组合字典下超宽带穿墙雷达自适应稀疏成像方法

晋良念; 申文婷; 钱玉彬; 欧阳缮

doi:10.11999/JEIT150884

组合字典下超宽带穿墙雷达自适应稀疏成像方法

doi: 10.11999/JEIT150884

基金项目:

国家自然科学基金(61461012)，广西区自然科学基金(2013GXNSFAA019329, 2013GXNSFAA019004)，认知无线电与信息处理教育部重点实验室2015主任基金项目(CRKL150107)

计量
- 文章访问数: 1169
- HTML全文浏览量: 151
- PDF下载量: 294
- 被引次数: 0
出版历程
- 收稿日期: 2015-07-23
- 修回日期: 2016-02-18
- 刊出日期: 2016-05-19

Adaptive Sparse Imaging Approach for Ultra-wideband Through-the-wall Radar in Combined Dictionaries

Funds:

The National Natural Science Foundation of China (61461012), Guangxi Natural Science Foundation (2013GXNSFAA019329, 2013GXNSFAA019004), Cognitive Radio and the Ministry of Education Key Laboratory of Information Processing, 2015 the Fund Project of director (CRKL150107)

摘要

摘要: 针对现有超宽带穿墙雷达稀疏成像算法大多只采用点目标稀疏基表示模型和稀疏优化的正则化参数不能被自适应调整以及目标位置不在划分网格上带来虚假像的问题，该文提出一种基于贝叶斯证据框架的自适应稀疏成像方法。该方法首先利用组合字典独立稀疏表示场景中的点目标和扩展目标，然后在建立的偏离网格稀疏表示模型的基础上分层最大化各参数的似然函数，用第1层推理结合共轭梯度算法估计组合字典的各稀疏表示系数，用第2层推理估计正则化参数和目标的偏离网格量，最终通过迭代优化参数的设置得到问题的求解。仿真和实验结果表明，该方法不仅同时自适应增强穿墙场景中的点目标和扩展目标，还消除了偏离网格目标引起的虚假像。
- 超宽带穿墙雷达稀疏成像 /
- 组合字典 /
- 证据框架 /
- 参数自适应调整
Abstract: The existing algorithms of ultra-wideband through-the-wall radar sparse imaging mostly adopt point target model. Also the regularization parameter of sparse optimization can not be adjusted adaptively, and the ghost imaging can be produced if the targets are not positioned at the pre-discretized grid location. To deal with the above issues, an adaptive sparse imaging algorithm based on Bayesian evidence framework is proposed, which represents sparsely the scene with the point targets and the extended targets by combination of appropriate dictionaries, and maximizes hierarchically the likelihood?function of all parameters as well. The first-level inference of the Bayesian, combined with conjugate gradient algorithm, is adopted to estimate the sparse representation coefficients of the combined dictionaries. The second-level inference of the Bayesian is adopted to estimate the regularization parameter as well as the targets off-grid shifts. Therefore, the problem can be solved through iterative optimizating the parameter setting. The simulation and experimental results show that the proposed method can not only adaptively enhance the characteristics of both the point targets and the extended targets, but also mitigate ghosts caused by off-grid targets.
- Ultra-wideband through-the-wall radar sparse imaging /
- Combined dictionaries /
- Evidence framework /
- Adaptive adjustment of parameters

HTML全文

参考文献(18)

LI G and BURKHOLDER R J. Hybrid matching pursuit for distributed through-wall radar imaging[J]. IEEE Transactions on Antennas and Propagation, 2015, 63(4):

TIVIVE F H C, BOUZERDOUM A, and AMIN M G. A subspace projection approach for wall clutter mitigation in through-the-wall radar imaging[J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(4): 2108-2122. doi: 10.1109/TGRS.2014.2355211.

JIA Yong, CUI Guolong, KONG Lingjiang, et al. Multichannel and multiview imaging approach to building layout determination of through-wall radar[J]. IEEE Geoscience and Remote Sensing Letters, 2014, 11(5): 970-974. doi: 10.1109/LGRS.2013.2283778.

AMIN M G and AHMAD F. Change detection analysis of human moving behind walls[J]. IEEE Transactions on Aerospace and Electronic Systems, 2013, 49(3): 1410-1425.

WU Qisong, ZHANG Y D, AHMAD F, et al. Compressive sensing based high-resolution polarimetic through-the-wall radar imaging exploiting taget characteristics[J]. IEEE Antennas and Wireless Progagation Letters, 2014, 99: 1-4. doi: 10.1109/LAWP.2014.238087.

XIA Shugao and LIU Fengshan. Off-gird compressive sensing through-the-wall radar imaging[J]. Proceedings of SPIE, 2014, 9077: 90771F-1-8.

晋良念, 钱玉彬, 刘庆华, 等. 超宽带穿墙雷达偏离网格目标稀疏成像方法[J]. 仪器仪表学报, 2015, 36(4): 743-748.

JIN Liangnian, QIAN Yubin, LIU Qinghua, et al. Off-grid target sparse imaging method for ultra-wideband though- the-wall rader[J]. Chinese Journal of Scientific Instrument, 2015, 36(4): 743-748.

BROWNE K E, BURKHOLDER R J, and VOLAKIS J L. Fast optimization of through-wall radar images via the method of lagrange multipliers[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(1): 320-328. doi: 10.1109/TAP.2012.2220321.

SAMADI S,ETIN M, and MASNADI-SHIRAZI M A. Multiple feature-enhanced SAR imaging using sparsity in combined dictionaries[J]. IEEE Geoscience and Remote Sensing Letters, 2013, 10(4): 821-825. doi: 10.1109/LGRS. 2012.2225016.

LIU Hongchao, JIU Bo, LIU Hongwei, et al. An adaptive ISAR imaging method based on evidence framework[J]. IEEE Geoscience and Remote Sensing Letters, 2014, 11(6): 1031-1035. doi: 10.1109/LGRS.2013.2281194.

JIN T, CHEN B, and ZHOU Z. Imaging-domain estimation of wall parameters for autofocusing of through-the-wall SAR imagery[J]. IEEE Transactions on Geoscience and Remote Sensing, 2013, 51(3): 1836-1843. doi: 10.1109/TGRS.2012. 2206395.

LAGUNAS E, AMIN M G, AHMAD F, et al. Joint wall mitigation and compressive sensing for indoor image reconstruction[J]. IEEE Transactions on Geoscience and Remote Sensing, 2013, 51(2): 891-906. doi: 10.1109/TGRS. 2012.2203824.

PANT J and KRISHNAN S. Reconstruction of ECG signals for compressive sensing by promoting sparsity on the gradient[C]. IEEE International Conference on Acoustics, Speech and Signal Processing (ICASSP), Vancouver, 2013: 993-997.

安芹力, 冯有前, 高大化, 等. 组合正交基字典稀疏分解快速匹配追踪算法[J]. 电子设计工程, 2011, 19(2): 78-80.

AN Qinli, FENG Youqian, GAO Dahua, et al. A quick MP algorithm of sparse decomposition by overcomplete dictionary combined orthogonal bases[J]. Electronic Design Engineering, 2011, 19(2): 78-80.

SHENG F and JIAO D. A deterministic-solution based fast eigenvalue solver with guaranteed convergence for finite-element based 3-D electromagnetic analysis[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(7): 3701-3711 doi: 10.1109/TAP.2013.2258315.

-1711. doi: 10.1109/TAP.2015.2398115.
