密集布放环境下的标签互阻设计方法

彭章友; 孟春阳; 任秀方; 李帅

doi:10.11999/JEIT141340

密集布放环境下的标签互阻设计方法

doi: 10.11999/JEIT141340

基金项目:

上海市科学技术委员会(12510500600)资助课题

计量
- 文章访问数: 1437
- HTML全文浏览量: 180
- PDF下载量: 585
- 被引次数: 0
出版历程
- 收稿日期: 2014-10-20
- 修回日期: 2014-12-20
- 刊出日期: 2015-06-19

Design of Stacked Tags for Mutual Impedance in Intensive Distribution Environment

摘要

摘要: 在密集布放环境中，超高频射频识别标签(UHF RFID)会受到相邻标签的干扰产生互阻抗，导致读取率下降。基于二端口网络和八木阵列天线的理论，该文分析天线结构与互阻抗的关系，并解释标签天线传输系数和增益的变化原因。进而提出一种密集布放环境中的标签互阻设计方法。仿真和测试结果表明，新标签不仅单一性能良好，且互相间的干扰小，适用于多标签密集布放环境中的射频识别系统。
- 无线通信 /
- 标签天线 /
- 密集布放 /
- 互阻抗 /
- 传输系数
Abstract: In the dense distribution environment, the Ultra-High Frequency Radio-Frequency IDentification (UHF RFID) tags are interfered by the mutual impedance of adjacent tags, which can lead to a decline in reading rate. Based on the two-port network and Yagi-Uda antenna array theory, this paper firstly analyzes the relationship of antenna structure and mutual impedance. Then, the reasons for the change of the tag antenna transmission coefficient and the gain are explained. At last, a design of stacked tags for mutual impedance in intensive distribution environment is proposed. The numerical simulation and measurement results show that the new kind of RFID tag, not only has better performance in stand-alone scenario, but also has less interference between each other. It is suitable for RFID system in dense environment of multiple tags.
- Wireless communication /
- Tag antenna /
- Dense environments /
- Mutual impedance /
- Transmission coefficient

HTML全文

参考文献(20)

Marrocco G. RFID grids: part IElectromagnetic theory[J]. IEEE Transactions on Antennas and Propagation, 2011, 59(3): 1019-1026.

Dobkin D M and Weigand S M. UHF RFID and tag antenna scattering, part II: theory[J]. Microwave Journal, 2006, 49(6): 86-96.

Dobkin D M and Weigand S M. UHF RFID and tag antenna scattering part I: experimental results-first in a two-part series on the use of radio frequency communications to identify physical objects in the commercial supply chain[J]. Microwave Journal, 2006, 49(5): 170-190.

佐磊, 何怡刚, 李兵, 等. 标签密集环境下天线互偶效应研究[J]. 物理学报, 2013, 62(4): 1021-1029.

Zuo Lei, He Yi-gang, Li Bing, et al.. Theory and measurement for mutual coupling effect of ultra high frequency radio- frequency identification in dense environments[J]. Acta Physica Sinica, 2013, 62(4): 1021-1029.

Caizzone S and Marrocco G. RFID grids: part II Experimentations[J]. IEEE Transactions on Antennas and Propagation, 2011, 59(8): 2896-2904.

Lu F, Chen X S, and Ye T T. Performance analysis of stacked RFID tags[C]. Proceedings of the IEEE International Conference on RFID, Orlando, USA, 2009: 330-337.

Weisgerber L and Popugaev A E. Multibeam antenna array for RFID applications[C]. Proceedings of the European Microwave Conference, Nuremberg, Germany, 2013: 84-87.

Dhakal S and Shin S. A sequential reading strategy to improve the performance of RFID anti-collision algorithm in dense tag environments[C]. Proceedings of the 2013 Fifth International Conference on Ubiquitous and Future Networks, Da Nang, Vietnam, 2013: 531-536.

Abdulhadi A E and Abhari R. Design and experimental evaluation of miniaturized monopole UHF RFID tag antennas[J]. IEEE Antennas and Wireless Propagation Letters, 2012, 11: 248-251.

Zamora G, Zuffanelli S, Paredes F, et al.. Design and synthesis methodology for UHF-RFID tags based on the T-Match network[J]. IEEE Transactions on Microwave Theory Techniques, 2013, 61(12): 4090-4098.

Endo T, Sunahara Y, Satoh S, et al.. Resonant frequency and radiation efficiency of meander line antennas[J]. Electronics and Communications in Japan (Part II: Electronics), 2000, 83(1): 52-58.

Keskin N, Imeci T, Rahman S M T, et al.. Dipole antenna designs for UHF RFID passive tag[C]. Proceedings of the IEEE 22nd Signal Processing and Communications Applications Conference, Trabzon, Turkey, 2014: 1134-1137.

Faudzi N M, Ali M T, Ismail I, et al.. A compact dipole UHF-RFID tag antenna[C]. Proceedings of the IEEE International RF and Microwave Conference, Penang, Malaysia, 2013: 314-317.

肖芳鑫, 张雪凡, 李帅, 等. 密集布放环境下RFID标签受限链路[J]. 上海大学学报(自然科学版), 2014(5): 624-632.

Xiao Fang-xin, Zhang Xue-fan, Li Shuai, et al.. RFID limited system link analysis of stacked tags[J]. Journal of Shanghai University(Natural Science Edition), 2014(5): 624-632.

Asl S E, Ghasr M T, Zawodniok M, et al.. Preliminary study of mutual coupling effect on a passive RFID antenna array[C]. Proceedings of the IEEE International Instrumentation and Measurement Technology Conference, Minneapolis, USA, 2013: 138-141.

钟顺时. 天线理论与技术[M]. 北京: 电子工业出版社, 2011: 96-100.

Zhong Shun-shi. Antenna Theory and Techniques[M]. Beijing: Publishing House of Electronics Industry, 2011: 96-100.

Hotte D, Siragusa R, Duroc Y, et al.. Performance optimization for the choice of impedances in the design of passive RFID tags[C]. Proceedings of the IEEE-APS Topical Conference on Antennas and Propagation in Wireless Communications, Torino, Italy, 2013: 1349-1352.
