参数微扰方法对Boost变换器的混沌控制
Small Parametric Perturbation Method in Controlling Boost Converter
-
摘要: 该文使用参数微扰方法控制电流控制模式Boost变换器在连续电流模式下产生的混沌行为。文中利用离散模型确定了系统运行的混沌区域,并在设计控制环时作了适当的简化,以利于实现。仿真分析和实验都显示,这一方法对于开关电路是有效的。电路的稳定被重新建立,并在此基础上进一步扩大了变换器的工作范围,文中还分析了噪声在控制中的影响。
-
关键词:
- Boost变换器; 分岔; 混沌控制
Abstract: OGY method(1990) is applied to control the chaos exhibited by current-mode controlled boost dc-dc converter, as its chaotic regime has been established in this paper. This is achieved by using discrete-time model and making simplification of the control loop design. Both simulation and experiment are done. Stability of the circuit is obtained, which proves this control method is valid in controlling switching circuit. -
Deane J H B. Chaos in a current-mode controlled boost dc-dc converter. IEEE Trans. on Circuits and Systems-I, 1992, CAS-I-39(8): 680-683.[2]Banerjee S, Chakrabarty K. Nonlinear modeling and bifurcation in the boost converter[J].IEEE Trans. on Power Electronics.1998, 13(2):252-260[3]Chan W C Y, Tse C K. Study of bifurcations in current programmed dc/dc boost converters:Form qusiperiodicity to period doubling. IEEE Trans. on Circuits and Systems-I, 1997, CAS-I-44(12): 1129-1142.[4]Pyragas K. Continuous control of chaos by self-controlling feedback[J].Phys. Lett. A.1992, 170:421-428[5]G. Chen, X. Dong. On feedback control of chaotic nonlinear dynamic systems. Int. J. Bifurcation and Chaos, 1992, 2(2): 407-411.[6]Poddar G, Chakrabarty K, Banerjee S. Control of chaos in dc-dc converters. IEEE Trans. on Circuits and Systems-I, 1998, CAS-I-45(6): 672-676.[7]Ott E, Grebogi C, Yorke J. Controlling chaos[J].Phys. Rev. Lett.1990, 64(11):1196-1199 -
