一种基于极坐标格式算法的高分辨SAR成像自聚焦算法

曾乐天; 梁毅; 邢孟道

doi:10.11999/JEIT141131

一种基于极坐标格式算法的高分辨SAR成像自聚焦算法

doi: 10.11999/JEIT141131

基金项目:

中央高校基本科研业务费专项资金(K5051302046)和国家自然科学基金优秀青年基金(61222108)资助课题

计量
- 文章访问数: 1425
- HTML全文浏览量: 133
- PDF下载量: 612
- 被引次数: 0
出版历程
- 收稿日期: 2014-08-27
- 修回日期: 2014-12-08
- 刊出日期: 2015-06-19

Autofocus Algorithm of High Resolution SAR Based on Polar Format Algorithm Processing

摘要

摘要: 针对机载聚束合成孔径雷达(SAR)惯导精度无法满足高分辨SAR成像的问题，该文提出了一种结合极坐标格式算法(PFA)的自聚焦算法，即由粗到精的混合多阶段参数化最小熵(Hybrid Multistage Parameterized Minimum Entropy, HMPME)距离单元徙动校正方法和基于图像对比度增强(Contrast Enhancement, CE)的变步长迭代相位误差校正方法。该自聚焦算法可以直接嵌入到PFA处理中，精确地补偿了惯导测量精度不足引起的越距离单元徙动(Range Cell Migration, RCM)和相位误差，且对于低对比度、低信噪比场景数据有良好的聚焦性能。最后，利用仿真实验和实测机载聚束SAR数据验证了所提算法的有效性。
- 合成孔径雷达 /
- 极坐标格式算法 /
- 自聚焦 /
- 参数化最小熵 /
- 对比度增强
Abstract: Equipped with an airborne spotlight SAR, inertia navigation system can not measure the motion errors with the required accuracy for high resolution SAR imaging, which may degrade severely the quality of a SAR image. In this paper, a novel autofocus algorithm that can be directly embedded in Polar Format Algorithm (PFA) is proposed, that is, a Hybrid Multistage Parameterized Minimum Entropy (HMPME) algorithm to proceed Range Cell Migration (RCM) correction and a scaled-stepsize iterative phase correction method based on Contrast Enhancement (CE). The autofocus processing accurately compensates the effects of range cell migration and phase errors. Also, this algorithm is most robust in processing images of low contrast and low signal-to-noise ratio. Finally, simulations and experiments with real spotlight SAR data validate the effectiveness of the proposed algorithm.
- SAR /
- Polar Format Algorithm (PFA) /
- Autofocus /
- Parameterized minimum entropy /
- Contrast enhancement

HTML全文

参考文献(14)

张磊. 高分辨SAR/ISAR成像及误差补偿技术研究[D]. [博士论文], 西安电子科技大学, 2012.

Zhang Lei. Study on high resolution SAR/ISAR imaging and error correction[D]. [Ph.D. dissertation], Xidian University, 2012.

Yang Lei, Xing Meng-dao, Wang Yong, et al.. Compensation for the NsRCM and phase error after polar format resampling for airborne spotlight SAR raw data of high resolution[J]. IEEE Geoscience and Remote Sensing Letters, 2013, 10(1): 165-169.

Carrara G, Goodman S, and Majewski M. Spotlight Synthetic Aperture Radar: Signal Processing Algorithm[M]. Boston, MA: Artech House, 1995: 200-244.

Xu Gang, Xing Meng-dao, Zhang Lei, et al.. Robust autofocusing approach for highly squinted SAR imagery using the extended wavenumber algorithm[J]. IEEE Transactions on Geoscience and Remote Sensing, 2013, 51(10): 5031-5046.

黄大荣, 张磊, 邢孟道, 等. 基于加权最大范数的SAR自聚焦方法[J].?电子与信息学报,?2014,?36(1):?202-208.

Huang Da-rong, Zhang Lei, Xing Meng-dao, et al.. A weighted maximize norm method for SAR autofocus[J]. Journal of Electronics Information Technology, 2014, 36(1): 202-208.

Wahl D E, Eichel P H, Ghiglia D C, et al.. Phase gradient autofocus-a robust tool for high resolution phase correction[J]. IEEE Transactions on Aerospace and Electronic Systems, 1994, 30(3): 827-835.

Ye Wei, Yeo T S, and Bao Zheng. Weighted least-squares estimation of phase errors for SAR/ISAR autofocus[J]. IEEE Transactions on Geoscience and Remote Sensing, 1999, 37(5): 2487-2494.

Xiong Tao, Xing Meng-dao, Wang Yong, et al.. Minimum- entropy-based autofocus algorithm for SAR data using Chebyshev approximation and method of series reversion, and its implementation in a data processor[J]. IEEE Transactions on Geoscience and Remote Sensing, 2014, 52(3): 1719-1728.

Gao Yang, Yu Wei-dong, Liu Ya-bo, et al.. Sharpness-based autofocus for stripmap SAR using an adaptive-order polynomial model[J]. IEEE Geoscience and Remote Sensing Letters, 2014, 11(6): 1086-1090.

Doerry A W. Autofocus correction of excessive migration in synthetic aperture radar images[R]. Sandia Laboratory, 2004.

Thomas K J and Alaa K A. Monotonic iterative algorithm for minimum-entropy autofocus[C]. IEEE International Conference on Image Processing, Atlanta, USA, 2006: 645-648.

Josse K. Image reconstruction and restoration using constrained optimization algorithms[D]. [Ph.D. dissertation], Purdue University, 1996.
