一种基于边缘的图像配准方法
An Image Edge Based Algorithm for Multisensor Image Registration
-
摘要: 图像配准是多传感器图像融合研究中的一项关键技术,多传感器图像特别是波段相距较远的相关性较小的图像,要实现图像配准存在很大的困难。对于能够用仿射变换模型来描述的图像,图像之间比较明显的特征是各个物体之间的边缘。该文研究利用小波变换的方法提取图像的边缘,并对边缘图像作交互方差分析,搜索出最佳交互方差的配准参数。通过对SPOT和TM图像的处理,达到了精度较高的配准效果。
-
关键词:
- 图像配准; 图像融合; 边缘检测
Abstract: Image registration is an very important technology in multisensor image fusion. There is little correlation among multisensor images, especially images with different bands. It is very difficult to matching these images. Among some images which can be described in affine model, edge is a very obvious character. In this article, wavelet analysis is used to extract image edge, then correlative deviation is calculated. When correlative deviation reaches the minor, the image registration parameters are obtained. The processing of SPOT and TM images demonstrates the efficacy of the proposed method. -
Brown L G. A survey of inage registration techniques[J].ACM Computing Surveys.1992, 24(4):325-376[2]Hui Li, Manjunath B S. A contour-based approach to multisensor image registration. IEEE Trans. on Image Processing, 1995, IP-4(3): 320-334.[3]Jun-Wei Hsieh. Image registration using a new edge-based approach[J].Computer Vision and Image Understanding.1997, 67(2):112-130[4]Mallat S. Singularity detection and processing with wavelets[J]. IEEE Trans. on Information Theory, 1992, IT-38(2): 617-643.[5]Mallat S. Characterization of signals from multiscale edges[J].IEEE Trans. on Pattern Analysis Machine Intelligence.1992, 14(7):710-732[6]王东峰.多模态图像配准和大型图像配准.[博士论文],北京:中国科学院电子学研究所,2002. 期刊类型引用(6)
1. 章蕾，张执. 基于虚拟现实技术的康复训练系统设计与效果评估研究. 计算机测量与控制. 2025(02): 317-324 .
百度学术2. 郑威，杨俊杰，陶坤宇. 姿态航向参考系统中关联信息分级解耦方法. 上海电机学院学报. 2025(01): 45-51 . 百度学术3. 莫玲，龙顺宇，蒋冠东，刘世杰. 基于STM32小型四旋翼飞行器硬件系统设计与实现. 工业控制计算机. 2024(05): 150-152 . 百度学术4. 靳建波，孔令哲. 船载惯性测量单元姿态信息优化方法. 空间电子技术. 2022(05): 63-67 . 百度学术5. 于玉丹，林伟，俞朝阳. 改进Sage-Husa 算法结合小波模糊阈值算法的MEMS陀螺去噪. 电子测量技术. 2022(19): 64-69 . 百度学术6. 刘春，何敏，戴雷. 基于Mahony与改进Kalman融合的姿态解算方法. 电子测量与仪器学报. 2022(09): 64-71 . 百度学术其他类型引用(8)
-
