一种基于模型的合成孔径声呐图像目标快速识别方法

朱兆彤; 彭石宝; 许稼; 许肖梅

doi:10.11999/JEIT141228

一种基于模型的合成孔径声呐图像目标快速识别方法

doi: 10.11999/JEIT141228

1.
(厦门大学水声通信与海洋信息技术教育部重点实验室厦门 361005) ②(清华大学电子工程系北京 100084) ③(北京理工大学信息与电子学院北京 100081)

基金项目:

国家自然科学基金(61271391, 41176032, 41376040)

计量
- 文章访问数: 1278
- HTML全文浏览量: 115
- PDF下载量: 634
- 被引次数: 0
出版历程
- 收稿日期: 2014-09-23
- 修回日期: 2015-03-09
- 刊出日期: 2015-07-19

Fast Model-based Automatic Target Recognition Method for Synthetic Aperture Sonar Image

1.
(Key Laboratory of Underwater Acoustic Communication and Marine Information Technology (Xiamen University),Ministry of Education, Xiamen 361005, China)
2.
(Department of Electronic Engineering, Tsinghua University, Beijing 100084, China)

摘要

摘要: 针对基于合成孔径声呐(SAS)图像目标识别的先验模板获取困难、运算复杂度高的问题，该文提出一种基于模型的改进型相关快速识别方法。首先，基于构造凸壳估计目标姿态角，实现目标成像几何关系的估计；其次，提出改进的基于隐藏点移除的目标图像快速生成方法，可实时得到各备选目标对应成像几何关系的仿真图像；进而基于图像相关实现目标图像识别；最后，仿真实验证明了算法的有效性。仿真实验结果表明，相比于常规的直接模板识别方法，该方法识别率高，计算速度快。
- 合成孔径声呐 /
- 目标自动识别 /
- 模型识别 /
- 姿态角估计 /
- 仿真模板
Abstract: A modified model-based method is proposed to obtain sufficient prior templates and reduce the computational complexity on Synthetic Aperture Sonar (SAS) automatic target recognition. First, a quick method based on build convex hull is proposed to estimate the target pose quickly as well as the SAS imaging geometry for the specified target. Second, an improved method based on Hidden Point Removal (HPR) algorithm is proposed to obtain the target SAS simulation image effectively. Accordingly, the target recognition is realized by the correlation between the test image and the simulated image. Finally, the effectiveness of the proposed method is verified by the simulation experiment. It is shown that the proposed method can achieve higher computational efficiency than the conventional direct templet-based method, but remain the same high recognition rate.
- Synthetic Aperture Sonar (SAS) /
- Automatic Target Recognition (ATR) /
- Model-based recognition /
- Pose estimation /
- Simulation template

HTML全文

参考文献(22)

Williams D P and Fakiris E. Exploiting environmental information for improved underwater target classification in sonar imagery[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(10): 6284-6297.

Tai F, Kraus D, and Zoubir A M. Contributions to automatic target recognition systems for underwater mine classification [J]. IEEE Transactions on Geoscience and Remote Sensing, 2015, 53(1): 505-518.

Myers V and Fawcett J. A template matching procedure for automatic target recognition in synthetic aperture sonar imagery[J]. IEEE Signal Processing Letters, 2010, 17(7): 683-686.

Myers V and Williams D P. Adaptive multiview target classification in synthetic aperture sonar images using a partially observable markov decision process[J]. IEEE Journal of Oceanic Engineering, 2012, 37(1): 45-55.

Groen J, Coiras E, Del Rio Vera J, et al.. Model-based sea mine classification with synthetic aperture sonar[J]. IET Radar, Sonar Navigation, 2010, 4(1): 62-73.

Williams D P. Bayesian data fusion of multiview synthetic aperture sonar imagery for seabed classification[J]. IEEE Transactions on Image Processing, 2009, 18(6): 1239-1254.

Dobeck G J and Hyland J C. Automated detection and classification of sea mines in sonar imagery[J]. SPIE, 1997, Vol. 3097: 90-110.

Zhang H, Nasrabadi N M, Zhang Y, et al.. Multi-view automatic target recognition using joint sparse representation[J]. IEEE Transactions on Aerospace and Electronic Systems, 2012, 48(3): 2481-2497.

Sun Y, Liu Z, Todorovic S, et al.. Adaptive boosting for SAR automatic target recognition[J]. IEEE Transactions on Aerospace and Electronic Systems, 2007, 43(1): 112-125.

Xing X, Ji K, Zou H, et al.. Sparse representation based SAR vehicle recognition along with aspect angle[J]. The Scientific World Journal, 2014, 2014(1): 1-10.

Dong G, Wang N, and Kuang G. Sparse representation of monogenic signal: with application to rarget recognition in SAR images[J]. IEEE Signal Processing Letters, 2014, 21(8): 952-956.

Huang Y, Peia J, Yanga J, et al.. Neighborhood geometric center scaling embedding for SAR ATR[J]. IEEE Transactions on Aerospace and Electronic Systems, 2014, 50(1): 180-192.

Zhu Z, Peng S, Xu J, et al.. A fast SAS image simulator based on HPR algorithm[C]. Oceans - San Diego, 2013, San Diego, CA, USA, 2013: 1-5.

刘维, 张春华, 刘纪元. 合成孔径声呐三维数据仿真研究[J]. 系统仿真学报, 2008, 20(14): 3838-3841.

Liu Wei, Zhang Chun-hua, and Liu Ji-yuan. Research on synthetic aperture sonar 3-D data simulation[J]. Journal of System Simulation, 2008, 20(14): 3838-3841.

熊文昌, 王宏琦, 唐侃. 基于面元投影模型的SAR建筑物快速图像仿真[J]. 电子与信息学报, 2014, 36(5): 1062-1068.

Xiong Wen-chang, Wang Hong-qi, and Tang Kan. Fast SAR imaging simulation for urban structures based on facet projection model[J]. Journal of Electronics Information Technology, 2014, 36(5): 1062-1068.

倪心强. SAR图像分类与自动目标识别技术研究[D]. [博士论文], 中国科学院大学, 2007.

Ni Xin-qiang. Research of classification and automatic target recognition using SAR imagery[D]. [Ph.D. dissertation], University of Chinese Academy of Sciences, 2007.

程鹏飞, 闫浩文, 韩振辉. 一个求解多边形最小面积外接矩形的算法[J]. 工程图学学报, 2008, 29(1): 122-126.

Cheng Peng-fei, Yan Hao-wen, and Han Zhen-hui. An algorithm for computing the minimum area bounding rectangle of an arbitrary polygon[J]. Journal of Engineering Graphics, 2008, 29(1): 122-126.

Katz S, Tal A, and Basri R. Direct visibility of point sets[J]. ACM Transactions on Graphics, 2007, 26(3): 1-24.
