干扰条件下MIMO雷达收发联合方向图优化设计

王玉玺; 黄国策; 李伟

doi:10.11999/JEIT160002

干扰条件下MIMO雷达收发联合方向图优化设计

doi: 10.11999/JEIT160002

基金项目:

国家自然科学基金(61302153)

计量
- 文章访问数: 1262
- HTML全文浏览量: 126
- PDF下载量: 355
- 被引次数: 0
出版历程
- 收稿日期: 2016-01-04
- 修回日期: 2016-07-12
- 刊出日期: 2016-12-19

Joint Transmit and Receive Beampattern Design for MIMO Radar under Jamming

WANG Yuxi^{1
, ,},
HUANG Guoce¹,
LI Wei¹

Funds:

The National Natural Science Foundation of China (61302153)

摘要

摘要: 针对干扰条件下MIMO雷达面临的信号截获以及干扰源快速移动等问题，对雷达收发方向图进行优化设计。在发射端利用最小积分旁瓣准则对发射波束矩阵进行优化，将发射信号能量集中到目标空域，降低旁瓣并在干扰方向形成发射零陷；在接收端利用广义对角加载方法优化接收方向图，在提高信号接收稳健性的同时展宽零陷。通过对MIMO雷达收发方向图进行联合优化设计，解决了信号被截获及快速移动的有源干扰等问题，从收发两端共同提高雷达整体性能。通过实验仿真对比分析，验证了所提方法的可行性和有效性。
- MIMO雷达 /
- 方向图设计 /
- 稳健波束形成 /
- 零陷展宽
Abstract: For the problem of signal interception and fast moving jammers in MIMO radar application, this paper designs a new transmit beampattern through optimizing the transmit beamforming matrix based on the minimization of integrated-sidelobe. This new transmit beampattern can not only focus the transmit energy on the desired spatial sector but decrease the level of sidelobe as well as form a nulling at the jammers direction with the prior knowledge. At the receiving, a new robust beamforming method based on non-uniform generalized diagonal loading is proposed, which can strengthen the robustness of receiving beamformer against different errors and broaden the nulling adaptively. Through the optimization of joint transmit and receive beampattern for MIMO radar, the interception of signal and fast moving jamming are addressed, which improve the performance of MIMO radar from both transmitting and receiving. Simulation results and comparisons with existing methods demonstrate the feasibility and effectiveness of the proposed methods.
- MIMO radar /
- Beampattern design /
- Robust beamforming /
- Nulling broadening

HTML全文

参考文献(15)

STOCIA P, LI J, and XIE Yao. On probing signal design for MIMO radar[J]. IEEE Transactions on Signal Processing, 2007, 55(8): 4151-4161. doi: 10.1109/TSP.2007.894398.

FUHRMANN D R and ANTONIO G S. Transmit beamforming for MIMO radar systems using signal cross- correlation[J]. IEEE Transactions on Aerospace and Electronic Systems, 2008, 44(1): 171-186. doi: 10.1109/TAES. 2008.4516997.

GONG P, SHAO Z, TU G, et al. Transmit beampattern design based on convex optimization for MIMO radar systems[J]. Signal Processing, 2014, 94: 195-201. doi: 10. 1016/j.sigpro.2013.06.021.

HASSANIEN A and VOROBYOV S A. Transmit energy focusing for DOA estimation in MIMO radar with colocated antennas[J]. IEEE Transactions on Signal Processing, 2011, 59(6): 2669-2682. doi: 10.1109/TSP.2011.2125960.

KHABBAZIBASMENJ A, HASSANIEN A, VOROBYOV S, et al. Efficient transmit beamspace design for search-free based DOA estimation in MIMO radar[J]. IEEE Transactions on Signal Processing, 2014, 62(6): 1490-1500. doi: 10.1109/ TSP.2014.2299513.

BENJAMIN F. On transmit beamforming for mimo radar[J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(4): 3376-3388. doi: 10.1109/TAES.2012.6324717.

XIANG C, FENG D, and L H. Robust adaptive beamforming for MIMO radar[J]. Signal Processing, 2010, 90(12): 3185-3196. doi: 10.1016/j.sigpro.2010.05.022.

LI J, STOCIA P, and WANG Z. On robust capon beamforming and diagonal loading[J]. IEEE Transactions on Signal Processing, 2003, 51(7): 1702-1715. doi: 10.1109/TSP. 2003.812831.

LI Y, VOROBYOV S, and HASSANIEN A. Robust beamforming for jammers suppression in MIMO radar[C]. IEEE Radar Conference, Cincinnati, OH, USA, 2014: 629-634.

AHMED S and ALOUINI M S. MIMO radar transmit beampattern design without synthesising the covariance matrix[J]. IEEE Transactions on Signal Processing, 2014, 62(9): 2278-2289. doi: 10.1109/TSP.2014.2310435.

CHEN C and VAIDYANATHAN P P. MIMO radar waveform optimization with prior information of the extended target and clutter[J]. IEEE Transactions on Signal Processing, 2009, 57(9): 3533-3544. doi: 10.1109/TSP.2009. 2021632.

LIU J, LI H, and HIMED B. Joint optimization of transmit and receive beamforming in active arrays[J]. IEEE Signal Processing Letters, 2014, 21(1): 39-42, 2014. doi: 10.1109/LSP. 2013.2289325.

CHEN Z, LI H, CUI G, et al. Adaptive transmit and receive beamforming for interference mitigation[J]. IEEE Signal Processing Letters, 2014, 21(2): 235-239. doi: 10.1109/LSP. 2014.2298497.

XU H, BLUM R S, and WANG J. Colocated MIMO radar waveform design for transmit beampattern formation[J]. IEEE Transactions on Aerospace and Electronic Systems, 2015, 51(2): 1558-1568. doi: 10.1109/TAES.2014.140249.

COX H, ZESKIND R, and OWEN M. Robust adaptive beamforming[J]. IEEE Transactions on Acoustics, Speech and Signal Processing, 1987, 35(10): 1365-1376. doi: 10.1109/ TASSP.1987.1165054.
