考虑螺带厚度的纵向导体加载螺旋慢波特性分析

雷文强; 杨中海; 廖平

考虑螺带厚度的纵向导体加载螺旋慢波特性分析

计量
- 文章访问数: 2436
- HTML全文浏览量: 103
- PDF下载量: 482
- 被引次数: 0
出版历程
- 收稿日期: 2003-04-04
- 修回日期: 2003-08-18
- 刊出日期: 2004-09-19

Vane-Loaded Helical Slow-Wave Characteristic Analysis Considering Helical Tape Thickness

摘要

摘要: 考虑非翼片区角向高次模式以及螺带厚度，运用场匹配方法参考脊加载环板慢波结构的边界条件推导得到翼片加载螺旋慢波结构的色散特性方程；并运用MAFIA软件对该结构进行模拟计算，将理论结果与模拟计算进行比较，其误差范围基本满足设计精度的要求，并讨论了不同翼片结构参数对色散特性的影响，为各种类型的翼片加载螺旋慢波特性的计算提供了一种参考方法。
- 场论匹配方法;色散特性;非翼片区角向高次模式;螺带厚度;MAFIA软件
Abstract: Considering azimuthal higher order modes in non-vane area and helical tape thickness, using field matching method and boundary condition of the ridge-loaded ring-piano slow wave structure, the dispersion equation of vane-load helical slow-wave structure is obtained. The numerical simulation for the vane-loaded helical slow-wave structure using MAFIA software is done. The theory calculation results are compared with the simulation results. Their errors reach the request of design precision. The effect of the dispersion is discussed in the different parameters of the vane structure. The instruction method also is provided for other types vane-load helical slow-wave structure.

HTML全文

参考文献(1)

赵士录.连续波宽带大功率行波管中的色散成型及谐波抑制技术研究.电子学报.1999,27(3):113-115. ［2］Paik S F. Design formulas for helix dispersion shaping. IEEE Trans. on Electron. Devices, 1969,16(12): 1010-1014. ［3］Kumar L, Raju R S, et al.. Modeling of a vane-loaded helical slow-wave structure for broad-band traveling-wave tubes. IEEE Trans. on Electron. Devices, 1989, 36(9): 1991-1999. ［4］AK Sinha R Verma, et al.. An improved model for the analysis of segment loaded helical slow-wave used in traveling wave tubes, 4th International Symposium on Recent Advances in Microwave Technology, India, 1993 C2.1: 144-147. ［5］范植开,刘庆想.谐振腔链色散关系及场分布的解析研究.物理学报,2000,49(7):1249-1255. ［6］Gong Y B, Wang W X, et al.. Theoretical analysis of ridge-loaded ring-plane slow wave structure by variational methods. IEE Proc.-Microw. Antennas Propag., 1998, 145(5): 397-405. ［7］张勇,莫元龙.有限厚度翼片加载螺旋线模型.电子科技大学学报,2002,31(5):479-484. ［8］The Mafia Collaboration.2000 Mafia User Manual,version4.0.25(Germany:CST.Inc),2000:221. ［9］刘盛纲,李宏福等.微波电子学导论.北京:国防工业出版社,1984:162-164. ［10］张克潜,李德杰.微波与光电子学中的电磁理论.北京:电子工业出版社,2001:255-259. ［11］Jain P K,Basu B N.The inhomogeneous loading effects of practical dielectric supports fbr the helical slow-wave structure of a TWT.IEEE Trans.on Electron.Devices,1987,34(12):2643-2648. ［12］宫玉彬.新型大功率行波管的研究.[博士论文],成都:电子科技大学.1998:22-25. ［13］Kory C L,Dayton J A.Accurate cold-test model of helical TWT slow-wave circuits.IEEE Trans.on Electron.Devices,1998,45(4):966-971. ［14］樊孝年,贾会文等.用MAFIA软件计算改进的梳形慢波线的色散特性.真空电子技术,1999,4:10-13. ［15］雷文强,杨中海等.螺旋慢波电路高频特性的三维计算模拟.强激光与粒子束,2002,14(6):892-896.
