X波段脉冲空间行波管输出结构可靠性研究

尚新文; 李鑫伟; 曹林林; 肖刘; 苏小保

doi:10.11999/JEIT160003

X波段脉冲空间行波管输出结构可靠性研究

doi: 10.11999/JEIT160003

基金项目:

国家科技重大专项(2012ZX01007004001)，国家自然科学基金(61401427)，中科院国防科技创新基金(CXJJ-16Q137)

计量
- 文章访问数: 1170
- HTML全文浏览量: 167
- PDF下载量: 447
- 被引次数: 0
出版历程
- 收稿日期: 2016-01-04
- 修回日期: 2016-04-14
- 刊出日期: 2016-10-19

Study of the Reliability of the Output Structure for X-band Space Traveling Wave Tube

Funds:

The National Science and Technology Major Project (2012ZX01007004001), The National Natural Science Foundation of China (61401427), The National Defense Science and Technology Innovation Foundation, Chinese Academy of Sciences, (CXJJ-16Q137)

摘要

摘要: X波段脉冲空间行波管主要用于轻型SAR等雷达系统，要求行波管具有高功率、高效率、高可靠的性能。输出结构是行波管的重要部件，其可靠性不仅影响行波管的输出功率等性能，还影响行波管的稳定性与可靠性。该文针对X脉冲空间行波管输出结构进行可靠性研究，通过电、磁、热多物理场耦合的方式对它进行热、力结构可靠性分析，按分析结果对输出结构薄弱环节进行改进，耐冲击能力增强，并经过1000 h以上的整管老练及空间环境试验验证，输出结构具有较高的可靠性，满足空间环境试验及使用要求。
- 脉冲空间行波管 /
- 多物理场耦合 /
- 输出结构 /
- 可靠性
Abstract: X-band pulsed space Traveling Wave Tube (TWT) is mainly used in such radar system as light-weight SAR, which is required to have high power, high efficiency and high reliability. The output structure is an important part of the TWT, and its reliability not only affects the output power of TWT, but also influences the stability and reliability of the TWT. In this paper, the reliability of the output structure of an X-band pulsed space TWT is studied. The thermal and structural reliability is studied by means of multi-physics coupling including electrical and magnetic. The shock resistance ability of the output structure is improved according to the analysis results. Furthermore, in the course of above 1000 hours aging and space environmental test, the output structure has high reliability, meeting the space environment test and use requirements.
- Pulsed space Traveling Wave Tube (TWT) /
- Multi-physics coupling /
- Output structure /
- Reliability

HTML全文

参考文献(28)

肖刘, 刘濮鲲, 苏小保, 等. 300 W Ku 波段栅控脉冲空间行波管放大器研制[J]. 微波学报, 2010(8): 421-423.

XIAO Liu, LIU Pukun, SU Xiaobao, et al. Development of a 300 W Ku-band grid-controlled pulsed STWTA[J]. Journal of Microwaves, 2010(8): 421-423.

尚新文, 陈之亮, 金锋, 等. 脉冲空间行波管的研制[J]. 真空电子技术, 2014(3): 29-34. doi: 10.3969/j.issn.1002-8935. 2014.03.008.

SHANG Xinwen, CHEN Zhiliang, JIN Feng, et al. The development of pulsed space TWT[J]. Vacuum Electronics, 2014(3): 29-34. doi: 10.3969/j.issn.1002-8935.2014.03.008.

丁耀根. 大功率速调管的设计制造和应用[M]. 北京: 国防工业出版社, 2012: 262-264.

DING Yaogen. Design, Manufacture and Application of High Power Klystron[M]. Beijing: National Defend Industry Press, 2012: 262-264.

杨丹, 叶菊芳, 李少平, 等. 行波管输能窗的封接可靠性研究[C]. 中国电子学会可靠性分会学术年会, 重庆, 2004: 496-501.

YANG Dan, YE Jufang, LI Shaoping, et al. The Study of seal reliability about the power window of TWT[C]. Annual Academic Conference of Reliability Branch, Electronic Society of China, Chongqing, China, 2004: 496-501.

石明, 尚阿曼, 程建. Al2O3陶瓷窗片在毫米波盒形窗中的微波性能模拟及其封接残余应力模拟评估[J]. 真空电子技术, 2010(6): 4447. doi: 10.3969/j.issn.1002-8935.2010.06.011.

SHI Ming, SHANG Aman, and CHENG Jian. Simulation of A12O3 ceramic in millimeter wave window and evaluation of sealed residual stress[J]. Vacuum Electronics, 2010(6): 44-47. doi: 10.3969/j.issn.1002-8935.2010.06.011.

刘颖博, 高志强. 一种高可靠Ka波段盒型窗研究[C]. 华东三省一市真空学术交流会, 合肥, 2013: 245-247.

LIU Yingbo and GAO Zhiqiang. Study of a highly reliable Ka-band box type window[C]. Vaccum Academic Exchange Conference of 3 Province and 1 City in East China, Hefei, China, 2013: 245-247.

何晟, 邓艳波, 李儒礼. 高斯模式输出窗的热分析[J]. 真空电子技术, 2015(3): 12-16. doi: 10.3969/j.issn.1002-8935. 2015. 03.004.

HE Sheng, DENG Yanbo, and LI Ruli. The thermal analysis of output HE11 mode windows[J]. Vacuum Electronics, 2015(3): 12-16. doi: 10.3969/j.issn.1002-8935.2015.03.004.

陈辉, 王丽, 徐勇, 等. Q波段回旋行波管宽带高平均功率输出窗设计与热分析[J]. 强激光与粒子束, 2014, 26(12): 123005.1-123005.6. doi: 10.11884/HPLPB201426.123005.

CHEN Hui, WANG Li, XU Yong, et al. Design and thermal analysis of broad bandwidth and high average power output window for Q-band gyro-TWT[J]. High Power Laser and Particle Beams, 2014, 26(12): 123005.1-123005.6. doi: 10.11884/HPLPB201426.123005.

BAEK S W, LEE J H, KIM S H, et al. Thermal analysis of output connector for traveling wave tube[C]. IEEE International Vacuum Electronics Conference, Monterey, CA, USA, 2002: 230-231.

HEMAMALINI R, RAO P R R, RAO K V, et al. Thermal co-simulation of coaxial RF window and connector of a TWT[C]. 15th IEEE International Vacuum Electronics Conference (IVEC 2014), Monterey, CA, USA, 2014: 259-260.

徐长有, 赵世柯, 郝保良, 等. 某行波管输能窗结构动力学特性与随机振动试验[J]. 真空科学与技术学报, 2013, 33(4): 321-325. doi: 10.3969/j.issn.1672-7126.2013.04.05.

XU Changyou, ZHAO Shike, HAO Baoliang, et al. Simulation and random vibration test of structural dynamic characteristics of microwave window of traveling wave tube[J]. Chinese Journal of Vacuum Science and Technology, 2013, 33(4): 321-325. doi: 10.3969/j.issn.1672-7126.2013.04.05.

ROLAND H, GUNTER D, ANDREAS M, et al. CVD diamond windows studied with low and high-power millimeter waves[J]. IEEE Transactions on Plasma Science, 2002, 30(3): 800-807. doi: 10.1109/TPS.2002.801558.

MARC E H, RICHARD S C, and DAVID H W. High power vacuum window in WR10[J]. IEEE Transactions on Microwave Theory and Techniques, 2001, 49(5): 994-995.

KAREN A C and SUBHASH H R. Dielectric materials for window applications[J]. Journal of Physics and Chemistry of Solids, 2000, 61(4): 551-560.

NUSINOVICH G S, RUIFENG P, SINITSYN O V, et al. Self-excitation of a tapered gyrotron oscillator[J]. IEEE Transactions on Plasma Science, 2010, 38(6): 1200-1207. doi: 10.1109/TPS.2010.2046638.

高陇桥. 陶瓷在真空电子功率器件输出窗中的应用[J]. 电子科学技术评论, 2004(5): 37-43. doi: 10.3969/j.issn.1673-5692. 2004.05.007.

GAO Longqiao. The application of ceramics in the output window of the vacuum electronic power device[J]. Review of Electronics Science and Technology, 2004(5): 37-43. doi: 10.3969/j.issn.1673-5692.2004.05.007.

中国科学院电子学研究所. BM-9152型X波段脉冲空间行波管详细规范[S]. 北京, 2015.

Institute of Electronics Chinese Academy of Sciences. Detail specification for BM-9152 X-band pulsed traveling wave tube of space application[S]. Beijing, China, 2015.
