大误差条件下单频干扰引起的伪码跟踪误差研究

瞿智; 杨俊; 杨建伟

doi:10.11999/JEIT150481

大误差条件下单频干扰引起的伪码跟踪误差研究

doi: 10.11999/JEIT150481

基金项目:

国家自然科学基金(61201031)

计量
- 文章访问数: 1236
- HTML全文浏览量: 125
- PDF下载量: 433
- 被引次数: 0
出版历程
- 收稿日期: 2015-04-28
- 修回日期: 2015-09-24
- 刊出日期: 2016-01-19

Effects of Continuous Wave Interference on Pseudorandom Code Tracking Error under Large Error Conditions

Funds:

The National Natural Science Foundation of China (61201031)

摘要

摘要: 单频干扰能够引起较大的伪码跟踪误差，基于小误差条件的跟踪误差分析会失效。在大误差条件下，由于码环鉴相器不再工作在线性区域，利用鉴相器输出的二阶泰勒展开式代替一阶线性化近似，该文给出了单频干扰下伪码跟踪误差的解析表达式。通过数值分析和仿真实验分析验证了在单频干扰下伪码跟踪误差随干扰起始相位、干扰频率和干信比的变化特性。结果表明：当干扰引起的伪码跟踪误差较大时，基于鉴相器线性化的理论预测的准确性显著下降，而基于鉴相器二阶泰勒近似的理论分析能够准确预测大误差条件下的伪码跟踪误差，在跟踪误差不超过0.34 chip时，理论分析误差不超过20%。
- 单频干扰 /
- 伪码跟踪误差 /
- 鉴相器 /
- 大误差条件 /
- 二阶泰勒展开
Abstract: Continuous Wave Interference (CWI) can induce large code tracking error, and the tracking error analysis based on small error conditions becomes invalid. Under large error conditions, since code loop discriminator is no longer working in the linear region, the second-order Taylor series expansion of discriminator output is introduced instead of linear approximation, and analytical expressions of the tracking error in the presence of CWI are derived. Numerical analysis and simulation results are presented to evaluate the code tracking error with different initial phases，interference frequencies and interference-to-signal power ratio (ISR). The experimental results show that, when the code tracking error induced by CWI is large, the prediction accuracy of theoretical analysis based on linearized discriminator decreases noticeable, while the new theoretical expressions based on second-order Taylor series expansion provide accurate predictions of code tracking errors under large error conditions. If the code tracking error is smaller than 0.34 chip, the theoretical prediction error is no more than 20%.
- Continuous wave interference /
- Pseudorandom code tracking error /
- Discriminator /
- Large error conditions /
- Second-order Taylor series expansion

HTML全文

参考文献(22)

KAPLAN E D and HEGARTY C. Understanding GPS: Principles and Applications (2nd Ed.)[M]. Norwood, MA: Artech House, 2006: 243-272.

BEK M K, SHAHEEN E M, and ELGAMEL S A. Classification and mathematical expression of different interference signals on a GPS receiver[J]. NAVIGATION, Journal of the Institute of Navigation, 2015, 62(1): 23-37.

BALAEI A T, DEMPSTER A G, and PRESTI L L. Characterization of the effects of CW and pulse CW interference on the GPS signal quality[J]. IEEE Transactions on Aerospace and Electronic Systems, 2009, 45(4): 1418-1431.

PARKINSON B W, SPILKER J J, and ENGE P. Global Positioning System: Theory and Applications, vol. I[M]. Washington, DC: American Institute of Aeronautics and Astronautics, 1996: 745-756.

VAN Dierendonck A J, FENTON P, and FORD T. Theory and performance of narrow correlator spacing in a GPS receiver [J]. NAVIGATION, Journal of The Institute of Navigation, 1992, 38(3): 265-283.

BETZ J W and KOLODZIEJSKI K R. Generalized theory of code tracking with an early-late discriminator part I: Lower bound and coherent processing[J]. IEEE Transactions on Aerospace and Electronic Systems, 2009, 45(4): 1538-1550.

BETZ J W and KOLODZIEJSKI K R. Generalized theory of code tracking with an early-late discriminator part II: Noncoherent processing and numerical results[J]. IEEE Transactions on Aerospace and Electronic Systems, 2009, 45(4): 1551-1564.

JANG J, PAONNI M, and EISSFELLER B. CW Interference effects on tracking performance of GNSS receivers[J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(1): 243-258.

MOTELLA B, SAVASTA S, MARGARIA D, et al. Method for assessing the interference impact on GNSS receivers[J]. IEEE Transactions on Aerospace and Electronic Systems, 2011, 47(2): 1416-1431.

LIU Y, RAN Y, KE T, et al. Code tracking performance analysis of GNSS signal in the presence of CW interference[J]. Signal Processing, 2011, 91(4): 970-987.

刘禹圻, 胡修林, 冉一航, 等. 卫星导航信号抗单频干扰性能研究[J]. 电子学报, 2011, 36(6): 1410-1416.

LIU Yuqi, HU Xilin, RAN Yihan, et al. Study on evaluating the impact of CWI on DLL tracking performance for GNSS signals[J]. Acta Electronica Sinica, 2011, 36(6): 1410-1416.

孟生云, 杨文革, 王保华. 单音干扰下扩频测控信号伪码跟踪性能研究[J]. 宇航学报, 2013, 34(9): 1259-1265.

MENG Shengyun, YANG Wenge, and WANG Baohua. Study on pseudo-code tracking performance of spread spectrum TTC signals under single tone jamming[J]. Journal of Astronautics, 2013, 34(9): 1259-1265.

QU Z, YANG J, and CHEN J. Continuous wave interference effects on ranging performance of spread spectrum receivers [J]. Wireless Personal Communications, 2015, 82(1): 473-494.

ZHANG T and CHU H. Continuous wave interference impact assessment on tracking performance of Beidou civil B1I signal [C]. The 5th China Satellite Navigation Conference, Nanjing, China, 2014: 1-7.

QU B, WEI J, TANG Z, et al. Analysis of combined effects of multipath and CW interference on coherent delay lock loop [J]. Wireless Personal Communications, 2014, 77(3), 2213-2233.

QU B, WEI J, ZHABG S, et al. Effects of multipath and CW interference on code tracking loop with EML discriminator [C]. Proceedings of the 2014 International Technical Meeting of the Institute of Navigation, San Diego, CA, 2014: 297-303.

毛虎, 吴德伟, 卢虎, 等. 对GPS接收机的一种新宽带压制干扰样式分析[J]. 电子与信息学报, 2014, 36(12): 2929-2934. doi: 10.3724/SP.J.1146.2014.00123.

MAO Hu, WU Dewei, LU Hu, et al. Analysis of a new wideband blanket jamming type to GPS receiver[J]. Journal of Electronics Information Technology, 2014, 36(12): 2929-2934. doi: 10.3724/SP.J.1146.2014.00123.

程艳合, 杨文革. 压缩域直扩测控通信信号伪码跟踪方法研究[J]. 电子与信息学报, 2015, 37(8): 2028-2032. doi: 10.11999/JEIT141654.

CHENG Yanhe and YANG Wenge. Study on pseudo-noise code tracking method for compressive domain direct sequence tracking telemetry and command communication signals[J]. Journal of Electronics Information Technology, 2015, 37(8): 2028-2032. doi: 10.11999/JEIT141654.
