一种支持节点分割的vEPC虚拟网络功能部署模型

汤红波; 袁泉; 卢干强; 王晓雷; 赵宇

doi:10.11999/JEIT160507

一种支持节点分割的vEPC虚拟网络功能部署模型

doi: 10.11999/JEIT160507

基金项目:

国家863计划项目(2014AA01A701)，国家自然科学基金(61521003)，科技部支撑计划(2014BAH30B01)

计量
- 文章访问数: 1761
- HTML全文浏览量: 189
- PDF下载量: 553
- 被引次数: 0
出版历程
- 收稿日期: 2016-05-17
- 修回日期: 2016-09-06
- 刊出日期: 2017-03-19

A Model for Virtualized Network Function Deployment Based on Node-splitting in vEPC

Funds:

The National 863 Program of China (2014AA01A701), The National Natural Science Foundation of China (61521003), The Ministry of Science and Technology Support Plan (2014BAH30B01)

摘要

摘要: 软件定义网络(SDN)和网络功能虚拟化(NFV)促进了网络的创新，NFV实现了虚拟网络功能(VNF)的逻辑集中部署。针对vEPC(virtualized Evolved Packed Core)网络中VNF的池组化部署问题，该文提出一种支持节点分割的VNF部署模型，该模型基于虚拟请求业务流量的感知，利用节点分割算法动态调整VNF与底层网络资源切片的映射关系，实现VNF的跨域组池。与传统的多功能链联合映射算法相比，该方法能够实现节点资源细粒度化管理和统筹调度，优化网络视图，减少资源碎片。在SNDlib提供的网络拓扑实例下仿真证明，该模型可以降低虚拟网络的资源开销，并提高虚拟网络的请求接收率。
- 网络功能虚拟化 /
- 虚拟网络功能部署 /
- 5G /
- EPC(Evolved Packed Core) /
- 节点分割
Abstract: Software Defined Networking (SDN) and Network Function Virtualization (NFV) promote network innovation. NFV realizes logic centralized deployment of Virtualized Network Function (VNF). This paper proposes a kind of node-splitting VNF deployment model for problem of pooling deployment of VNF in virtualized Evolved Packet Core (vEPC) network. Based on the acknowledgement of virtual request traffic-aware, the model uses node-splitting algorithm to realize the dynamic adjustment of the mapping relation between VNF and physical network slices and organize the same VNFs across different domains as one pool. Compared with the traditional joint mapping algorithm of multi-function chain, the method can realize fine-grained management and overall scheduling of node resources, optimize network view, and reduce resource fragments. It is proven by network topology instance provided by SNDlib that the model can reduce resource overhead of virtual network and improve the ratio of acceptance of virtual network requests.
- Network Function Virtualization (NFV) /
- Virtualized network function placement /
- 5G /
- Evolved Packet Core (EPC) /
- Node-splitting

HTML全文

参考文献(15)

FISCHER A, BOTERO J F, TILL BECK M, et al. Virtual network embedding: a survey[J]. IEEE Communications Surveys Tutorials, 2013, 15(4): 1888-1906. doi: 10.1109/ SURV.2013.013013.00155.

SAMA M R, CONTRERAS L M, KAIPPALLIMALIL J, et al. Software-defined control of the virtualized mobile packet core[J]. IEEE Communications Magazine, 2015, 53(2): 107-115. doi: 10.1109/MCOM.2015.7045398.

BASTA A, KELLERER W, HOFFMANN M, et al. Applying NFV and SDN to LTE mobile core gateways, the functions placement problem[C]. ACM Workshop on All Things Cellular: Operations, Applications, Challenges, Chicago, USA, 2014: 33-38. doi: 10.1145/2627585.2627592.

BAUMGARTNER A, REDDY V S, and BAUSCHERT T. Mobile core network virtualization: a model for combined virtual core network function placement and topology optimization[C]. IEEE Conference on Network Softwarization, London, United Kingdom, 2015: 1-9. doi: 10.1109/NETSOFT.2015.7116162.

TALEB T, CORICI M, PARADA C, et al. EASE: EPC as a service to ease mobile core network deployment over cloud[J]. IEEE Network, 2015, 29(2): 78-88. doi: 10.1109/MNET. 2015.7064907.

CHOWDHURY M, RAHMAN M R, and BOUTABA R. Vineyard: virtual network embedding algorithms with coordinated node and link mapping[J]. IEEE/ACM Transactions on Networking, 2012, 20(1): 206-219. doi: 10.1109/TNET.2011.2159308.

李文, 吴春明, 陈健, 等. 物理节点可重复映射的虚拟网映射算法[J]. 电子与信息学报, 2011, 33(4): 908-914. doi: 10.3724/ SP.J.1146.2010.00735.

LI Wen, WU Chunming, CHEN Jian, et al. Virtual network mapping algorithm with repeatable mapping over substrate nodes[J]. Journal of Electronics Information Technology, 2011, 33(4): 908-914. doi: 10.3724/SP.J.1146.2010.00735.

JARRAY A and KARMOUCH A. Decomposition approaches for virtual network embedding with one-shot node and link mapping[J]. IEEE/ACM Transactions on Networking, 2015, 23(3): 1012-1025. doi: 10.1109/TNET. 2014.2312928.

LIU L, XU J, YU H, et al. A novel performance preserving VM splitting and assignment scheme[C]. IEEE International Conference on Communications, Sydney, Australia, 2014: 4215-4220. doi: 10.1109/ICC.2014.6883982.

ZHOU Y, LI Y, JIN D, et al. A virtual network embedding scheme with two-stage node mapping based on physical resource migration[C]. IEEE International Conference on Communication Systems, Amsterdam, Netherlands, 2010: 761-766. doi: 10.1109/ICCS.2010.5686504.

CHIH-LIN I, HAN S, XU Z, et al. 5G: rethink mobile communications for 2020+[J]. Philosophical Transactions of the Royal Society A, 2016, 374(2062): 20140432. doi: 10.1098/ rsta.2014.0432.

蔡志平, 刘强, 吕品, 等. 虚拟网络映射模型及其优化算法[J]. 软件学报, 2012, 23(4): 864-877. doi: 10.3724/SP.J.1001.2012. 04063.

CAI Zhiping, LIU Qiang, L Pin, et al. Virtual network mapping and optimization algorithm[J]. Journal of Software, 2012, 23(4): 864-877. doi: 10.3724/SP.J.1001.2012.04063.

DOBRESCU M, EGI N, ARGYRAKI K, et al. RouteBricks: exploiting parallelism to scale software routers[C]. ACM SIGOPS Symposium on Operating systems principles, Big Sky, USA, 2009: 15-28. doi: 10.1145/1629575.1629578.
