一种面向水面纹理的毫米波LFMCW雷达成像算法

魏翔飞 种劲松 王小青 李原 孟辉

魏翔飞, 种劲松, 王小青, 李原, 孟辉. 一种面向水面纹理的毫米波LFMCW雷达成像算法[J]. 电子与信息学报, 2017, 39(5): 1030-1035. doi: 10.11999/JEIT160684
引用本文: 魏翔飞, 种劲松, 王小青, 李原, 孟辉. 一种面向水面纹理的毫米波LFMCW雷达成像算法[J]. 电子与信息学报, 2017, 39(5): 1030-1035. doi: 10.11999/JEIT160684
WEI Xiangfei, CHONG Jinsong, WANG Xiaoqing, LI Yuan, MENG Hui. Imaging Algorithm of Millimeter-wave LFMCW Radar for Water Surface Texture Detection[J]. Journal of Electronics & Information Technology, 2017, 39(5): 1030-1035. doi: 10.11999/JEIT160684
Citation: WEI Xiangfei, CHONG Jinsong, WANG Xiaoqing, LI Yuan, MENG Hui. Imaging Algorithm of Millimeter-wave LFMCW Radar for Water Surface Texture Detection[J]. Journal of Electronics & Information Technology, 2017, 39(5): 1030-1035. doi: 10.11999/JEIT160684

一种面向水面纹理的毫米波LFMCW雷达成像算法

doi: 10.11999/JEIT160684
基金项目:

微波成像技术国家重点实验室基金(CXJJ_15S119)

Imaging Algorithm of Millimeter-wave LFMCW Radar for Water Surface Texture Detection

Funds:

The Foundation of National Key Laboratory of Science and Technology on Microwave Imaging (CXJJ_15S119)

  • 摘要: 利用毫米波线性调频连续波(LFMCW)雷达探测水面时,静止目标的回波以及噪声通常会淹没水面本身的回波信号,导致采用传统成像算法得到的结果中难以看到水面波浪纹理。针对这一问题,该文提出一种面向水面纹理的毫米波LFMCW雷达成像算法,该算法在距离向上采用Dechirp技术进行距离压缩,在方位向上进行分块处理。方位向分块处理过程中,首先根据静止目标与运动目标回波多普勒频率不同的特性,在频域去除静止目标回波的干扰;然后基于水面电磁散射特性,采用最大似然估计方法估计方位向频谱参数,计算水面回波能量。采用该算法对实测数据进行处理,结果显示该算法能够获得水面纹理信息,成像结果优于传统成像算法。
  • MEHDI G and MIAO Jungang. Millimeter wave FMCW radar for foreign object debris (FOD) detection at airport runways[C]. International Bhurban Conference on Applied Sciences Technology (IBCAST), Islamabad, Pakistan, 2012: 407-412. doi: 10.1109/IBCAST.2012.6177589.
    FERRI M, GIUNTA G, BANELLI A, et al. Millimeter wave radar applications to airport surface movement control and foreign object detection[C]. European Radar Conference, Rome, Italy, 2009: 437-440.
    MAZOUNI K, KOHMURA A, FUTATSUMORI S, et al. 77GHz FM-CW radar for FODs detection [C]. European Radar Conference, Paris, France, 2010: 451-454.
    NSENGIYUMVA F, PICHOT C, ALIFERIS I, et al. Millimeter-wave imaging of foreign object debris (FOD) based on two-dimensional approach[C]. IEEE Conference on Antenna Measurements Applications (CAMA), Chiang Mai, Thailand, 2015. doi: 10.1109/CAMA.2015.7428122.
    ZHONG Qi, ZHANG Zhongjin, YAN Danqing, et al. Airport runway FOD detection based on LFMCW radar using interpolated FFT and CLEAN[C]. IEEE 12th International Conference on Computer and Information Technology, Chengdu, China, 2012: 747-750. doi: 10.1109/CIT.2012.160.
    FEIL P, MENZEL W, NGUYEN T P, et al. Foreign objects debris detection (FOD) on airport runways using a broadband 78 GHz sensor[C]. European Radar Conference, Amsterdam, Netherlands, 2008: 451-454. doi: 10.1109/ EUMC.2008.4751779.
    LEONARD T, LAMONT S T, HODGES R, et al. 94 GHz TARSIER radar measurements of wind waves and small targets[C]. European Radar Conference, Manchester, UK, 2011: 73-76.
    CAPUTI W J. Stretch: A time-transformation technique [J]. IEEE Transactions on Aerospace and Electronic System, 1971, 7(2): 269-278. doi: 10.1109/TAES.1971.310366.
    CROMBIE D D. Doppler spectrum of sea echo at 13.56Mc/s [J]. Nature, 1955, 175(4459): 681-682. doi: 10.1049/cp.2012. 1727.
    HUANG Weimin and GILL E. Measuring surface wind direction by mono-static HF Ground-Wave radar at the eastern China sea[J]. IEEE Journal of Oceanic Engineering, 2004, 29(4): 1032-1037. doi: 10.1109/JOE.2004.834175.
    HUANG Weimin and GILL E. HF radar wave and wind measurement over the eastern China sea[J]. IEEE Transactions on Geoscience and Remote Sensing, 2002, 40(9): 1950-1955. doi: 10.1109/TGRS.2002.803718.
    BRUNING C, ALPER W R, and SCHROTER J G. On the focusing issue of synthetic aperture radar imaging of ocean waves[J]. IEEE Transactions on Geoscience and Remote Sensing, 1991, 29(1): 120-128. doi: 10.1109/36.101378.
    OUCHI K. Synthetic aperture radar imagery of range traveling ocean waves[J]. IEEE Transactions on Geoscience and Remote Sensing, 1988, 26(1): 30-37. doi: 10.1109/36. 2997.
    GOODMAN J W. Statistical Properties of Laser Speckle Patterns[M]. Laser Speckle and Related Phenomena, New York, USA, Springer, 1975: 9-75.
    OLIVER C and QUEGAN S. Understanding Synthetic Aperture Radar Images[M]. Raleigh, NC, SciTech Publishing, USA, 2004: 49-100.
    CHITROUB S, HOUACINE A, and SANSAL B. Statistical characterisation and modelling of SAR images[J]. Signal Processing, 2002, 82(1): 69-92.
