软件定义光网络中基于最小点覆盖的控制平面跨层生存性设计

熊余; 董先存; 李圆圆; 吕翊; 王汝言

doi:10.11999/JEIT150815

软件定义光网络中基于最小点覆盖的控制平面跨层生存性设计

doi: 10.11999/JEIT150815

基金项目:

国家自然科学基金(61401052)，重庆市教委科学技术研究项目(KJ1400418, KJ1500445)，重庆邮电大学博士启动基金(A2015-09)

计量
- 文章访问数: 1205
- HTML全文浏览量: 122
- PDF下载量: 430
- 被引次数: 0
出版历程
- 收稿日期: 2015-07-08
- 修回日期: 2015-12-25
- 刊出日期: 2016-05-19

The Cross-layer Survivable Design of Control Plane Based on Minimum Point Covering in Software Defined Optical Network

Funds:

The National Natural Science Foundation of China (61401052), The Science and Technology Project of Chongqing Municipal Education Commission (KJ1400418, KJ1500445), The Ph. D. Start-up Fund of Chongqing University of Posts and Telecommunications (A2015-09)

摘要

摘要: 为降低软件定义光网络对单控制器的依赖，并避免多控制器冲突，有效提升控制平面的生存性，该文提出基于最小点覆盖的控制平面生存性设计策略。该策略结合集中控制约束条件，以最小点覆盖理论为基础，建立可靠的分级管控模型，设定控制器的管控优先级：全局控制器具有最高管控优先级，对全网进行集中管控；本地控制器次之，只对本地业务进行集中管控；权威交换机的管控优先级最低，用于完成局部波长粒度的光层快速管控。在此基础上，基于跨层信息模型为控制信道路由和资源分配进行生存性冗余设计。仿真表明，该策略能够满足网络对控制时延的要求，使控制平面的故障概率降低了30%，有效提升了网络在恶劣环境下的生存性。
- 软件定义光网络 /
- 生存性 /
- 控制平面 /
- 分级管控 /
- 最小点覆盖
Abstract: In order to lower the reliance on single controller in Software Defined Optical Network (SDON), avoid the conflict of different controllers, and improve effectively the survivability on the control plane, the survivable design of SDON control plane based on minimum point covering is proposed. Combined with the constraint of centralized control, the algorithm based on the minimum point covering establishes reliable hierarchical control model, and sets control priority to controllers. The master controller with the highest priority centralized controls the whole net, and the next comes the regional controller, which only intensively controls regional traffic, besides the authority switch which is introduced to control local wavelength in the optical layer owns the lowest level. Meanwhile, the model based on cross-layer information designs survivability redundancy for routing and allocates resource for the control channel. Simulation results show that the proposed strategy can satisfy the request on control delays, and lower the failure probability in the control plane by 30%, thus promoting the network survivability under critical environment.
- Software Defined Optical Network (SDON) /
- Survivability /
- Control plane /
- Hierarchical control /
- Minimum point covering

HTML全文

参考文献(20)

CHOI J S. Design and implementation of a PCE-based software-defined provisioning framework for carrier-grade MPLS-TP networks[J]. Photonic Network Communications, 2014, 29(1): 96-105.

姚琳元, 陈颖, 宋飞, 等. 基于时延的软件定义网络快速响应控制器部署[J]. 电子与信息学报, 2014, 36(12): 2802-2808. doi: 10.3724/SP.J.1146.2014.00211.

YAO Linyuan, CHEN Ying, SONG Fei, et al. Delay-aware controller placement for fast response in software-defined network[J]. Journal of Electronics Information Technology, 2014, 36(12): 2802-2808. doi: 10.3724/SP.J.1146.2014.00211.

左青云, 陈鸣, 赵广松, 等. 基于OpenFlow的SDN技术研究[J]. 软件学报, 2013, 24(5): 1078-1097.

ZUO Qingyun, CHEN Ming, ZHAO Guangsong, et al. Research on openflow-based SDN technologies[J]. Journal of Software, 2013, 24(5): 1078-1097.

CASADO M, GARFINKEL T, et al. SANE: a protection architecture for enterprise networks[C]. Usenix Security, Vancouver, 2006: 137-151.

CASADO M, FREEDMAN M J, PETTIT J, et al. Ethane: taking control of the enterprise[J]. ACM SIGCOMM Computer Communication Review, 2007, 37(4): 1-12.

MCKEOWN N, ANDERSON T, BALAKRISHNAN H, et al. OpenFlow: enabling innovation in campus networks[J]. ACM SIGCOMM Computer Communication Review, 2008, 38(2): 69-74.

Open Networking Foundation. version 1.3. 4. OpenFlow switch specification[S]. 2014.

HELLER B, SHERWOOD R, and MCKEOWN N. The controller placement problem[C]. Proceedings of the First ACM Workshop on Hot Topics in Software Defined Networks, Helsinki, 2012: 7-12.

JAIN S, KUMAR A, MANDAL S, et al. B4: experience with a globally-deployed software defined WAN[J]. ACM SIGCOMM Computer Communication Review, 2013, 43(4): 3-14.

YU M, REXFORD J, FREEDMAN M J, et al. Scalable flow-based networking with DIFANE[J]. ACM SIGCOMM Computer Communication Review, 2011, 41(4): 351-362.

ZHANG Y, BEHESHTI N, and TATIPAMULA M. On resilience of split-architecture networks[C]. IEEE Global Telecommunications Conference (GLOBECOM). Houston, 2011: 1-6.

MLLER L F, OLIVEIRA R R, et al. Survivor: an enhanced controller placement strategy for improving SDN survivability[C]. IEEE Global Communications Conference (GLOBECOM), Austin, 2014: 1909-1915.

熊余, 张鸿, 王汝言, 等. 基于光通路状态感知的分簇式故障定位机制[J]. 电子与信息学报, 2014, 36(1): 41-47. doi: 10.3724/SP.J.1146.2013.00214.

XIONG Yu, ZHANG Hong, WANG Ruyan, et al. Fault location mechanism based on lightpath status aware using cluster allocation[J]. Journal of Electronics Information Technology, 2014, 36(1): 41-47. doi: 10.3724/SP.J.1146.2013. 00214.

张清华, 陈六新, 等. 图论及其应用[M]. 北京: 清华大学出版社, 2013: 126-137.

ZHANG Qinghua, CHEN Liuxin, et al. Graph Theory and Its Application[M]. Beijing: Tsinghua University Press, 2013: 126-137.

ZHANG D, SONG X, CHEN C, et al. Software defined synergistic IP+optical resilient transport networks[J]. Journal of Optical Communications and Networking, 2015, 7(2): A209-A217.

DIN D R and HUANG J S. Multicast backup reprovisioning problem for Hamiltonian cycle-based protection on WDM networks[J]. Optical Fiber Technology, 2014, 20(2): 142-157.
