得到改善，验证了该算法的有效性。
- 匹配场处理 /
- 被动定位 /
- 最小二乘算法 /
- 声场重构
Abstract: The receiver array of matched field processing usually needs to cover the whole water column, such a large arrangement of array hinders its application seriously. To overcome this shortcoming, an approach called matched field processing based on least squares algorithm is proposed, which decomposes the received fields into depth function matrixes and amplitudes of normal mode at the beginning. Then all the mode amplitudes are estimated using the least squares in the sense of minimum norm. Next, the amplitudes estimated are used to reconstruct the received fields of the short vertical linear array, which makes the reconstructed ones contain more environmental information, therefore the performance of matched field processing with short array is improved. In the end, lots of simulations with three short vertical arrays which are located near by water surface are processed in the classical Pekeris waveguide, and the performance of matched field passive localization is evaluated. Meanwhile, in order to quantify the influence of different kinds of geometrical arrangements to the received fields, the generalized cosine-squared between two vectors is used. The results show that when the received fields of short array are reconstructed using the least squares, the generalized cosine-squared is larger obviously, finally the performance of matched field passive localization with short array is improved and the proposed algorithm is proved to be effective.
- Matched field processing /
- Passive localization /
- Least square algorithm /
- Acoustic fields reconstructed

HTML全文

参考文献(23)

BAGGEROER A B, KUPERMAN W A, and MLKHALEVSKY P N. An overview of matched field methods in ocean acoustics[J]. IEEE Journal of Oceanic Engineering, 1993, 18(4): 401-424. doi: 10.1109/48.262292.

KUPERMAN W A. An overview of beamforming, matched-field processing, and time reversal techniques[J]. The Journal of the Acoustical Society of America, 2016, 139(4): 2081. doi: 10.1121/1.4950176.

DONG H, BADIEY M, and ChAPMAN R. Matched mode geoacoustic inversion of broadband signals in shallow water [J]. The Journal of the Acoustical Society of America, 2015, 137(4): 2390. doi: 10.1121/1.4920698.

罗新禹, 李建, 周德富, 等. 失配情况下匹配模处理方法研究 [J]. 应用声学, 2016, 35(2): 172-178. doi: 10.11684/j.issn. 1000-310X.2016.02.012.

LUO Xinyu, LI Jian, ZHOU Defu, et al. Simulation studies of the matched-mode processing for locating underwater sound sources[J]. Journal of Applied Acoustics, 2016, 35(2): 172-178. doi: 10.11684/j.issn.1000- 310X.2016.02.012.

HARRISON B F, VACCARO R J, and TUFTS D W. Robust broadband matched-field localization: Results for a short, sparse vertical array [J]. The Journal of the Acoustical Society of America, 1999, 106(1): 515-517. doi: 10.1121/1.427072.

GEMBA K L, HODGKISS W S, and GERSTOFT P. Single and multiple snapshot compressive matched field processing [J]. The Journal of the Acoustical Society of America, 2015, 138(3): 1928. doi: 10.1121/1.4934072.

彭水, 袁蓉, 徐国贵. 浅海水平固定阵阵形对匹配场定位性能的影响[J]. 舰船科学技术, 2015, 37(9): 121-126. doi: 10.3404/j.issn.1672-7649.2015.09.024.

PENG Shui, YUAN Rong, and XU Guogui. Localization performance of different horizontal hydrophone array shape for matched field processing in shallow sea[J]. Ship Science and Technology, 2015, 37(9): 121-126. doi: 10.3404/j.issn. 1672-7649.2015.09.024.

TABRIKIAN J, KROLIK J L, and MESSER H. Robust maximum-likelihood source localization in an uncertain shallow-water waveguide[J]. The Journal of the Acoustical Society of America, 1997, 101(1): 241-249.

MICHALOPOULOU Z H and PORTER M B. Matched-field processing for broad-band source localization[J]. IEEE Journal of Oceanic Engineering, 1996, 21(4): 384-392. doi: 10.1109/48. 544049.

ORRIS G J, NICHOLAS M, and PERKINS J S. The matched-phase coherent multi-frequency matched-field processor[J]. The Journal of the Acoustical Society of America, 2000, 107(5): 2563-2575. doi: 10.1121/1.428644.

WILSON G R, KOCH R A, and VIDMAR P J. Matched mode localization[J]. The Journal of the Acoustical Society of America, 1988, 84(1): 310-320. doi: 10.1121/1.396987.

YANG T C. A method of range and depth estimation by modal decomposition[J]. The Journal of the Acoustical Society of America, 1987, 82(5): 1736-1745. doi: 10.1121/ 1.395825.

TOLLEFSEN D and DOSSO S E. Matched-field source localization with multiple small-aperture arrays[J]. The Journal of the Acoustical Society of America, 2015, 138(3): 1754-1754. doi: 10.1121/1.4933543.

Porter M B and Tolstoy A. The matched field processing benchmark problems [J]. Journal of Computational Acoustics, 1994, 2(3): 161-185. doi: 10.1142/S0218396X94000129.

YANG T C. Data-based matched-mode source localization for a moving source[J]. The Journal of the Acoustical Society of America, 2014, 135(3): 1218-1230. doi: 10.1121/1.4863270.

赵拥军, 赵勇胜, 赵闯. 基于正则化约束总体最小二乘的单站DOA-TDOA无源定位算法[J]. 电子与信息学报, 2016, 38(9): 2336-2343. doi: 10.11999/JEIT151379.

ZHAO Yongjun, ZHAO Yongsheng, and ZHAO Chuang. Single-observer passive DOA-TDOA location based on regularized constrained total least squares[J]. Journal of Electronics Information Technology, 2016, 38(9): 2336-2343. doi: 10.11999/JEIT151379.

WU H, CHEN S, ZHANG Y, et al. Robust structured total least squares algorithm for passive location[J]. Journal of Systems Engineering and Electronics, 2015, 26(5): 946-953. doi: 10.1109/JSEE.2015.00103.

GOLUB G H and VAN LOAN C F. An analysis of the total least squares problem[J]. SIAM Journal on Numerical Analysis, 1980, 17(6): 883-893. doi: 10.1137/0717073.

王奇, 王英民, 苟艳妮. 稳健的条件概率约束匹配场处理[J]. 电子与信息学报, 2014, 36(10): 2425-2430. doi: 10.3724/SP.J. 1146.2014.00027.

WANG Qi, WANG Yingmin, and GOU Yanni. Robust conditional probability constraint matched field processing[J]. Journal of Electronics Information Technology, 2014, 36(10): 2425-2430. doi: 10.3724/SP.J.1146.2014.00027.
