一种线性化的全双工MIMO收发器设计

张志亮; 沈莹; 邵士海; 潘文生; 唐友喜

doi:10.11999/JEIT151363

一种线性化的全双工MIMO收发器设计

doi: 10.11999/JEIT151363

2.
(电子科技大学通信抗干扰技术国家级重点实验室成都 611731) ②(四川大学锦城学院电子信息工程系成都 611731)

基金项目:

国家自然科学基金(61471108, 61501093)，国家科技重大专项(2014ZX03003001-002)

计量
- 文章访问数: 1529
- HTML全文浏览量: 105
- PDF下载量: 333
- 被引次数: 0
出版历程
- 收稿日期: 2015-12-03
- 修回日期: 2016-03-21
- 刊出日期: 2016-09-19

Novel Design of Linear Full-duplex MIMO Radios

2.
(National Key Laboratory of Communication, University of Electronic Science and Technology of China, Chengdu 611731, China)

Funds:

The National Natural Science Foundation of China (61471108, 61501093), The National Major Projects (2014 ZX03003001-002)

摘要

摘要: 针对全双工MIMO收发器发射通道非线性以及接收通道存在强烈自干扰的问题，该文提出一种使发射通道线性化并通过射频多抽头重建与数字重建消除自干扰的具有较低硬件成本与软件复杂度的设计方案：(1)基于改进的串扰消除和数字预失真(CTC-DPD)算法并复用反馈通道进行去耦合和数字预失真使发射通道线性化、等增益；(2)在接收通道加入可调衰减器并用多维梯度下降法基于接收的残留自干扰功率最小原则调整抽头参数；(3)基于频域信道估计进行数字自干扰重建。实现的20 MHz带宽LTE全双工22 MIMO通信样机，发射通道经过线性化后带内更平坦，而带外噪声抑制了约30 dB。射频和数字消除一轮调整共耗时约0.17 ms，总消除能力约75 dB。16QAM映射时全双工双向数据速率总和220 Mbps，相对单向时的110 Mbps实现了频谱效率的翻倍。通信样机证明了该方案的可行性。
- 无线通信 /
- 串扰 /
- 非线性 /
- 全双工 /
- MIMO
Abstract: Considering the issues of nonlinearity and self-interference in transmitting and receiving channels of a full-duplex MIMO radio respectively, a novel low hardware cost and low software complexity design scheme with transmitting channels linearization and self-interference cancellation by multi-tap RF cancellers and digital cancellers is proposed, where (1) An improved Cross-Talk Cancelling-Digital Pre-Distorter (CTC-DPD) algorithm and common feedback are used for decoupling and digital pre-distortion to make transmitting channels gain linearly and equally; (2) By introducing adjustable attenuators in receiving channels, multi-tap cancellers use received data along with minimum residual self-interference power criterion based multidimensional gradient descent method to search the multi-tap setting; (3) Digital self-interference is reconstructed for cancellation based on channel estimation in frequency domain. In the prototype of 20 MHz bandwidth LTE full-duplex 22 MIMO radio, transmitting channels have more flat in-band spectrum and 30 dB lower out-band noise after linearization. RF and digital self-interference cancellation need 0.17 ms for one turning and provide about 75 dB cancellation together. When two nodes with 16QAM mapping work at full-duplex mode, they achieve a sum of 220 Mbps bit rate, which double the bit rate of 110 Mbps at half-duplex mode and thus double the spectrum efficiency. The prototype demonstrates the feasibility of the proposed design.
- Wireless communication /
- Crosstalk /
- Nonlinearity /
- Full-duplex /
- MIMO

HTML全文

参考文献(17)

ZHANG Zhongshan, CHAI Xiaomeng, LONG Keping, et al. Full duplex techniques for 5G networks: Self-interference cancellation, protocol design, and relay selection[J]. IEEE Communications Magazine, 2015, 53(5): 128-137. doi: 10. 1109/MCOM.2015.7105651.

SABHARWAL A, SCHNITER P, GUO Dongning, et al. In-band full-duplex wireless: Challenges and opportunities[J]. IEEE Journal on Selected Areas in Communications, 2014, 32(9): 1637-1652. doi: 10.1109/JSAC.2014.2330193.

LI Yi, GURSOY M C, and VELIPASALAR S. Throughput and mode selection in two-way MIMO systems under queuing constraints[C]. 2015 IEEE International Conference on Communications (ICC), London, United Kingdom, 2015: 2271-2276. doi: 10.1109/ICC.2015.7248663.

BHARADIA D and KATTI S. Full duplex MIMO radios[C]. 11th USENIX Symposium on Networked Systems Design and Implementation, Seattle, WA, USA, 2014: 359-372.

DUARTE M, SABHARWAL A, AGGARWAL V, et al. Design and characterization of a full-duplex multiantenna system for WiFi networks[J]. IEEE Transactions on Vehicular Technology, 2014, 63(3): 1160-1177. doi: 10.1109/ TVT.2013.2284712.

ARYAFAR E, KHOJASTEPOUR M A, SUNDARESAN K, et al. MIDU: Enabling MIMO full duplex[C]. ACM The Eighteenth Annual International Conference on Mobile Computing and Networking (MobiCom12), Istanbul, Turkey, 2012: 257-268. doi: 10.1145/2348543.2348576.

RIIHONEN T and WICHMAN R. Analog and digital self-interference cancellation in full-duplex MIMO-OFDM transceivers with limited resolution in A/D conversion[C]. 46th Asilomar Conference on Signals, Systems, and Computers, Pacific Grove, California, USA, 2012: 45-49. doi: 10.1109/ACSSC.2012.6488955.

DING Lei, ZHOU G T, MORGAN D R, et al. A robust digital baseband predistorter constructed using memory polynomials[J]. IEEE Transactions on Communications, 2004, 51(1): 159-165. doi: 10.1109/TCOMM.2003.822188.

MORGAN D R, MA Zhengxiang, KIM J, et al. A generalized memory polynomial model for digital predistortion of RF power amplifiers[J]. IEEE Transactions on Signal Processing, 2006, 54(10): 3852-3860. doi: 10.1109/TSP.2006.879264.

SURYASARMAN P M and SPRINGER A. A comparative analysis of adaptive digital predistortion algorithms for multiple antenna transmitters[J]. IEEE Transactions on Circuits and Systems I: Regular Papers, 2015, 62(5): 1412-1420. doi: 10.1109/TCSI.2015.2403034.

BASSAM S A, HELAOUI M, and GHANNOUCHI F M. Crossover digital predistorter for the compensation of crosstalk and nonlinearity in MIMO transmitters[J]. IEEE Transactions on Microwave Theory and Techniques, 2009, 57(5): 1119-1128. doi: 10.1109/TMTT.2009.2017258.

ZAYANI R, BOUALLEGUE R, and ROVIRAS D. Crossover neural network predistorter for the compensation of crosstalk and nonlinearity in MIMO OFDM systems[C]. The 21st IEEE Symposium on Personal, Indoor and Mobile Radio Communications (PIMRC 2010), Instanbul, Turkey, 2010: 966-970. doi: 10.1109/PIMRC.2010.5671770.

SURYASARMAN P, HOFLEHNER M, and SPRINGER A. Digital pre-distortion for multiple antenna transmitters[C]. The 43rd European Microwave Conference, Nuremberg, Germany, 2013: 412-415. doi: 10.1109/GlobalSIP.2013. 6737109.

AMIRI M V, HELAOUI M, and GHANNOUCHI F M. Streamlined MIMO cross-over digital predistortion[C]. 2014 IEEE Radio and Wireless Symposium (RWS), Newport Beach, California, USA, 2014: 283-285. doi: 10.1109/RWS. 2014.6830132.

BOYD S and VANDENBERGHE L. Convex Optimization [M]. Cambridge, U.K.: Cambridge University Press, 2004: 466-475.

3GPP. TS25.814: Technical Specification Group Radio Access Network; Physical layer aspects for evolved Universal Terrestrial Radio Access (UTRA) (Release 7)[R]. 2006.

3GPP. TS25.102: Technical Specification Group Radio Access Network; User Equipment (UE) radio transmission and reception (TDD) (Release 12)[R]. 2004.
