基于知识辅助的MIMO雷达波形设计方法

关键; 李秀友; 黄勇; 薛永华

doi:10.11999/JEIT160008

基于知识辅助的MIMO雷达波形设计方法

doi: 10.11999/JEIT160008

关键¹,
李秀友^1, ,,
黄勇¹,
薛永华¹

基金项目:

国家自然科学基金(61471382, 61401495, 61201445, 61179017, 61501487)，山东省自然科学基金(2015ZRA06052)，泰山学者建设工程专项经费

计量
- 文章访问数: 1450
- HTML全文浏览量: 133
- PDF下载量: 481
- 被引次数: 0
出版历程
- 收稿日期: 2016-01-04
- 修回日期: 2016-05-30
- 刊出日期: 2016-12-19

Knowledge-aided MIMO Radar Waveform Design Method

Funds:

The National Natural Science Foundation of China (61471382, 61401495, 61201445, 61179017, 61501487), Natural Science Foundation of Shandong Province (2015ZRA 06052), Special Funds of Taishan Scholars Construction Engineering

摘要

摘要: 该文针对雷达系统受到天线主瓣和副瓣杂波以及强干扰影响时性能下降问题，提出基于距离扩展目标和杂波先验信息的MIMO雷达波形设计方法。首先建立了目标函数，综合考虑了波束主瓣增益、旁瓣杂波抑制能力以及目标输出SCNR的改善性能；然后在优化问题求解中对约束条件进行松弛，使得波形矩阵空域和时域2维解耦合，从而实现空域波束形成和时域波形设计独立优化求解；其次利用L-BFGS算法设计恒模的发射波形矩阵，形成低副瓣的波束方向图和较深的强杂波抑制凹口，并基于目标输出SCNR最大化准则，利用迭代算法分步求解优化的主瓣发射波形和接收滤波器；最后通过电磁仿真的距离扩展目标数据验证所提算法的有效性。
- MIMO雷达 /
- 知识辅助 /
- 波形设计 /
- 距离扩展目标
Abstract: In order to solve the problem of performance degradation when radar system is influenced by clutter from mainlobe and sidelobe, MIMO radar waveform design algorithm based on knowledge of range-spread target and clutter is investigated. Firstly, an optimization cost function is established, which includes mainlobe gain, sidelobe clutter suppression capability and Signal to Clutter plus Noise Ratio (SCNR) improvement. Secondly, to tackle the optimization problem, a relaxation is made to decouple spatial and temporal domain of the waveform matrix, beamforming and waveform design can be solved independently. Thirdly, L-BFGS algorithm is used to design the unimodular waveform matrix, beampattern with lower sidelobe and deep null is got. Based on maximization of SCNR, transmitted waveform and receiving filter are designed by iterative algorithm. Finally, the effectiveness of the proposed algorithm is verified by electromagnetic simulation of range-spread target.
- MIMO radar /
- Knowledge-aided /
- Waveform design /
- Range-spread target

HTML全文

参考文献(15)

VESPE M, JONES G, and BAKER C J. Lessons for radar: waveform diversity in echolocating mammals[J]. IEEE Signal Processing Magazine, 2009, 26(1): 65-75.

YANG Y and BLUM R S. Minimax robust MIMO radar waveform design[J]. IEEE Journal of selected Topics in Signal Processing, 2007, 1(1): 147-155.

COCHRAN D, SUVOROVA S, HOWARD S D, et al.. Waveform libraries: measures of effectiveness for radar scheduling[J]. IEEE Signal Processing Magazine, 2009, 26(1): 12-21.

JIU Bo, LIU Hongwei, ZHANG Lei, et al. Wideband cognitive radar waveform optimization for joint target radar signature estimation and target detection[J]. IEEE Transactions on Aerospace and Electronic Systems, 2015, 51(2): 1530-1546.

YAN Junkun, JIU Bo, LIU Hongwei, et al. Prior knowledge- based simultaneous multibeam power allocation algorithm for cognitive multiple targets tracking in clutter[J]. IEEE Transactions on Signal Processing, 2015, 63(2): 512-527.

YAN Junkun, LIU Hongwei, JIU Bo, et al. Power allocation algorithm for target tracking in unmodulated continuous wave radar network[J]. IEEE Sensors Journal, 2015, 15(2): 1098-1108.

TURLAPATY A and JIN Yuanwei. Bayesian sequential parameter estimation by cognitive radar with multiantenna arrays[J]. IEEE Transactions on Signal Processing, 2015, 63(4): 974-987.

AUBRY A, DE MAIO A, FARINA A, et al. Knowledge- aided (potentially cognitive) transmit signal and receive filter design in signal-dependent clutter[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 49(1): 93-116.

AUBRY A, DE MAIO A, JIANG Bo, et al. Ambiguity function shaping for cognitive radar via complex quartic optimization[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 61(22): 5603-5619.

CHEN Chunyang and VAIDYANATHAN P P. MIMO radar waveform optimization with prior information of the extended target and clutter[J]. IEEE Transactions on Signal Processing, 2009, 57(9): 3533-3544.

GUERCI J R. Cognitive Radar: The Knowledge-Aided Fully Adaptive Approach[M]. Norwood, MA, USA, Artech House, 2010, Chapter 2.

HULEIHEL W, TABRIKIAN J, and SHAVIT R. Optimal adaptive waveform design for cognitive MIMO radar[J]. IEEE Transactions on Signal Processing, 2013, 61(20): 5075-5089.

JIU Bo, LIU Hongwei, WANG Xu, et al. Knowledge-based spatial-temporal hierarchical MIMO radar waveform design method for target detection in heterogeneous clutter zone[J]. IEEE Transactions on Signal Processing, 2015, 63(3): 543-554.

KISIALIOU M, LUO X D, and LUO Z Q. Efficient implementation of quasi-maximum-likelihood detection based on semidefinite relaxation[J]. IEEE Transactions on Signal Processing, 2009, 57(12): 4811-4822.

WANG Yongchao, WANG Xu, LIU Hongwei, et al. On the design of constant modulus probing signals for MIMO radar[J]. IEEE Transactions on Signal Processing, 2012, 60(8): 4432-4438.
