球模式展开理论近远场变换及快速算法

李南京; 李元新; 胡楚锋

doi:10.11999/JEIT150203

球模式展开理论近远场变换及快速算法

doi: 10.11999/JEIT150203

1.
(西北工业大学无人机特种技术重点实验室西安 710065) ②(西北工业大学电子信息学院西安 710072)

基金项目:

国家自然科学基金(61201320, 61371023)

计量
- 文章访问数: 2239
- HTML全文浏览量: 295
- PDF下载量: 683
- 被引次数: 0
出版历程
- 收稿日期: 2015-02-03
- 修回日期: 2015-07-13
- 刊出日期: 2015-12-19

Near-field to Far-field Transformations Based on Spherical Wave Expansions and Fast Algorithm

1.
(National Key Laboratory of Science and Technology on Unmanned Aerial Vehicle, Northwestern Polytechnical University, Xi&rsquo

Funds:

The National Natural Science Foundation of China (61201320, 61371023)

摘要

摘要: 基于球模式展开理论的近远场变换是天线球面近场测量系统实现的关键，它将待测天线在空间建立的场展开成球面波函数之和，由于其计算公式复杂，因而计算耗费时间长。该文在实际计算中利用快速傅里叶变换及矩阵的思想可以大幅度提高程序运行速度，节省计算时间。采用该方法对角锥喇叭天线的近远场数据进行仿真验证，结果表明外推远场的结果和理论值吻合良好，说明了该方法在保证计算精度的同时，可缩短计算时间。
- 天线球面近场测量 /
- 球模式展开理论 /
- 近远场变换 /
- 快速算法
Abstract: The theory of near-field to far-field transformation using spherical-wave expansions is the key to implement the spherical near-field antenna measurement system. It can develop the field in the space which is built by antenna expanding into the sum of spherical wave functions. Because of its complex formula, it will consume a long time to compute. The FFT transformation and the ideas of matrix are put into used in this paper, so the compute speed can be improved and the compute time can be saved. Using this method to testify the near-field data and the far-field data of a horn antenna, the results show that the far-field pattern computed from near-field date and the far-field pattern from theoretical integral equations are compared very well. It is approved that this method can guarantee the calculation precision and shortens the compute time at the same time.
- Spherical near-field antenna measurements /
- Spherical-wave expansion /
- Near-field to far-field transformation /
- Fast algorithm

HTML全文

参考文献(21)

Quan Shao-hui. Compact range performance evaluation using aperture near-field angular spectrums[J]. IEEE Transactions on Antennas and Propagation, 2013, 61(5): 2741-2481.

Castaner M S, Facila F C, Foged L J, et al.. A reflection suppression technique for far field antenna measurements[C]. 7th European Conference on Antennas and Propagation, Gothenburg, 2013: 3894-3898.

Agostino F D, Ferrara F, Fordham J A, et al.. An experimental validation of the near-field far-field transformation with spherical spiral scan[J]. IEEE Transactions on Antennas and Propagation, 2013, 55(3): 228-235.

张福顺, 焦永昌, 马金平. 辐射、散射近场测量及近场成像技术的研究进展[J]. 西安电子科技大学学报(自然科学版), 1999, 26(5): 651-656.

Zhang Fu-shun, Jiao Yong-chang, and Ma Jin-ping, The state of art of near field techniques for radiation, targets scattering measurements and object imaging[J]. Journal of Xian Electronic and Science University(Natural Science), 1999, 26(5): 651-656.

王加莹, 高本庆, 刘瑞祥, 时域平面近场测量的数值分析方法[J]. 电子与信息学报, 2000, 22(3): 478-484.

Wang Jia-ying, Gao Ben-qing, and Liu Rui-xiang. Numerical analysis method for planar near field measurement in time domain[J]. Journal of Electronics Information Technology, 2000, 22(3): 478-484.

Wasylkiwskyj W and Kahn W K. Scattering properties and mutual coupling of antennas with prescribed radiation pattern[J]. IEEE Transactions on Antennas and Propagation, 1970, 18(6): 741-752.

Belmkaddem K, Rudant L, and Vuong T P. Small antenna radiation properties analysis using spherical wave expansion [C]. 15th International Symposium on Antenna Technology and Applied Electromagnetics, Toulouse, 2012: 1-5.

Belmkaddem K, Rudant L, and Vuong T P. Investigation on antennas miniaturization using spherical wave expansion[C]. 7th European Conference on Antennas and Propagation, Gothenburg, 2013: 1887-1890.

Giacomini A, Potenza A, Morbidini R, et al.. Quad-ridge dual polarized antenna for use in the 2~32 GHz band[C]. 6th European Conference on Antennas and Propagation, Prague, 2012: 769-772.

Noren P, Foged L J, and Garreau P. State of art spherical near-field antenna test systems for full vehicle testing[C]. 6th European Conference on Antennas and Propagation, Prague, 2012: 2244-2248.

Foged L J, Scialacqua L, Noren P, et al.. Fast measurements and diagnostics on radar antennas using compact cylindrical NF range[C]. 7th European Conference on Antennas and Propagation, Gothenburg, 2013: 2930-2933.

Foged L J, Scialacqua L, Herbiniere F, et al.. Comparative measurements and inverse source technique for validation of compact cylindrical NF ranges[C]. 2012 Loughborough Antenna and Propagation Conference, Loughborough, 2012: 1-4.

Zhou Yang, Li Nan-jing, and Xu Jia-dong. A novel algorithm based on stepped-frequence about extrapolating near-field to far-field[C]. 8th IEEE International Symposium on Communication Systems, Networks and Digital Signal Processing, Poznan, 2012: 1-4.

张麟兮, 鲁新建, 李南京, 天线在近场测量中的卷积外推算法研究[J]. 计算机仿真, 2010, 27(8): 359-362.

Zhang Lin-xi, Lu Xin-jian, and Li Nan-jing. A lgorithm of antenna in near field measurement[J]. Computer Simulation, 2010, 27(8): 359-362.

Hansen J E. Spherical Near-Field Antenna Measurements[M]. London: United Kingdom, 1988: 90-144.

Thal H L Jr and Manges J B. Theory and practice for a spherical-scan near-field antenna range[J]. IEEE Transactions on Antennas and Propagation, 1988, 36(6): 815-821.

曾江燕, 鲁述. 应用球模展开实现近远场变换[J]. 电子与信息学报, 1991, 13(1): 102-107.

Zeng Jiang-yan and Lu Shu. Near-field far-field transformations using spherical-wave expansions[J]. Journal of Electronics Information Technology, 1991, 13(1): 102-107.
