一种用于毫米波行波管的微带预失真电路

虞崇志; 胡波雄; 唐康凇; 王刚; 苏小保

doi:10.11999/JEIT160395

一种用于毫米波行波管的微带预失真电路

doi: 10.11999/JEIT160395

2.
(中国科学院电子学研究所北京 100190) ②(中国科学院大学北京 100039)

基金项目:

国家科技重大专项(2012ZX01007004001)，国家自然科学基金(61401427)

计量
- 文章访问数: 1118
- HTML全文浏览量: 100
- PDF下载量: 493
- 被引次数: 0
出版历程
- 收稿日期: 2016-04-22
- 修回日期: 2016-09-23
- 刊出日期: 2017-02-19

Micro-strip Predistortion Circuit for Millimeter-wave Travelling Wave Tube

2.
(Institute of Electronics, Chinese Academy of Sciences, Beijing 100190, China)

Funds:

The National Science and Technology Major Project (2012ZX01007004001), The National Natural Science Foundation of China (61401427)

摘要

摘要: 随着通信技术的发展，行波管预失真电路的研究变得越来越重要。该文针对基于肖特基二极管的非线性发生器，首次分析了二极管SPICE(Simulation Program with Integrated Circuit Emphasis)模型参数中零偏压结电容和串联电阻对预失真扩张曲线的影响。对目前的微带预失真电路工作在K波段以下，绝对或相对带宽一般不超过1.8 GHz和4%，需在输入及输出端加隔离器等不足，基于ADS(Advanced Design System)软件设计并加工了一种用于中心频率30 GHz，绝对和相对带宽为2 GHz和6.67% 的毫米波行波管的微带预失真电路。分别测试行波管和级联线性化器后的行波管，29 GHz, 30 GHz和31 GHz的增益和相位压缩量分别可以从7.5 dB和40 , 7.3 dB和50 , 7.1 dB和59改善到3.8 dB和10 , 3.7 dB和12 , 2.4 dB和15以内。双音测试结果表明，为了达到通信中载波与三阶交叉调制分量抑制比(C/IM3)25 dBc的要求，单独行波管在29 GHz, 30 GHz和31 GHz时需分别回退17 dB, 18 dB和18 dB，而加入线性化器后的行波管，只需分别回退12 dB, 9 dB和8 dB，也即加线性化器可改善5 dB, 9 dB和10 dB，极大地提升了行波管的线性度，具有重要工程应用价值。
- 行波管 /
- 肖特基二极管 /
- 预失真器 /
- 增益和相位扩张 /
- 载波与三阶交叉调制分量比
Abstract: With the development of communication technology, investigating predistortion circuit for Travelling Wave Tube (TWT) becomes more and more important. This paper analyzes the principle of nonlinearity generator based on the schottky diodes and the effects of the zero bias junction capacitor and series resistor of the diode Simulation Program with Integrated Circuit Emphasis (SPICE) model on the expansions of the circuit for the first time. The conventional micro-strip predistortion circuits, whose absolute or relative bandwidth are less than 1.8 GHz and 4%, work at below K band, and need isolators to match the input and output ports. Based on the Advanced Design System (ADS) software, it is designed that a micro-strip predistortion circuit for millimeter wave band TWT at center frequency 30 GHz, absolute bandwidth 2 GHz, and relative bandwidth 6.67%. The results of experiments show that the compressions variations of gain and phase are from 7.5 dB and 40, 7.3 dB and 50, 7.1 dB and 59to less than 3.8 dB and 10, 3.7 dB and 12, 2.4 dB and 15 for the TWT without and with the linearizer at 29 GHz, 30 GHz and 31 GHz respectively. The two tones test results show that the Input Power Back Off (IPBO) are 17 dB, 18 dB and 18 dB for the TWT, but 12 dB, 9 dB, and 8 dB for the Linearized TWT (LTWT), namely 5 dB, 9 dB, and 10 dB improvements with the linearizer at 29 GHz, 30 GHz, and 31 GHz respectively for the demand of 25 dBc Carrier to third InterModulation (C/IM3) ratioin in communication system. The linearity of TWT is clearly improved with the linearizer, which serves as a great value for engineering application.
- Travelling Wave Tube (TWT) /
- Schottky diode /
- Predistorter /
- Expansion of gain and phase /
- Carrier to third InterModulation (C/IM3) ratioin

HTML全文

参考文献(17)

SEYMOUR C D. Development of spacecraft solid-state high power L-band amplifiers[J]. IEE Proceedings F Communications, Radar and Signal Processing, 1986, 133(4): 326-338. doi: 10.1049/ip-f-1:19860056.

FAULKNER M. Amplifier linearization using RF feedback and feedforward techniques[J]. IEEE Transactions on Vehicular Technology, 1998, 47(1): 209-215. dio: 10.1109/25. 661047.

KENSINGTON P B and BENNETT D W. Linear distortion correction using a feed forward system[J]. IEEE Transactions on Vehicular Technology, 1996, 45(1): 74-81. doi: 10.1109/25. 481823.

ALLEN K, SHABBIR M, and JERRY K. Passive FET MMIC linearizers for C, X and Ku-band satellite application [C]. IEEE MTT-S Digest, USA, 1993: 353-356. doi: 10.1109/ MWSYM.1993.276805.

YAMAUCHI K, MORI K, NAKAYAMA M, et al. A microwave miniaturized linearizer using a parallel diode with a bias feed resisitance[J]. IEEE Transactions on Microwave Theory and Techniques, 1997, 45(12): 2431-2435. doi: 10. 1109/22.643856.

ALLEN K, ROBERT G, and ROGER D. Wide/Multi-band linearization of TWTAs using predistortion[J]. IEEE Transactions on Electron Devices, 2009, 56(5): 959-964. doi: 10.1109/TED.2009.2015412.

GHANNOUCHI F M. An S band RF digital linearizer for TWTAs and SSPAs[C]. European Conference on Circuit Theory and Design, Antalya, Turkey, 2009: 735-738. doi: 10.1109/ ECCTD.2009.5275092.

胡欣, 王刚, 王自成, 等. 一种场效应管预失真电路对改善行波管非线性的作用[J]. 电子与信息学报, 2011, 33(4): 951-955. doi: 10.3724/SP.J.1146.2010.00789.

HU Xin, WANG Gang, WANG Zicheng, et al. Improvement of TWT nonlinearity with a field effect transistor predistortion circuit[J]. Journal of Electronics Information Technology, 2011, 33(4): 951-955. doi: 10.3724/SP.J.1146. 2010.00789.

刘洁, 胡波雄, 王刚, 等. 一种适用于Ku波段行波管放大器的预失真线性化器[J]. 电子与信息学报, 2014, 36(10): 2515-2520. doi: 10.3724/SP.J.1146.2013.01820.

LIU Jie, HU Boxiong, WANG Gang, et al. A predistortion linearizer for Ku-band traveling wave tube amplifier[J]. Journal of Electronics Information Technology, 2014, 36(10): 2515-2520. doi: 10.3724/SP.J.1146.2013.01820.

VILLENMAZET J F, HISSA Y, AZZARA J C, et al. 1 GHz instantaneous wide-band analog predistortion linearizer for new telecom satellite transmit section[C]. IEEE Thirteenth International Vacuum Electronics Conference (IVEC), Monterey, California, USA, 2012: 425-426. doi: 10.1109/ IVEC.2012.6262224.

YOUNKYU C, DECKMAN B C, and DELISIO M P. Linearization of a spatially-combined X-band 100-W GaAs FET[C]. Compound Semiconductor Integrated Circuit Symposium (CSICS), La Jolla, California, USA, 2012: 1-4. doi: 10.1109/CSICS.2012.6340066.

KATZ A and CHOKOLA D. The evolution of linearizers for high power amplifiers[C]. IEEE MTT-S International Microwave Symposium (IMS), Phoenix, Arizona, USA, 2015: 1-4. doi: 10.1109/MWSYM.2015.7167120.

GUO Yan, YU Chao, and ZHU Anding. Simplified power adaptive digital predistorter for RF power amplifier in dynamic power transmission[C]. Proceedings of the 10th European Microwave Integrated Circuits Conference, Paris, France, 2015: 281-284. doi: 10.1109/EuMIC.2015.7345124.

MA Yuelin and YAMAO Y. Experimental results of digital predistorter for very wideband mobile communication system[C]. Vehicular Technology Conference, Glasgow, Scotland, UK, 2015: 2384-2387. doi: 10.1109/ VTCSpring.2015. 7145834.

LONG Zhenren, WANG Hua, GUAN Ning, et al. Indirect learning hybrid memory predistorter based on polynomial and look-up-table[C]. Vehicular Technology Conference, Glasgow, Scotland, UK, 2015: 361-365. doi: 10.1109/ VTCSpring. 2015.7145877.
