基于FDTD的波导介质层PBG结构的研究
Research on Dielectric Layer PBG Structures in Waveguide Based on FDTD
-
摘要: 该文提出了波导中介质层式的PBG结构，并对其阻带特性进行了数值分析，其中包括PBG 结构的设计，周期长度、周期个数、单元尺寸等几个方面对阻带特性的影响等，并给出了结论。利用介质层PBG结构来制作波导滤波器具有设计简单、易于实现的显著优点。Abstract: In this paper, a new dielectric layer PBG structures in waveguide is introduced, and numerical analysis to its stop-band characteristic is finished. The design of PBG structures and the effect of the size of period, the number of periods, the size of unit etc. are presented. And the conclusion is presented too. It is easy to design and manufacture waveguide filter using dielectric layer PBG structures.
-
Yablonovitch E. Inhibited spontaneous emission in solid-state physics and electronics[J].Phys. Rev.Lett.1987, 58(20):2059-2062[2]Vesna Radisic, Yongxi Qian, Roberto Coccioli, et al.. Novel 2-D photonic bandgap structure for microstrip lines[J].IEEE Microwave Guided Wave Lett.1998, 8(2):69-071[3]Yasushi Horii, Makoto Tsutsumi. Harmonic control by photonic bandgap on microstrip patch antenna[J].IEEE Microwave Guided Wave Lett.1999, 9(1):13-15[4]Joseph S. Colburn, Yahya Rahmat-Samii. Patch antennas on externally perforated high dielectric constant substrates. IEEE Trans. on Antennas Propagat., 1999, AP-47(12): 1785-1794.[5]Smith D R, Schultz S. A New type of waveguide structures with photonic band structures. IEEE MTT-S Digest, 1996: 911-914. -
